Alloy Steel Seamless Tubes ASTM A213 / SA213 T5 T9 T11 T22 T23 T91 T92 / ASTM A335 / SA335 P5 P9 P11 P22 P91 P92 tube
Alloy steel tubes is a kind of steel alloyed tube with other elements in amounts
of between 1 and 50% by weight to improve its mechanical properties.Alloying
elements are added to achieve certain properties in the material. As a guideline,
alloying elements are added in lower percentages (less than 5%) to increase
strength or harden ability or in larger percentages (over 5%) to achieve special
properties, such as corrosion resistance or extreme temperature stability.
Main Materials:
ASTM 213(Seamless Ferritic and Austenitic Alloy-Steel Boiler, Superheater, and Heat-Exchanger Tubes)
ASTM A213 T5, T9, T11, T22, T23, T91, T92
ASTM A335 (Seamless Ferritic Alloy-Steel Pipe for High-Temperature Service)
ASTM A335 P5, P9, P11, P22, P91, P92
ASTM A/ASME SA 213 specification pipes are available in grades including T5, T9, T11, T22, T23, T91, T92. ASTM A/ASME SA335 Grade P5, P9, P11, P22, P91, P92. Alloy steel tubes are generally available in stock with OD sizes in all standard sizes and thicknesses.On demand, we can offer our customers with high quality alloy steel pipes and tubes with black painting, anti-corrosion oil and galvanised finish.
| Trade Name | Grade | UNS # | Heater Tubes |
| 1 1/4 Chrome | T11 | K11597 | A213 / SA213 |
| 2 1/4 Chrome | T22 | K21590 | A213 / SA213 |
| 5 Chrome | T5 | K41545 | A213 / SA213 |
| 9 Chrome | T9 | K90941 | A213 / SA213 |
| T91 | T91 | K90901 | A213 / SA213 |
| T92 | T92 | K92460 | A213 / SA213 |
| Trade Name | Grade | UNS # | Pipe | Forged / Bored Pipe* |
| 1 1/4 Chrome | P11 | K11597 | A335 / SA335 | A369 / SA369 |
| 2 1/4 Chrome | P22 | K21590 | A335 / SA335 | A369 / SA369 |
| 5 Chrome | P5 | K41545 | A335 / SA335 | A369 / SA369 |
| 9 Chrome | P9 | S50400 | A335 / SA335 | A369 / SA369 |
| P91 | P91 | K91560 | A335 / SA335 | A369 / SA369 |
| P92 | P92 | K92460 | A335 / SA335 | A369 / SA369 |
Chemical composition(%):
| Grade | C | Mn | P≤ | S≤ | Si | Cr | Mo |
| P11 | 0.05-0.15 | 0.30-0.60 | 0.025 | 0.025 | 0.50-1.00 | 1.00-1.50 | 0.44-0.65 |
| P22 | 0.05-0.16 | 0.30-0.60 | 0.025 | 0.025 | ≤0.50 | 1.90-2.60 | 0.87-1.13 |
| P5 | ≤0.15 | 0.30-0.60 | 0.025 | 0.025 | ≤0.50 | 4.00-6.00 | 0.45-0.65 |
| P9 | ≤0.15 | 0.30-0.60 | 0.025 | 0.025 | 0.25-1.00 | 8.00-10.00 | 0.90-1.10 |
| P91 | 0.08-0.12 | 0.30-0.60 | 0.020/0.010 | 0.020/0.010 | 0.02-0.50 | 8.00-9.50 | 0.85-1.05 |
| P92 | 0.07-0.13 | 0.30-0.60 | 0.020/0.010 | 0.020/0.010 | ≤0.50 | 8.50-9.50 | 0.30-0.60 |
Mechanical properties:
| Grade | Tensile strength | Yield strength | Elongation |
| P11, P22, P5, P9 | ≥415 | ≥205 | ≥30/20 |
| P91 | ≥585 | ≥415 | ≥20 |
| P92 | ≥620 | ≥440 | ≥20 |
Type:Seamless
Form:Round Pipes/Tubes, Square Pipes/Tubes, Coiled Tubes,Pan Cake Coils, Hydraulic Tubes
Length:Single Random, Double Random & Required Length
End:Plain End, Beveled End, Treaded
End Protection:Plastic Caps
Outside Coating:Black Painting, Anti-Corrosion Oil, Galvanized Finish, Finish as per customer Requirements
Inspection, Test Reports:Mill Test Certificates, EN 10204 3.1, Chemical Reports, Mechanical Reports, PMI Test Reports, Visual Inspection Reports, Third Party Inspection Reports, NABL Approved Lab Reports, Destructive Test Report, Non Destructive Test Reports.
