ASME SA182 F904L SO RF FLANGE DN 80 CL150 B16.5

ASME SA182 F904L SO RF FLANGE DN 80 CL150 B16.5

  • ASME SA182 F904L SO RF FLANGE  DN 80 CL150 B16.5
  • ASME SA182 F904L SO RF FLANGE  DN 80 CL150 B16.5
  • ASME SA182 F904L SO RF FLANGE  DN 80 CL150 B16.5
  • ASME SA182 F904L SO RF FLANGE  DN 80 CL150 B16.5
ASME SA182 F904L SO RF FLANGE  DN 80 CL150 B16.5
Product Details:
Place of Origin: CHINA
Brand Name: YUHONG
Certification: ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number: JIS B2220 5K ,10K, 16K , ... ASTM A182 CLASS 150, CLASS 300, CLASS 600, CLASS 1500, CLASS 3000, CLASS5000 , CLASS 10000
Payment & Shipping Terms:
Minimum Order Quantity: 100KGS
Price: Negotiable
Packaging Details: Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Delivery Time: 5-80 Days
Payment Terms: T/T, L/C
Supply Ability: 1500 tons per month
Contact Now
Detailed Product Description
Material: SUS316 , SUS316L , SUS304, SUS304L , SUS321, F51, F53, F44, F60 Standard: JIS B2220 , A182, B564
Type: SOP FF, SOH FF, BL, WN, Lap Joint Flange, Thread Flange, Sock-Weld Flange, Orifice Flange, Spectacle Flange Face Type: FF, RF, RTJ
Specification: ASTM B16.5, B16.47 Series A & B Size: 1/2" To 100"
Pressure Grade: Class 150, 300, 600, 900, 1500, 2500, 3000, 6000, 10000, 15000
High Light:

stainless steel flanges


forged steel flanges

ASME SA182 F904L SO RF FLANGE DN 80 CL150 B16.5


YUHONG SPECIAL STEEL deal with Austenitic Stainless Steel, Nickel Alloy Steel(Hastelloy , Monel, Inconel, Incoloy ) seamless and welded pipe and tube already more than 25 years, every year sell more than 80000 tons of steel pipe and tube. Our client already cover more than 45 countries, Like Italy, UK, Gernmany, USA, Canada, Chile, Colombia, Saudi Arabia, Russia, Korea, Singapore, Austrial, Poland, France , ....And our group branch company and factory have been already approved by :ABS, DNV, GL, BV, PED 97/23/EC, AD2000-WO, GOST9941-81, CCS, TS, CNNC, ISO9001-2008, ISO 14001-2004.


Plate Flanges

Plate Flanges, which are of wide variety, are manufactured mainly from plates. They are conforming to national & international standards and they are hubless. Plate flanges are produced from quality mill plates. Before cutting pieces out of plates, each plate is checked for serious laminations. They should be virtually free of voids, non-metallic inclusions and other defects. Another important property of plate is its weldability & hardenability. For more critical application of flanges, the hardness, strength and impact properties are also important factors. These properties vary through, along and across the section of the product as a result of temperature and microstructural variations during hot rolling, cold rolling or quenching and cooling

Size : 1/2"NB TO 100"NB IN

Steel Flange ,Class 50 LBS Plate Flanges, 300 LBS Plate Flanges, 600 LBS Plate Flanges, 900 LBS Plate Flanges, 1500 LBS


Plate Flanges Standard : AS A150, AS A300, TABLE D,E,F,H, DIN, ND-6,10, 16, 25, 40 Etc

Plate Flanges Type

  • Plate Blind
  • Slip On (SORF)
  • Blind (BLRF)
  • Lap Joint
  • Reducing
  • Ring Joint
  • Large Dia Ring


Plate Flanges Materials

Nickel Alloy Plate Flanges
Standard :

  • ASTM / ASME SB 162 / 127 / 424 / 168 / 443 / 574 / 462.
  • UNS 10276 -HASTELLOY C 276 Plate Flanges
  • UNS 2200- NICKEL 200 Plate Flanges
  • UNS 2201 -NICKEL 201 Plate Flanges
  • UNS 4400 - MONEL 400 Plate Flanges
  • UNS 8020 -ALLOY 20 Plate Flanges
  • UNS 8825 -INCONEL 825 Plate Flanges
  • UNS 6600 -INCONEL 600 Plate Flanges
  • UNS 6601- INCONEL 601 Plate Flanges
  • UNS 6625 -INCONEL 625 Plate Flanges

Copper Alloy Plate Flanges

  • C 70600 (CU -NI- 90/10) - Cupro Nickel Plate Flanges
  • C 71500 (CU -NI- 70/30) - Copper Nickel Plate Flanges
  • UNS NO. C 92200, UNS NO. C 83600, UNS NO. UNS NO C 10100,
  • C 10200, C 10300, C 10800, C 12000, C 12200

Duplex Steel Plate Flanges
Grade : S 31803 , S 32205.

Stainless Steel Plate Flanges - SS Plate Flanges

  • ASTM A182
  • ASTM SA 240 .
  • Grade : 304, 304L, 304H, 309S, 309H, 310S, 310H, 316, 316TI, 316H, 316L, 316LN, 317, 317L, 321, 321H, 347, 347H, 904L..

Alloy Steel Plate Flanges - AS Plate Flanges
ASTM SA 387 Grade 1/5/9/11/22/91

Carbon Steel Plate Flanges - CS Plate Flanges
ASTM A36, IS 2062

Low Temperature Carbon Steel Plate Flanges - LTCS Plate Flanges
A516 GR.70

Value Added Services for Plate Flanges

  • Hot Dip Galvanizing

Test Certificate
Mill Test Certificate as per EN 10204 / 3.1B

ASME SA182 F904L SO RF FLANGE  DN 80 CL150 B16.5 1
