Incoloy Pipe , B163/ B423 /B407 Incoloy 800/ 800H/800HT/825 /925/926 Solid and Hot Finished , 8" SCH40S 6M

Incoloy Pipe , B163/ B423 /B407 Incoloy 800/ 800H/800HT/825 /925/926 Solid and Hot Finished , 8" SCH40S 6M

  • Incoloy Pipe , B163/ B423 /B407 Incoloy 800/ 800H/800HT/825 /925/926 Solid and Hot Finished , 8" SCH40S 6M
  • Incoloy Pipe , B163/ B423 /B407 Incoloy 800/ 800H/800HT/825 /925/926 Solid and Hot Finished , 8" SCH40S 6M
  • Incoloy Pipe , B163/ B423 /B407 Incoloy 800/ 800H/800HT/825 /925/926 Solid and Hot Finished , 8" SCH40S 6M
  • Incoloy Pipe , B163/ B423 /B407 Incoloy 800/ 800H/800HT/825 /925/926 Solid and Hot Finished , 8" SCH40S 6M
  • Incoloy Pipe , B163/ B423 /B407 Incoloy 800/ 800H/800HT/825 /925/926 Solid and Hot Finished , 8" SCH40S 6M
Incoloy Pipe , B163/ B423 /B407 Incoloy 800/ 800H/800HT/825 /925/926 Solid and Hot Finished , 8" SCH40S 6M
Product Details:
Place of Origin: China, USA, Korea, UE
Brand Name: YUHONG
Certification: ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number: B163/ B423 /B407 Incoloy 800/ 800H/800HT/825 /925/926
Payment & Shipping Terms:
Minimum Order Quantity: 100KGS
Price: negotiable
Packaging Details: Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Delivery Time: 10days->
Payment Terms: T/T, L/C
Supply Ability: 1500 tons per month
Contact Now
Detailed Product Description
Material: Incoloy 800/ 800H/800HT/825 /925/926 Standard: B163/ B423 /B407
NDT: 100% ET/ UT/ HT Type: Seamless & Welded
High Light:

nickel alloy tube

,

inconel tube

Incoloy Pipe , B163/ B423 /B407 Incoloy 800/ 800H/800HT/825 /925/926 Solid and Hot Finished , 8" SCH40S 6M



YUHONG GROUP deal with Stainless/Duplex/ Nickel steel seamless pipe and tube already more than 10 years, every year sell more than 80000 tons of Stainless/Duplex/ Nickel steel seamless pipe and tube. Our client already cover more than 45 countries. Our stainless steel seamless pipe and tube was width used in Mining, Energy, Petrochemical, Chemical Industry, Food plant, Paper plant, Gas and Fluid Industry etc. ANSI B16.10: B16.19 SCH 5S, SCH 10S, SCH 20, SCH 30, SCH 40S, SCH 60, SCH80S, XS, SCH 100, SCH 120, SCH160, XXS



Incoloy Alloy 800H/800HT/800AT

 Incoloy 800, Alloy 800, Ferrochronin 800, Nickelvac 800, Nicrofer 3220.

Common Trade Names: Incoloy 800H/800HT/800AT, Alloy 800H/800HT/800AT, Ferrochronin 800H/800HT/800AT, Nickelvac 800H/800HT/800AT, Nicrofer 3220.


INCOLOY alloy 800H/800HT/800AT is designated as UNS N08810, UNS N08811 and Werkstoff Number 1.4876, 1.4958, 1.4959. It is

listed in NACE MR0175 for oil and gas service.

Nickel-iron-chromium alloys having the same basic composition as INCOLOY alloy 800

but with significantly higher creep-rupture strength. The higher strength results from close control of the carbon, aluminum,

and titanium contents in conjunction with a high-temperature anneal. Used in chemical and petrochemical

processing, in power plants for super-heater and reheater tubing, in industrial furnaces, and for heattreating equipment.



Specifications

INCOLOY alloy 800H/800HT/800AT is designated as UNS N08810, UNS N08811 and Werkstoff Number 1.4876, 1.4958, 1.4959. It is

listed in NACE MR0175 for oil and gas service.

Rod, Bar, Wire, Forgings, and Forging Stock: ASTM B 408, ASME SB 408 (Rod & Bar), ASTM B 564,

ASME SB 564 (Forgings), ASME Code Case 1325 (All Product Forms), ASME Code Case 1949 (Forgings),

 AMS 5766 (Rod & Bar), ISO 9723 (Rod & Bar), ISO 9724 (Wire), ISO 9725 (Forgings), BS 3076NA15 (

Rod & Bar), BS 3075NA15 (Wire), VdTÜV 412 (All Products).

Plate, Sheet, and Strip: ASTM A 240, ASTM A 480, ASME SA 240, ASME SA 480 (Plate, Sheet, and Strip),

 ASTM B 409, ASTM B 906, ASME SB 409, ASME SB 906 (Plate, Sheet, and Strip), ASME Code Case

1325 (All Product Forms), ASME Code Case 2339 (Plate), AMS 5871 (Plate, Sheet, and Strip), BS

3072NA15 (Plate & Sheet), BS 3073NA15 (Strip), VdTÜV 412 (All Products), ISO 6208 (plate, sheet and

strip).

Pipe and Tubes: ASTM B 163 & ASME SB 163 (Seamless Condenser & Heat Exchanger Tubes), ASTM B

407, ASTM B 829, ASME SB 407, ASME SB 829 (Seamless Pipe & Tubes), ASTM B 514, ASTM B 775,

ASME SB 514, ASME SB 775 (Welded Pipe), ASTM B 515, ASTM B 751, ASME SB 515, ASME SB 751

(Welded Tubes), ASME Code Case 1325 (All Product Forms), ASME N-20 (Cold Worked Seamless

Condenser and Heat Exchanger Tubes for Nuclear Service), BS 3074NA15 (Seamless Pipe & Tubes),

VdTÜV 412 (All Products), ISO 6207 (Seamless Tubing).

Other Product Forms:  ASTM B 366 & ASME SB 366 (Fittings)



Chemical Composition



UNS Designation

N08800

N08810

N08811

Incoloy Alloys

800

800H

800HT

Nickel

30.0 - 35.0

30.0 - 35.0

30.0 - 35.0

Chromium

19.0 - 23.0

19.0 - 23.0

19.0 - 23.0

Iron

39.5 min.

39.5 min

39.5 min.

Carbon

0.10 max

0.05 - 0.10

0.06 - 0.10

Aluminum

0.15 - 0.60

0.15 - 0.60

0.25 - 0.60

Titanium

0.15 - 0.60

0.15 - 0.60

0.25 - 0.60

Aluminum +

Titanium

0.30 - 1.20

0.30 - 1.20

0.85 - 1.20

ASTM Grain Size

Not Specified

5 or Coarser

5 or Coaser



INCOLOY 800 / 800H / 800HT SEAMLESS TUBES
UNS No: UNS N08800
Werkstoff Nr: 1.4876

Common Trade Names: Incoloy 800, Ferrochronin 800, Nickelvac 800, Nicrofer 3220

The above names are trade names and/or trademarks of specific manufactures including Special Metal Corporation. Prosaic Steel & Alloy is not affiliated with any manufacturer(s). Orders will be filled to meet specifications from any available source(s). Names are listed solely for reference to help identify products consistent with listed specifications
Specifications  Incoloy 800 / 800H / 800HT Tubes -UNS N08800

Product Range -Seamless tubes 6 mm OD x 0.7 mm to 50.8 mm OD x 3 mm thk.
Specifications- B 163 / B 407.
Finish Conditions- Cold Drawn Solution Annealed & Pickled / Cold Drawn Bright annealed / NACE MRO 175

Incoloy Pipe , B163/ B423 /B407 Incoloy 800/ 800H/800HT/825 /925/926 Solid and Hot Finished , 8" SCH40S 6M 0



Incoloy alloy 800 is a widely used material of construction for equipment that must have high strength and resist carburization,oxidation and other harmful effects of high-temperature exposure. (For high temperature applications requiring optimum rupture and creep properties, Incoloy alloys 800H and 800HT are used). The chromium in the alloy imparts resistance to oxidation and corrosion. The high percentage of nickel maintains an austenitic structure so that the alloy is ductile. the nickel content also contributes general corrosion, resistance to scaling and stress-corrosion cracking.
Incoloy alloy 800 is used in a variety of applications involving exposure to high temperatures and corrosive environments. It is used for heat-treating equipment such as baskets, trays and fixtures. In chemical and petrochemical processing the alloy is used for heat exchangers and other piping systems in nitric acid media especially where resistance to chloride stress-corrosion cracking is required. In nuclear power plants, it is used for steam-generator tubing. The alloy is often used in home appliances for sheathing of electric heating elements. In the production of paper pulp, digester liquid heaters are often made of alloy 800. In petroleum processing , the alloy is used for heat exchangers that air-cool the process stream.
Incoloy 800 is a nickel-chromium alloy with good strength and excellent resistance to oxidation and carburization. The alloy maintains stable structure during exposure to high temperature, therefore incoloy 800 has good  corrosion resistance  to many acidic environments.



Chemical Analysis of ALLOY 800 UNS (N08800)

C

MN

P

S

Si

Cr

Ni

Mo

Cu

Co

Cb+Ta

Ti

Al

Fe

Al + Ti

Grain

.10 max



19.0 - 23.0

30.0-35.0



0.15 - 0.60

0.15 -0.60

39.5 min

3.15 4.15



Incoloy Pipe , B163/ B423 /B407 Incoloy 800/ 800H/800HT/825 /925/926 Solid and Hot Finished , 8" SCH40S 6M 1
