ASME SA213 TP304 S30400 Stainless Steel Seamless Tube For Boiler

Product Details:

Place of Origin:	CHINA
Brand Name:	YUHONG
Certification:	ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number:	ASME SA213 TP304

Payment & Shipping Terms:

Minimum Order Quantity:	500KGS
Price:	Negotiable
Packaging Details:	Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Delivery Time:	15-20DDays
Payment Terms:	L/C,T/T
Supply Ability:	1500 Tons per Month

Contact Now

All Products

Stainless Steel Seamless Pipe (290)

Stainless Steel Seamless Tube (277)

Duplex Stainless Steel Pipe (127)

Duplex Stainless Steel Tube (29)

Needle Tube (107)

Fin Tube (631)

Heat Exchanger (17)

Heat Exchanger Tube (424)

Heat Exchanger Tube Bundle (37)

Heat Exchanger Tubesheet (116)

Heat Exchanger Baffle (36)

Air Cooler (8)

Pressure Vessel (4)

Stainless Steel Welded Pipe (57)

Stainless Steel Welded Tube (114)

Nickel Alloy Pipe (261)

Nickel Alloy Tube (79)

Copper Alloy Tube (227)

Alloy Steel Tube (184)

Titanium Tube (10)

Bright Annealed Tube (153)

Boiler Tube (145)

Steel Fitting (804)

Steel Flange (590)

Others (391)

Cladding Parts (7)

Detailed Product Description

Standard:	ASME SA213	Grade:	TP304, TP304L, TP316, TP309, TP347
Type:	Seamless	Application:	Boiler
Condition:	Hot Finished, Cold Finished	Test:	Hydrostatic Test, Nondestructive Electric Test, Grain Size(ASTM E112), Flattening Test, Flaring Test
Highlight:	Boiler Stainless Steel Seamless Tube , Boiler Stainless Seamless Tube , SA213 Stainless Steel Seamless Tube

ASME SA213 TP304 S30400 Stainless Steel Seamless Tube for Boiler Applications

Yuhong Special Steel specializes in ASME SA213 TP304 (UNS S30400) stainless steel seamless tubes for boiler applications. With over 30 years in austenitic stainless steel pipe operations, we ensure quality through strict adherence to standards like ASME SA213. Our TP304 tubes offer excellent corrosion resistance and high - temperature strength, vital for boiler systems. Certified by ABS, DNV, ISO 9001 - 2008, etc., they meet global quality benchmarks. Serving over 85 countries, we provide customized solutions, from size to specification, to support safe and efficient boiler operations in power plants and industrial heating.

Chemical Composition

Grade	UNS Designation	Carbon	Manganese	Phosphorus	Sulfur	Silicon	Chromium	Nickel
TP304	S30400	0.08	2	0.045	0.03	1	18.0 - 20.0	8.0 - 11.0

Heat Treatment and Grain Size Requirements

Grade	UNS Number	Heat Treat Type	Austenitizing/Solutionizing/Stabilizing Temperature	Cooling Media
TP304	S30400	solution treatment	1900 [1040]°^F	water or other rapid cool

Equivalent specification

Region/Organization	Specification System	Grade Designation
China	GB	06Cr19Ni9
Japan	JIS	SUS 304
South Korea	KS	STS 304
USA	ASTM	304
ISO	ISO Designation	X5CrNi 18 - 10
Germany	DIN EN/DIN	X5CrNi 18 - 10 (X5CrNi 18 - 9)
France	NF EN/NF	Z6CN 18 - 09
Russia	GOST	08X18H10

Tensile and Hardness Requirements

Grade	UNS	Tensile Strength	Yield Strength	Elongation	Hardness
TP304	S30400	min, ksi[MPa]	min, ksi[MPa]	in 2 in. or 50 mm, min, %	Brinell/Vickers	Rockwell
		75[515]	30[205]	35	192 HBW	90 HRB
					200 HV

ASME SA213 TP304 S30400 Stainless Steel Seamless Tube for Boiler Applications
ASME SA213 TP304 (UNS S30400) stainless steel seamless tubes are essential for boiler applications, valued for their material properties and standard compliance:

Corrosion & High - Temp Resistance:TP304 resists oxidation and pitting in high - pressure, high - temp boiler environments, ensuring long - term reliability and preventing leakage. Its high - temp strength maintains structural integrity during steam generation and heat exchange.
ASME SA213 Compliance:Manufactured to strict ASME SA213 standards, these tubes meet rigorous quality requirements for pressure - bearing boiler components, from material control to testing.
Operational Efficiency:As heat transfer carriers, they enable efficient steam generation and withstand thermal cycling stresses, supporting safe, long - cycle boiler operation in power plants and industrial heating.
