Yuhong Holding Group Co.,LTD
 |
| Place of Origin: | China |
| Brand Name: | YUHONG |
| Certification: | ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008 |
| Model Number: | ASME SA182 F304 SPACER RING |
| Minimum Order Quantity: | 1PC |
|---|---|
| Price: | Negotiable |
| Packaging Details: | According to client requirements/wooden case packing |
| Delivery Time: | Depends on quantity |
| Payment Terms: | L/C AT SIGHT, T/T |
| Supply Ability: | 100 pcs per month |
| Steel Grade: | SS304 | Application: | Boiler, Superheater, Heat-Exchanger, And Condenser... |
|---|---|---|---|
| Workmanship: | FORGING PROCESS | Standard: | ASTM,AISI |
| Shape: | Circular | Package: | Standard Seaworthy Package |
| High Light: | Forged Spacer Ring,Pressure Vessel Spacer Ring,Forged Steel Rings ASME SA182 |
||
Overview
A182 F304 Forged Ring refers to a specific type of ring made from the stainless steel alloy A182 F304 through the forging process. The A182 F304 designation indicates that the ring is made from a stainless steel alloy that conforms to the ASTM A182 standard specification. The "F" signifies that it is a forging-grade stainless steel, specifically designed for use in high-temperature and high-pressure applications.
The number "304" represents the composition of the stainless steel alloy, indicating that it contains approximately 18% chromium and 8% nickel. This composition gives the stainless steel excellent corrosion resistance, high strength, and good formability.
Forging is a manufacturing process whereby the stainless steel material is shaped and formed by applying compressive forces to it under high temperature. This process results in a ring with improved mechanical properties, such as enhanced strength, greater resistance to fatigue, and improved structural integrity compared to other manufacturing methods.
A182 F304 Forged Rings are commonly used in industries such as oil and gas, petrochemical, chemical processing, power generation, and others where corrosion resistance, high strength, and durability are crucial. These rings are often employed in applications requiring reliable sealing, connecting, or supporting components in equipment and systems subjected to demanding operating conditions.
The specific dimensions, sizes, and tolerances of A182 F304 Forged Rings can vary based on the application requirements and industry standards. It is important to consult the appropriate specifications and standards to ensure the correct selection and use of these rings in specific applications.
SS304 Chemical Composition and Mechanical Property
| Steel Grade | Chemical Composition | Mechanical Performance | |||||||||
| C (Max) | Si (Max) | Mn (Max) | P (Max) | S (Max) | Ni | Cr | N (Max) | Mo | Tensile Strength (Min) |
Yield Strength (Min) |
|
| Mpa | Mpa | ||||||||||
| 304 | 0.08 | 0.75 | 2.00 | 0.045 | 0.03 | 8.0–10.5 | 18.0–20.0 | 0.1 | / | 515 | 205 |
Short Introduction:
|
Largest OD:2500mm
|
Element:
| C:≤0.08% | Si≤1% |
| Mn:≤2.00% | P≤0.045% |
| S≤0.030% | Ni:8%~11% |
| Cr:18.0~20.0% |
Specification
Features
Testing mandatorily executed
Pharmaceutical Equipment
Chemical Equipment
Sea Water Equipment
Heat Exchangers
Condensers
Pulp and Paper Industry
Off-Shore Oil Drilling Companies
Power Generation
Petrochemicals
Gas Processing
Specialty Chemicals
Pharmaceuticals
