ASTM A554 Stainless Steel Welded Tubing Polished Plain End TP304 / 304L TP316

Product Details:

Place of Origin:	China, India, USA, Korea, UE
Brand Name:	YUHONG SPECIAL STEEL
Certification:	ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number:	ASTM A554, TP304 , TP316L

Payment & Shipping Terms:

Minimum Order Quantity:	100KGS
Price:	negotiable
Packaging Details:	Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Delivery Time:	10days->
Payment Terms:	T/T, L/C
Supply Ability:	1500 tons per month

Contact Now

All Products

Stainless Steel Seamless Pipe (224)

Stainless Steel Seamless Tube (178)

Stainless Steel Welded Pipes (41)

Stainless Steel Welded Tube (77)

Finned Tube (204)

Heat Exchanger Tube (131)

Duplex Stainless Steel Pipes (111)

Alloy Steel Seamless Tubes (62)

Bright Annealed Tube (146)

Copper Alloy Tube (131)

Nickel Alloy Pipe (264)

Carbon Steel Pipe (50)

U Bend Tube (140)

Boiler Tube (72)

Steel Pipe Fittings (530)

Steel Flanges (374)

Steel Valves (12)

Precision Steel Strip (23)

Alloy Wires (271)

Heat Exchanger Parts (44)

Detailed Product Description

High Light:

stainless steel welded tubing

stainless steel coiled tubing

ASTM A554 Stainless Steel Welded Tubing Polished Plain End TP304 / 304L TP316

Overview
1.1 This specification covers welded stainless steel tubing for mechanical applications where appearance, mechanical properties, or corrosion resistance is needed.
1.2 This specification covers as-welded or cold-reduced mechanical tubing in sizes to 16 in. (406.4 mm) outside diameter, inclusive (for round tubing) and in wall thicknesses 0.020 in. (0.51 mm) and over.
1.3 Tubes shall be furnished in one of the following shapes as specified by the purchaser: round, square, rectangular, or special.
1.4 Supplementary requirements of an optional nature are provided and when desired shall be so stated in the order.
1.5 Values stated in inch-pound units, in accordance with the specifications, are to be regarded as the standard.

Tube Gauge for ASTM A554 Round

O.D./In.	Wall/In.	Wt./Ft.
.500	.049	.236
.625	.035	.221
.750	.065	.476
.875	.035	.314
1.000	.049	.498
1.000	.065	.649
1.000	.083	.813
1.250	.049	.629
1.250	.065	.823
1.500	.035	.548
1.500	.065	.996

O.D./In.	Wall/In.	Wt./Ft.
1.625	.065	1.083
1.750	.035	.641
1.750	.120	2.090
1.875	.049	.956
2.000	.035	.735
2.000	.049	1.021
2.000	.065	1.343
2.250	.049	1.152
2.500	.049	1.283
3.000	.065	2.030
4.000	.065	2.730

Tube Gauge for ASTM A554 Square

O.D./In.	Wall/In.	Wt./Ft.
.750 x .750	.065	.605
.750 x .750	.120	1.028
1.000 x 1.000	.049	.634
1.000 x 1.000	.065	.827
1.000 x 1.000	.083	1.035
1.000 x 1.000	.120	1.436
1.250 x 1.250	.065	1.047
1.250 x 1.250	.083	1.317
1.250 x 1.250	.120	1.844
1.500 x 1.500	.065	1.268
1.500 x 1.500	.083	1.599
1.500 x 1.500	.120	2.252
1.500 x 1.500	.180	3.230
1.750 x 1.750	.120	2.660
2.000 x 2.000	.065	1.710
2.000 x 2.000	.083	2.164
2.000 x 2.000	.120	3.050
2.000 x 2.000	.180	4.136
2.000 x 2.000	.250	5.410

O.D./In.	Wall/In.	Wt./Ft.
2.500 x 2.500	.083	2.730
2.500 x 2.500	.120	3.900
2.500 x 2.500	.180	5.352
3.000 x 3.000	.083	3.290
3.000 x 3.000	.109	4.250
3.000 x 3.000	.120	4.750
3.000 x 3.000	.180	6.578
3.000 x 3.000	.250	8.810
4.000 x 4.000	.120	6.460
4.000 x 4.000	.180	9.351
4.000 x 4.000	.250	12.210
5.000 x 5.000	.250	16.350
6.000 x 6.000	.250	19.020
6.000 x 6.000	.375	27.120
6.000 x 6.000	.500	38.123
8.000 x 8.000	.250	26.528
8.000 x 8.000	.375	39.291
8.000 x 8.000	.500	51.721

Tube Gauge for ASTM A554 Rectangular

O.D./In.	Wall/In.	Wt./Ft.
.750 x 1.500	.065	.937
1.000 x 1.500	.083	1.317
1.000 x 2.000	.065	1.270
1.000 x 2.000	.120	2.252
1.000 x 3.000	.065	1.710
1.500 x 2.500	.065	1.710
1.500 x 3.000	.120	3.480
2.000 x 3.000	.120	3.900
2.000 x 3.000	.180	5.352

O.D./In.	Wall/In.	Wt./Ft.
2.000 x 4.000	.120	4.750
2.000 x 4.000	.180	6.578
2.000 x 4.000	.250	8.810
2.000 x 5.000	.180	8.060
2.000 x 6.000	.180	9.420
2.000 x 6.000	.250	12.210
3.000 x 4.000	.120	5.610
4.000 x 6.000	.180	11.900
4.000 x 6.000	.250	15.620
4.000 x 6.000	.375	23.994
4.000 x 6.000	.500	31.324
