ASTM A213 TP304 316 321 Polished Stainless Steel Seamless Tube for Heat Exchanger

Product Details:

Place of Origin:	CHINA
Brand Name:	YUHONG
Certification:	ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number:	ASTM A213 TP304

Payment & Shipping Terms:

Minimum Order Quantity:	100 KGS
Price:	NEGOTIABLE
Packaging Details:	Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Delivery Time:	20-80 days
Payment Terms:	T/T,L/C
Supply Ability:	1500 Tons Per Month

Contact Now

All Products

Stainless Steel Seamless Pipe (308)

Stainless Steel Seamless Tube (297)

Duplex Stainless Steel Pipe (132)

Duplex Stainless Steel Tube (33)

Needle Tube (134)

Fin Tube (672)

Heat Exchanger (20)

Heat Exchanger Tube (443)

Heat Exchanger Tube Bundle (40)

Heat Exchanger Tubesheet (117)

Heat Exchanger Baffle (37)

Air Cooler (9)

Pressure Vessel (4)

Stainless Steel Welded Pipe (58)

Stainless Steel Welded Tube (120)

Nickel Alloy Pipe (266)

Nickel Alloy Tube (92)

Copper Alloy Tube (240)

Alloy Steel Tube (204)

Titanium Tube (15)

Bright Annealed Tube (155)

Boiler Tube (151)

Steel Fitting (826)

Steel Flange (615)

Others (401)

Cladding Parts (7)

Detailed Product Description

Steel Grade:	300 Series, Stainless Steel 304/316L, 400 Series, X5CrNi18-20, 200 Series	Type:	Seamless, Welded, Round Pipe/Tube
Standard:	ASTM, AISI, GB, DIN, JIS	Certification:	ISO, SGS, BV, ISO & SGS, ISO/CE/SGS
Length:	3000mm-6000mm, 6 Meters Or Customized, 18000max., 11.8m Or As Required., 8m	Thickness:	0.4-30mm, 1.0mm, 0.6mm-2500mm, 1mm-60mm, 0.6-25 Mm
Technique:	Cold Rolled Hot Rolled, Cold Drawn, Extrusion, Cold Drawn/Cold Rolling Or Both Of Them	Product Name:	Stainless Steel Pipe, 304 304L 316 316L 321 310S Stainless Steel Welded/Seamless Tube, Factory Direct Sales Stainless Steel Pipe For Electric Heating Element, Seamless Stainless Steel Pipe/Tube
Outer Diameter:	6-630mm, Customized, 6-762mm, 6-860mm;, 6mm-630mm	Surface:	Annealing, 8K, Polishing Or Unpolishing, Morror/Satin
Finish:	Brush Polish, Cold Drawn, Pickled, Bright Annealed Or Un Annealed, Bright	Material:	Stainless Steel
Shape:	Seamless Tube
Highlight:	polished boiled stainless steel seamless tube , tp 304 stainless steel seamless tube , 321 stainless steel heat exchanger tubes

ASTM A213 TP304 316 321 Stainless Steel Seamless Tube Polished For Heat Exchanger

Yuhong Special Steel has over 25 years of experience in manufacturing seamless and welded pipes of austenitic stainless steel and nickel alloy steel (Hastelloy, Monel, Inconel). With annual sales exceeding 80,000 tons of steel pipes and pipelines, we serve customers in over 55 countries worldwide including USA, Canada, UK, Germany, Italy, Chile, Colombia, Saudi Arabia, South Korea, Singapore, Australia, Poland, and France.

Standard Specifications

ASTM A213/A213M-11a: Seamless Ferritic and Austenitic Alloy Steel Boiler, Superheater, and Heat Exchanger Tubes
ASTM A269-10: General Purpose Seamless and Welded Austenitic Stainless Steel Pipe
ASTM A312/A312M-12: Seamless, Welded, and Recold-Worked Austenitic Stainless Steel Pipe
ASTM A511/A511M-12: Seamless Stainless Steel Mechanical Tubing
ASTM A789/A789M-10a: General Purpose Seamless and Welded Ferritic/Austenitic Stainless Steel Pipe
ASTM A790/A790M-11: Seamless and Welded Ferritic/Austenitic Stainless Steel Pipe
DIN 17456-2010: Seamless round stainless steel tubes for general purpose
DIN 17458-2010: Seamless round austenitic stainless steel tubes
EN10216-5 CT 1/2: Stainless Steel Seamless Pipe
GOST 9941-81: Seamless cold-worked and warm-worked tubes made of corrosion-resistant steel
Other standards including BS and JIS available

Stainless Steel Grade Information

What is SS 304?

Type 304 stainless steel is a T 300 series austenitic stainless steel containing a minimum of 18% chromium and 8% nickel, with maximum 0.08% carbon. Defined as a chromium-nickel austenitic alloy, Grade 304 is the standard "18/8" stainless steel commonly used in pans and cooking tools.

Difference Between SS316 and SS304

The primary difference is chemical composition: SS316 contains 2-3% molybdenum by weight, while SS304 has only trace amounts. This higher molybdenum content provides superior corrosion resistance in grade 316.

SS304 Quality Assessment

Both 304 and 316 stainless steels are durable with excellent corrosion and rust resistance. SS304 is the most versatile and widely used austenitic stainless steel globally due to its exceptional corrosion resistance properties.

Identifying SS304

For spot checking, conduct a spark test using a grinder. SS304 produces reddish orange sparks that are thin and don't travel far, while SS202 generates yellow, thick sparks that fly further distances.

A312 TP304 Chemical Composition

SS GRADE	304	304N	304LN
Ni	8 - 11	8 - 11	8 - 11
Fe	Balance
Cr	18 - 20	18 - 20	18 - 20
C	0.08 max	0.08 max	0.035 max
Si	0.75 max	0.75 max	0.75 max
Mn	2 max	2 max	2 max
P	0.040 max	0.040 max	0.040 max
S	0.030 max	0.030 max	0.030 max
N		0.10 - 0.16	0.10 - 0.16

A312 TP304 Mechanical Properties

Property	Value
Rockwell B (HR B) maximum	92
Brinell (HB) maximum	201
Tensile Strength minimum (MPa)	515
Yield Strength 0.2% Proof minimum (MPa)	205
Elongation minimum (% in 50mm)	40

SA 312 TP 304 Equivalent Standards

Standard	Country/Region	Equivalent
UNS	USA	S30400
EN	EUROPE	X5CrNi18-10
JIS	JAPAN	SUS 304
AFNOR	GOST	Z7CN18‐09
BS	BRITISH	304S31
WERKSTOFF NR.	GERMAN	1.4301
GOST		08Х18Н10
SS	SWEDISH	2332

Applications for 304 Stainless Steel

Auto moldings and trim
Wheel covers
Storage tanks
Kitchen equipment/appliances
Electrical enclosures

As one of China's largest stainless steel, duplex and alloy steel pipe manufacturers, Yuhong has developed over 20 years of industry expertise, accumulating a global customer base and earning consistent praise for product quality and reliability.
