Yuhong Holding Group Co.,LTD
 |
| Place of Origin: | China |
| Brand Name: | Yuhong Group |
| Certification: | ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008 |
| Model Number: | ASTM A270 TP304L |
| Minimum Order Quantity: | 100 kgs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Ply-wooden Case /Iron Case/ Bundle |
| Delivery Time: | 7 days |
| Payment Terms: | L/C, T/T |
| Material: | TP304 | Standard: | GB,DIN,ASTM,JIS,AISI |
|---|---|---|---|
| Type: | Seamless Or Welded | Surface: | Annealing, Pickling, Polishing, 600 Grit Polished, Bright |
| High Light: | Stainless Steel Welded Sanitary Tube,TP304L Stainless Steel Sanitary Pipe,Food Industry Stainless Sanitary Tubing |
||
Yuhong is one of the famous ASTM A270 TP304 sanitary stainless steel pipe suppliers, we provide these after checking all the quality parameters by our experienced and knowledgeable staff. We stock welded and seamless stainless steel pipes in various industry standard sizes. After more than 20 years of development, we have accumulated a large number of customers all over the world, and Yuhong products have also won unanimous praise from customers.
| ASTM A270 TP304 Sanitary Tubing Type | Seamless and Welded Austenitic and Ferritic/Austenitic Stainless Steel Sanitary Tubing |
| ASTM A270 TP304 Sanitary Tubing OD. | 1/2”-4” |
| ASTM A270 TP304 Sanitary Tubing Wall | 16 Gauge (0.065”) |
| ASTM A270 TP304 Sanitary Tubing Length | 20′ |
| ASTM A270 TP304 Sanitary Tubing OD Tolerance | +/-0.005” / +/-0.13MM |
| ASTM A270 TP304 Sanitary Tubing WT Tolerance | +/-10% |
| ASTM A270 TP304 Sanitary Tubing Length Tolerance | +1/8” / +3.18MM |
| ASTM A270 TP304 Sanitary Tubing Material | SS 304, SS 304L,SS 316,SS 316L |
| ASTM A270 TP304 Sanitary Tubing Standard | ASTM A270 / A270M |
| ASTM A270 TP304 Sanitary Tubing Finish | 2B MIll Finish , No.4 finish, BA Finish, 400 Grit Finish, 550 Grit Finish, 600 Grit Finish |
| ASTM A270 TP304 Sanitary Tubing Polish | Mechanical Polished |
| ASTM A270 TP304 Sanitary Tubing Type | Seamless |
| ASTM A270 TP304 Sanitary Tubing Certification | 3A – Food / Dairy Grade |
| ASTM A270 TP304 Sanitary Tubing Mill Test Certificate | EN10204 3.1 |
| ASTM A270 TP304 Product | ASTM A270 304 Sanitary Tubing, ASTM A270 SS304 Seamless Sanitary Tubes, ASTM A270 Type 304 Tubing, ASTM A270 TP304 Welded Sanitary Tubing, ASTM A270 304 Welded Sanitary Tubes, ASTM A270 TP304 Stainless Steel Sanitary Tubing |
| ASTM A270 TP304 Sanitary Tubing Packing | Sleeved, Ends Capped, Wooden Boxe |
| NB SIZES | SCH 5 | SCH 10 | SCH 40 | SCH 80 | SCH 160 |
| 1/8″ | √ | √ | √ | √ | |
| 1/4″ | √ | √ | √ | √ | |
| 3/8″ | √ | √ | √ | √ | |
| 1/2″ | √ | √ | √ | √ | √ |
| 3/4″ | √ | √ | √ | √ | √ |
| 1″ | √ | √ | √ | √ | √ |
| 1 1/4″ | √ | √ | √ | √ | √ |
| 1 1/2″ | √ | √ | √ | √ | √ |
| 2″ | √ | √ | √ | √ | √ |
| 2 1/2″ | √ | √ | √ | √ | √ |
| 3″ | √ | √ | √ | √ | √ |
| 4″ | √ | √ | √ | √ | √ |
| 5″ | √ | √ | √ | √ | |
| 6″ | √ | √ | √ | √ |
DIMENSIONAL TOLERANCE OF ASTM A270 TP304 SANITARY TUBING
| Tube | SIZE OD | NOMINAL WALL THICKNESS | OUTSIDE DIAMETER TOLERANCE | LENGTH TOLERANCE | WALL THICKNESS TOLERANCE | ||||
| ASTM 270 | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (%) |
| ASTM 270 | ½ | 12.7 | 0.065 | 1.65 | +/-0.005 | +/-0.13 | +⅛, -0 | +3.18, -0 | +/-10.0% |
| ASTM 270 | ¾ | 19.1 | 0.065 | 1.65 | +/-0.005 | +/-0.13 | +⅛, -0 | +3.18, -0 | +/-10.0% |
| ASTM 270 | 1 | 25.4 | 0.065 | 1.65 | +/-0.005 | +/-0.13 | +⅛, -0 | +3.18, -0 | +/-10.0% |
| ASTM 270 | 1½ | 38.1 | 0.065 | 1.65 | +/-0.008 | +/-0.20 | +⅛, -0 | +3.18, -0 | +/-10.0% |
| ASTM 270 | 2 | 50.8 | 0.065 | 1.65 | +/-0.008 | +/-0.20 | +⅛, -0 | +3.18, -0 | +/-10.0% |
| ASTM 270 | 2½ | 63.5 | 0.065 | 1.65 | +/-0.010 | +/-0.25 | +⅛, -0 | +3.18, -0 | +/-10.0% |
| ASTM 270 | 3 | 76.2 | 0.065 | 1.65 | +/-0.010 | +/-0.25 | +⅛, -0 | +3.18, -0 | +/-10.0% |
| ASTM 270 | 4 | 101.6 | 0.083 | 2.11 | +/-0.015 | +/-0.38 | +⅛, -0 | +3.18, -0 | +/-10.0% |
| ASTM 270 | 6 | 152.4 | 0.109 | 2.77 | +/-0.030 | +/-0.76 | +1, -0 | +25.4, -0 | +/-10.0% |
