Home ProductsCarbon Steel Boiler Tube

ASTM A214 ASME SA214 welded Carbon Steel Boiler Tube, A178 , GR.A , GR.C , A179 , A192, A209, A210, A213

ASTM A214 ASME SA214 welded Carbon Steel Boiler Tube, A178 , GR.A , GR.C , A179 , A192, A209, A210, A213

    • ASTM A214 ASME SA214 welded Carbon Steel Boiler Tube,  A178 , GR.A , GR.C  , A179 , A192, A209, A210, A213
    • ASTM A214 ASME SA214 welded Carbon Steel Boiler Tube,  A178 , GR.A , GR.C  , A179 , A192, A209, A210, A213
    • ASTM A214 ASME SA214 welded Carbon Steel Boiler Tube,  A178 , GR.A , GR.C  , A179 , A192, A209, A210, A213
    • ASTM A214 ASME SA214 welded Carbon Steel Boiler Tube,  A178 , GR.A , GR.C  , A179 , A192, A209, A210, A213
  • ASTM A214 ASME SA214 welded Carbon Steel Boiler Tube,  A178 , GR.A , GR.C  , A179 , A192, A209, A210, A213

    Product Details:

    Place of Origin: China, India, USA, Korea, UE
    Brand Name: YUHONG SPECIAL STEEL
    Certification: ISO9001-2008, API 5L, API 5CT
    Model Number: ASTM A214 ASME SA214 ASTM A214 ASME SA214 welded Carbon Steel Boiler Tube, A178 , GR.A , GR.C , A179 , A192, A209, A210, A213

    Payment & Shipping Terms:

    Minimum Order Quantity: 5 tons
    Price: negotiable
    Packaging Details: Ply-wooden Case /Iron Case/ Bundle with plastic Cap
    Delivery Time: 10days->
    Payment Terms: T/T, L/C
    Supply Ability: 15000 tons per month
    Contact Now
    Detailed Product Description
    Standard: ASTM A214 , ASME SA214 ,BS3059, ASME SA178 ,DIN17175 Grade: Grade A, C, D, 360, 440, 243, 620-460, 622-490, S1, S2, TC1, TC2, ST35.8, ST45.8
    Type Of Tube: Staight ,Tube, U Bend Tube

    ASTM A214 ASME SA214 welded Carbon Steel Boiler Tube, ASTM A214 ASME SA214 welded Carbon Steel Boiler Tube,  A178 , GR.A , GR.C  , A179 , A192, A209, A210, A213







    Application: For high, middle, low pressure boiler and pressure purpose





    Production Standard, Grade, Steel No:

    ASTM A178 Grade A, C, D

    ASTM A179 Grade A, C, D

    ASTM A192

    ASTM A210 GradeA-1, C

    BS3059-Ⅰ 320 CFS

    BS3059-Ⅱ 360, 440, 243, 620-460, 622-490, S1, S2, TC1, TC2

    EN10216-1 P195TR1/TR2, P235TR1/TR2, P265TR1/TR2

    EN10216-2 P195GH, P235GH, P265GH, TC1, TC2

    DIN17175 ST35.8, ST45.8

    DIN1629 ST37.0, ST44.0, ST50.0

    JIS G3454 STPG370, STPG410

    JIS G3461 STB340, STB410, STB440

    GB5310 20G, 15MoG, 12CrMoG, 12Cr2MoG, 15CrMoG, 12Cr1MoVG, 12Cr2MoWVTiB

    GB9948 10, 20, 12CrMo, 15CMo

    GB3087 10, 20

    Delivery Condition:Annealed, Normalized, Normalized and Tempered

    Inspection and Test:

    Chemical Composition Inspection, Mechanical Properties Test(Tensile Strength,Yield Strength,

    Elongation, Flaring, Flattening, Bending, Hardness, Impact Test), Surface and Dimension Test,No-destructive Test, Hydrostatic Test.

    Surface treatment:

    Oil-dip, Varnish, Passivation, Phosphating, Shot Blasting



    Tube Sizes for Heat Exchangers & Condensers & Boiler

    Outside Diameter



    BWG

    25

    22

    20

    18

    16

    14

    12

    10



    Wall Thickness mm

    0.508

    0.71

    0.89

    1.24

    1.65

    2.11

    2.77

    3.40

    mm

    inch



    Weight kg/m

    6.35

    1/4

    0.081

    0.109

    0.133

    0.174

    0.212







    9.53

     3/8

    0.126

    0.157

    0.193

    0.257

    0.356

    0.429





    12.7

     1/2



    0.214

    0.263

    0.356

    0.457

    0.612

    0.754



    15.88

     5/8



    0.271

    0.334

    0.455

    0.588

    0.796

    0.995



    19.05

     3/4



    0.327

    0.405

    0.553

    0.729

    0.895

    1.236



    25.4

    1



    0.44

    0.546

    0.75

    0.981

    1.234

    1.574

    2.05

    31.75

    1 1/4



    0.554

    0.688

    0.947

    1.244

    1.574

    2.014

    2.641

    38.1

    1 1/2



    0.667

    0.832

    1.144

    1.514

    1.904

    2.454

    3.233

    44.5

    1 3/4







    1.342

    1.774

    2.244

    2.894

    3.5

    50.8

    2







    1.549

    2.034

    2.574

    3.334

    4.03

    63.5

    2 1/2







    1.949

    2.554

    3.244

    4.214

    5.13

    76.2

    3







    2.345

    3.084

    3.914

    5.094

    6.19

    88.9

    3 1/2







    2.729

    3.609

    4.584

    5.974

    7.27

    101.6

    4









    4.134

    5.254

    6.854

    8.35

    114.3

    4 1/2









    4.654

    5.924

    7.734

    9.43

    Form of Tube: Straight & U-bend & Finned & Coiled

    Stainless Steel Tube: A/SA213, A/SA249, A/SA268, A/SA269, A/SA789, EN10216-5, A/SA688, B/SB163, JIS-G3463, GOST9941-81.

    Carbon &Alloy Steel Tube: A/SA178, A/SA179, A/SA192,A/SA209, A/SA210, A/SA213, A.SA214



    ASTM A214 ASME SA214 welded Carbon Steel Boiler Tube,  A178 , GR.A , GR.C  , A179 , A192, A209, A210, A213
