Yuhong Holding Group Co.,LTD
 |
| Place of Origin: | China |
| Brand Name: | Yuhong |
| Certification: | ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008 |
| Model Number: | TP405, TP409, TP410, TP420, TP430, TP439 Stainless Steel SMLS Tube |
| Minimum Order Quantity: | 1PC |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Ply-wooden Case /Iron Case/ Bundle with plastic Cap etc. |
| Delivery Time: | 5- 60 Days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 800 Tons/ month |
| Standard: | JIS, AiSi, ASTM, GB, DIN, EN | Specification: | TP405, TP409, TP410, TP420, TP430, TP439 Stainless Steel SMLS Tube |
|---|---|---|---|
| Type: | Seamless | Technique: | Cold Drawn |
| Shape: | Round, Square, Rectangle | Processing Service: | Bending, Welding, Decoiling, Punching, Cutting |
| Package: | Standard Seaworthy Package | ||
| High Light: | Martensitic Stainless Steel Pipe ASTM A268,Stainless Steel Seamless Tube TP405,Power Plants Stainless Steel Seamless Tube |
||
ASTM A268 TP405 Martensitic Stainless Steel Seamless Tube for Power Plants
We are Yuehong Group, one of the largest manufacturers of stainless steel, duplex and alloy steel pipes in China. After 33 years of development, we have accumulated a large number of customers around the world, and Yuhong products have won the praise of our customers.
Overview
ASTM A268 TP405 is a standard specification for seamless and welded ferritic and martensitic stainless steel tubing for general corrosion resistance and high temperature service. The "TP" in the name stands for "Seamless Pipe" and the "405" stands for a specific grade of stainless steel.
Composition
Chemical Composition: The composition of TP405 stainless steel typically includes chromium, manganese, silicon, sulfur, phosphorus, carbon, and iron. It is a ferritic stainless steel with good oxidation resistance.
Mechanical Properties
Tensile Requirements: The material must meet certain tensile requirements, including minimum tensile strength, yield strength and elongation. These properties ensure that the pipe has the necessary mechanical strength.
Sizes and Specifications
SIZE RANGE: ASTM A268 TP405 stainless steel seamless steel pipe is available in a variety of sizes. This standard specifies the outside diameter and wall thickness requirements for steel pipe.
Heat Treatment
HEAT TREATMENT: Steel pipe under this specification may be subjected to heat treatment processes such as annealing or solution annealing to achieve the desired properties and microstructure.
Chemical Composition
| C % | Mn % | P % | S % | Si % | Cr % | Ni % | Al % |
| 0.08 max | 1.00 max | 0.04max | 0.03 max | 1.00 max | 11.5-14.5 | 0.50 max | 0.10-0.30 |
Mechanical Properties of ASTM A268 TP405 Stainless Steel Pipes
| Tensile Strength, Mpa | Yield Strength, MPa | Elongation, % | Hardness, HB |
| 415 min | 205 min | 20 min | 207 max |
Specification
| Specifications | ASTM A268 / SA 268 |
| Dimensions | ASTM, ASME and API |
| Size | 1/4″ (6.25mm) to 8″ (203mm), WT 0.02″ (0.5mm) to 0.5″(12mm) |
| Schedule | SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS |
| Specialized in | Large Diameter Size |
| Length | Single Random, Double Random & Cut Length. |
| Form | Round, Square, Rectangular, Hydraulic Etc |
| End | Plain End, Beveled End, Treaded |
Martensitic stainless steel tube S40500 Typical Usages
