ASTM B366 UNS N04400, Monel 400 Butt Weld Nickel Alloy Steel Pipe Fittings, Elbows, Reducers

ASTM B366 UNS N04400, Monel 400 Butt Weld Nickel Alloy Steel Pipe Fittings, Elbows, Reducers

  • ASTM B366 UNS N04400, Monel 400 Butt Weld Nickel Alloy Steel Pipe Fittings, Elbows, Reducers
  • ASTM B366 UNS N04400, Monel 400 Butt Weld Nickel Alloy Steel Pipe Fittings, Elbows, Reducers
  • ASTM B366 UNS N04400, Monel 400 Butt Weld Nickel Alloy Steel Pipe Fittings, Elbows, Reducers
  • ASTM B366 UNS N04400, Monel 400 Butt Weld Nickel Alloy Steel Pipe Fittings, Elbows, Reducers
ASTM B366 UNS N04400, Monel 400 Butt Weld Nickel Alloy Steel Pipe Fittings, Elbows, Reducers
Product Details:
Place of Origin: China
Brand Name: YUHONG
Certification: ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2015
Model Number: UNS N04400, Monel 400
Payment & Shipping Terms:
Minimum Order Quantity: 3 Piece
Price: Negotiable
Packaging Details: Ply-wooden Case / Pallet
Delivery Time: 10-60 Work Days
Payment Terms: T/T, L/C
Supply Ability: According to Clients' Requirement
Contact Now
Detailed Product Description
Standard: ASTM B366, ASME SB366 Material Grade: UNS N04400, Monel 400
Size: 1/2''-48''(DN15-DN1200) Product Name: Nickel Alloy Steel Pipe Fittings
Type: Elbow,Nipple,Reducer,Tee,Union,Coupling,Etc. Application: Construction,Gas And Oil Pipes,Air,Petroleum Gas Water,Etc.
High Light:

Buttweld Nickel Alloy Steel Pipe Fittings

,

Monel 400 Steel Pipe Fittings

,

Nickel Alloy Steel Pipe Elbow

ASTM B366 UNS N04400, Monel 400 Butt Weld Nickel Alloy Steel Pipe Fittings, Elbows, Reducers



Monel 400 is a high performance, high strength alloy of nickel and copper (with trace amounts of iron, manganese, carbon, and silicon content). It exhibits excellent resistance to acids and alkalis, good ductility, and good thermal conductivity, and can be hardened only by cold-working.



ASTM B366 UNS N04400 / Monel 400 Nickel Alloy Buttweld Fittings are resistant to caustic solvents, acids and alkaline, as well as seawater, has high robustness at high temperatures, and are wieldable too, used in many marine engineering applications. Monel 400 pipe fittings are an excellent choice for applications that require superior resistance to corrosion and erosion.



Specifications:

Grade Monel 400, UNS N04400
size Seamless Butt Weld Fittings: 1/2" - 10"
Welded Butt Weld Fittings: 1/2" - 48"
Type DN15-DN1200
Connection Welding
Form 90 Elbow, 45 Elbow, Long Radius Elbow, Short Radius Elbow, Concentric Reducer, Eccentric Reducer, Equal Tee, Unequal Tee, Lateral Tee, Cross, Bends 1.5D, 3D, 5D, 10D, U bend, 180 Deg Bend, Short Stub End, Long stub end, End Cap, Dish Cap
Dimensions ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1560, BS10
Thickness SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH 80, SCH 100, SCH 120, SCH 140, SCH 160, XXS
Bending Radius R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom
Manufacturing process Push, Press, Forge, Cast, etc.



ASTM B366 UNS N04400, Monel 400 Butt Weld Nickel Alloy Steel Pipe Fittings, Elbows, Reducers 0



Equivalent Grades:

STANDARD UNS WERKSTOFF NR. AFNOR EN JIS BS GOST
Monel 400 N04400 2.4360 NU-30M NiCu30Fe NW 4400 NA 13 МНЖМц 28-2,5-1,5



Product Features:

Corrosion resistant

Sustain high pressure & temperature load

Rust proof finish

Excellent stress distribution



Chemical Composition:

Ni 63 min
C 0.3 max
Al 0.5 max
Mn 2 max
Si 0.5 max
Fe 1 – 2.5
Cu 28 – 34.
S 0.02 max



Mechanical Properties:

Density Melting Point Yield Strength (0.2%Offset) Tensile Strength Elongation
8.8 g/cm3 1350 °C (2460 °F) Psi – 35,000 , MPa – 240 Psi – 80,000 , MPa – 550 40 %



Applications:

Condensers

Heat Exchangers

Pharmaceuticals

Sea Water Equipments

Pulp and Paper Industries

Power Generation

Gas Processing Plants

Chemical & Petrochemicals Equipments



ASTM B366 UNS N04400, Monel 400 Butt Weld Nickel Alloy Steel Pipe Fittings, Elbows, Reducers 1
