Yuhong Holding Group Co.,LTD
Place of Origin: | CHINA |
Brand Name: | YUHONG |
Certification: | ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008 |
Model Number: | ASTM A270 TP304 |
Minimum Order Quantity: | 100 KGS |
---|---|
Price: | NEGOTIABLE |
Packaging Details: | Ply-wooden Case /Iron Case/ Bundle with plastic Cap |
Delivery Time: | 20-80 days |
Payment Terms: | T/T, L/C |
Supply Ability: | 1500 Tons Per Month |
Application: | Construction,Decoration,Industry | Standard: | ASTM, AISI, GB, DIN, JIS |
---|---|---|---|
Steel Grade: | 300 Series,304 304L 316 316L 310S 321 | Type: | Seamless,Welded |
Thickness: | SCH10 - XXS | Length: | 3000mm~6000mm,Customer Request,18000max. |
Outer Diameter: | 1/2"-8", Max 304.8mm | Technique: | Cold Rolled Hot Rolled,Cold Drawn,welded,seamless |
Surface: | Annealing,pickling,polishing,600 Grit Polished,Bright | Grade: | 304L 316 316L 310s 321 321H 347 347H |
Surface Finish: | Polished | Price Term: | CIF CFR FOB EX-WORK |
Packing: | Ply-wooden Case /Iron Case/ Bundle | Rectangle Pipe: | 10*20mm~30*90mm, Thickness 0.4mm~10mm |
Customized Service: | Demand Customization | Inspection: | 100% |
Diameter: | DN6 - DN400mm | Invoicing: | By Theoretical Weight |
Applications: | Construction,Industry,boiler,Chemical | Dnt: | ET,UT,PT,HT |
Outer Diameter: | 6~1200 | Material: | Stainless Steel |
High Light: | astm a270 stainless steel sanitary tubing,tp304 stainless steel sanitary tubing,astm a270m stainless steel sanitary pipe |
Yuhong is one of the famous ASTM A270 TP304 sanitary stainless steel pipe suppliers, we provide these after checking all the quality parameters by our experienced and knowledgeable staff. We stock welded and seamless stainless steel pipes in various industry standard sizes. After more than 20 years of development, we have accumulated a large number of customers all over the world, and Yuhong products have also won unanimous praise from customers.
ASTM A270 TP304 Sanitary Tubing Type | Seamless and Welded Austenitic and Ferritic/Austenitic Stainless Steel Sanitary Tubing |
ASTM A270 TP304 Sanitary Tubing OD. | 1/2”-4” |
ASTM A270 TP304 Sanitary Tubing Wall | 16 Gauge (0.065”) |
ASTM A270 TP304 Sanitary Tubing Length | 20′ |
ASTM A270 TP304 Sanitary Tubing OD Tolerance | +/-0.005” / +/-0.13MM |
ASTM A270 TP304 Sanitary Tubing WT Tolerance | +/-10% |
ASTM A270 TP304 Sanitary Tubing Length Tolerance | +1/8” / +3.18MM |
ASTM A270 TP304 Sanitary Tubing Material | SS 304, SS 304L,SS 316,SS 316L |
ASTM A270 TP304 Sanitary Tubing Standard | ASTM A270 / A270M |
ASTM A270 TP304 Sanitary Tubing Finish | 2B MIll Finish , No.4 finish, BA Finish, 400 Grit Finish, 550 Grit Finish, 600 Grit Finish |
ASTM A270 TP304 Sanitary Tubing Polish | Mechanical Polished |
ASTM A270 TP304 Sanitary Tubing Type | Seamless |
ASTM A270 TP304 Sanitary Tubing Certification | 3A – Food / Dairy Grade |
ASTM A270 TP304 Sanitary Tubing Mill Test Certificate | EN10204 3.1 |
ASTM A270 TP304 Product | ASTM A270 304 Sanitary Tubing, ASTM A270 SS304 Seamless Sanitary Tubes, ASTM A270 Type 304 Tubing, ASTM A270 TP304 Welded Sanitary Tubing, ASTM A270 304 Welded Sanitary Tubes, ASTM A270 TP304 Stainless Steel Sanitary Tubing |
ASTM A270 TP304 Sanitary Tubing Packing | Sleeved, Ends Capped, Wooden Boxe |
NB SIZES | SCH 5 | SCH 10 | SCH 40 | SCH 80 | SCH 160 |
1/8″ | √ | √ | √ | √ | |
1/4″ | √ | √ | √ | √ | |
3/8″ | √ | √ | √ | √ | |
1/2″ | √ | √ | √ | √ | √ |
3/4″ | √ | √ | √ | √ | √ |
1″ | √ | √ | √ | √ | √ |
1 1/4″ | √ | √ | √ | √ | √ |
1 1/2″ | √ | √ | √ | √ | √ |
2″ | √ | √ | √ | √ | √ |
2 1/2″ | √ | √ | √ | √ | √ |
3″ | √ | √ | √ | √ | √ |
4″ | √ | √ | √ | √ | √ |
5″ | √ | √ | √ | √ | |
6″ | √ | √ | √ | √ |
DIMENSIONAL TOLERANCE OF ASTM A270 TP304 SANITARY TUBING
Tube | SIZE OD | NOMINAL WALL THICKNESS | OUTSIDE DIAMETER TOLERANCE | LENGTH TOLERANCE | WALL THICKNESS TOLERANCE | ||||
ASTM 270 | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (%) |
ASTM 270 | ½ | 12.7 | 0.065 | 1.65 | +/-0.005 | +/-0.13 | +⅛, -0 | +3.18, -0 | +/-10.0% |
ASTM 270 | ¾ | 19.1 | 0.065 | 1.65 | +/-0.005 | +/-0.13 | +⅛, -0 | +3.18, -0 | +/-10.0% |
ASTM 270 | 1 | 25.4 | 0.065 | 1.65 | +/-0.005 | +/-0.13 | +⅛, -0 | +3.18, -0 | +/-10.0% |
ASTM 270 | 1½ | 38.1 | 0.065 | 1.65 | +/-0.008 | +/-0.20 | +⅛, -0 | +3.18, -0 | +/-10.0% |
ASTM 270 | 2 | 50.8 | 0.065 | 1.65 | +/-0.008 | +/-0.20 | +⅛, -0 | +3.18, -0 | +/-10.0% |
ASTM 270 | 2½ | 63.5 | 0.065 | 1.65 | +/-0.010 | +/-0.25 | +⅛, -0 | +3.18, -0 | +/-10.0% |
ASTM 270 | 3 | 76.2 | 0.065 | 1.65 | +/-0.010 | +/-0.25 | +⅛, -0 | +3.18, -0 | +/-10.0% |
ASTM 270 | 4 | 101.6 | 0.083 | 2.11 | +/-0.015 | +/-0.38 | +⅛, -0 | +3.18, -0 | +/-10.0% |
ASTM 270 | 6 | 152.4 | 0.109 | 2.77 | +/-0.030 | +/-0.76 | +1, -0 | +25.4, -0 | +/-10.0% |
