Yuhong Holding Group Co.,LTD
 |
| Place of Origin: | CHINA |
| Brand Name: | YUHONG |
| Certification: | ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008 |
| Model Number: | SB338 Gr1 Gr2 Gr3 Gr4 Gr5 Gr7 Gr6 |
| Minimum Order Quantity: | 500KGS |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Wooden Box package |
| Delivery Time: | 10-15 DAYS |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 1000Ton per month |
| SPEC: | SB338 | Material: | SB338 Gr1 Gr2 Gr3 Gr4 Gr5 Gr7 Gr6 |
|---|---|---|---|
| Size: | As Per Client's Request | Application: | Industrial, Medical |
| Technique: | Hot Rolled |
As an alloy, Titanium Round Tubes is recognized for having a high strength to weight ratio. titanium NCF Tubes are considered to be a strong alloy with low density. Additionally, the titanium alloy tubing is quite ductile. The titanium tubing material is paramagnetic in nature. As compared to other metals, titanium alloy tube has a fairly low electrical and thermal conductivity.
| Item | Titanium Tube / Titanium Pipe |
| Standard |
ASTM B861-05,ASTM B862-05,ASTM B338-06,GB/T3625-2007, GB/T3624-2007,JISH4630-2001,JISH4631-2009,etc |
| Material |
TA1,Gr.1,TP270H,BT1-00,TA2,TP340H,Gr.2,BT1-0,Ti2,TA3,Gr.3, TP480H,Ti3,TA9,Gr.7,TA10,Gr.12,etc |
| Size |
OD:2-910mm WT:0.2-100mm Length:1-10m,or as reqired |
| Package |
Standard export package,suit for air and sea transport,by wooden box or as required |
| Price term | Ex-Work,FOB,CNF,CFR,CIF,etc |
| Export to |
Poland ,India,Singapore,Indonesia,Dubai,Ukraine,Saudi Arabia,Spain, Brazil,Korea,Thailand,USA,UK,Canada,Ireland,etc |
| MOQ | 100Kg |
| Application |
Because of the titanium excellent corrosion resistance, titanium material widely used in petroleum,chemical,salt,Pharmaceutical, metallurgy,electronic,aviation, aerospace, Marine,etc. |
| Contact |
If you have any question,please feel free to contact us . We are sure your inquiry or requirements will get prompt attention. |
|
Dimension
|
Outer Diameter
|
Thickness
|
Length
|
|---|---|---|---|
|
Size Range:
|
0.5mm – 330mm
|
0.4mm – 10mm
|
Max 15m
|
|
Manufacturing Standards
|
ASTM B338, ASTM B861, DIN 17 861
|
||
|
Tensile strength
|
Yeild strength min max |
Elongation | |||
| MPa | kis | ksi Mpa | ksi Mpa | % | |
| Gr 1 | 240 | 35 | 20(138) | 45(310) | 24 |
| Gr 2 | 345 | 50 | 40(275) | 65(450) | 20 |
| Gr 3 | 450 | 65 | 55(380) | 80(550) | 18 |
| Gr 7 | 345 | 50 | 40(275) | 65(450) | 20 |
| Gr 9 | 620 | 90 | 70(483) | ... | 15 |
| Gr11 | 240 | 35 | 20(138) | 45(310) | 24 |
| Gr12 | 483 | 70 | 50(345) | ... | 18 |
| Gr13 | 275 | 40 | 25(170) | ... | 24 |
| Gr14 | 410 | 60 | 40(275) | ... | 20 |
| Surface Finish | Internal Surface(ID) | Exterbal Surface(OD) | |||
| Roughness Average(RA) | Roughness Average(RA) | ||||
| μ inch | μm | μ inch | μm | ||
| MP | Mechanical Polish | 40,32,25,20 | 1.0,0.8,0.6,0.5 | 32 | 0.8 |
| EP | Electro Polish | 15,10,7,5 | 0.38,0.25,0.20;0.13 | 32 | 0.8 |
| BA | Beight Annealed | 40,32,25,20 | 1.0,0.8,0.6,0.5 | 32 | 0.8 |
| AP | Annealed & Pickled | Not defined | Not defined | 40 or Not defined | 1.0 or Not defined |
Features of Titanium Oval Tubing
