Yuhong Holding Group Co.,LTD
 |
| Place of Origin: | CHINA |
| Brand Name: | YUHONG |
| Certification: | ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2015 |
| Model Number: | F55 |
| Minimum Order Quantity: | 1PC |
|---|---|
| Price: | negotiation |
| Packaging Details: | PLYWOOD CASE,PALLET |
| Delivery Time: | Depends on quantity |
| Payment Terms: | T/T, L/C at sight |
| Supply Ability: | 10000Ton/Month |
| TYPE: | WNRF,BLRF | SIZE: | 1/2" TO 36" |
|---|---|---|---|
| WT: | Sch10s To XXS | STANDARD: | ASTM A182 |
Chemical Composition of A182 F55 Flanges
| C | Mn | Si | P | S | Cr | Mo | Ni | N | Fe |
|---|---|---|---|---|---|---|---|---|---|
| 0.05 max | 1.00 max | 1.00 max | 0.030 max | 0.010 max | 24.00 – 26.00 | 3.00 – 4.00 | 6.00 – 8.00 | 0.20 – 0.30 |
57.61 min
|
| Density (g/cm 3) | Density (lb/in 3) | Melting Point (°C) | Melting Point (°F) |
|---|---|---|---|
| 7.8 | 0.281 | 1350 | 2460 |
Flanges are available in different surface types. Surface types include flat surfaces, raised surfaces, and annular connections.SA182 F55 RTJ flanges have an annular connection. The flange is held in two halves. The flange end has a groove machined into the surface. The two halves are connected by a middle ring that is pressed into the groove.ASTM A182 F55 UNS S32760 Blinds are used to close the pipe. There are also different types of blind plates. Blind plates are available in forged, screwed, threaded and plate flanges. Depending on the size, there are different pressure classes.ASTM A182 Gr F55 Slip On Flanges and other flanges can be classified as Class 150 to Class 2500 depending on the pressure capacity. Flanges are available in sizes ranging from 1/8 in. to 48 in. UNS S32760 F55 threaded flanges are used with threaded pipe. The male threaded pipe end is connected to the female threaded flange.
Application
Oil and Gas Pipeline
Chemical Industry
Petrochemical industry
Food industry
Aviation and aerospace industry
