| Place of Origin: | CHINA |
| Brand Name: | YUHONG |
| Model Number: | ASTM A213 TP304 |
| Minimum Order Quantity: | 100 KGS |
|---|---|
| Price: | NEGOTIABLE |
| Packaging Details: | Ply-wooden Case /Iron Case/ Bundle with plastic Cap |
| Delivery Time: | 20-80 days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 1500 Tons Per Month |
| Certification: | ISO, SGS, BV, ISO & SGS, ISO/CE/SGS | Stock: | Always In Good Stock |
|---|---|---|---|
| Steel Grade: | 300 Series, Stainless Steel 304/316L, 400 Series, X5CrNi18-20, 200 Series | Type: | Seamless, Welded, Round Pipe/Tube |
| Standard: | ASTM, AISI, GB, DIN, JIS | Length: | 3000mm-6000mm, 6 Meters Or Customized, 18000max., 11.8m Or As Required., 8m |
| Thickness: | 0.4-30mm, 1.0mm, 0.6mm-2500mm, 1mm-60mm, 0.6-25 Mm | Technique: | Cold Rolled Hot Rolled, Cold Drawn, Extrusion, Cold Drawn/Cold Rolling Or Both Of Them |
| Product Name: | Stainless Steel Pipe, 304 304L 316 316L 321 310S Stainless Steel Welded/Seamless Tube, Factory Direct Sales Stainless Steel Pipe For Electric Heating Element, Seamless Stainless Steel Pipe/Tube | Outer Diameter: | 6-630mm, Customized, 6-762mm, 6-860mm;, 6mm-630mm |
| Surface: | Annealing, 8K, Polishing Or Unpolishing, Morror/Satin | Finish: | Brush Polish, Cold Drawn, Pickled, Bright Annealed Or Un Annealed, Bright |
| Color: | Customerized | Company Type: | Factory And Trading |
| Corrosion Resistance: | High | Customized Service: | Demand Customization |
| Delivery Condition: | Annealed | Grade: | 304,304L,310S,316L,321,904L,S32760.etc |
| Ndt: | ET, UT, HT | Section Shape: | Round |
| Shape: | Round | Size: | Customizable |
| Third Party Inspection: | BV,SGS,ASP | Treatment: | Cold Rolled / Cold Drawn |
| Type Of Tube: | Bright Annealed Tube | ||
| High Light: | High Pressure Stainless Steel Seamless Tube,Ss Seamless Pipe Corrosion Resistance,TP304 Seamless Stainless Steel Pipe |
||
Yuhong Group is one of the large manufacturers of high quality ASTM A213 / ASME SA213 TP 304/304L pipes. ASTM A213 seamless tubes are mainly used as superheater, boiler, heat exchanger tubes. ASME SA213 TP304 pipe is made from austenitic grades with the addition of 2% to 3% molybdenum to further improve corrosion resistance. ASTM A213 TP304 Tubing Sizes and Thicknesses are typically supplied to their specifications from 1/8 in. [3.2 mm] ID to 5 in. [127 mm] OD with a minimum wall thickness of 0.015 to 0.500 in. [0.4 to 12.7 mm] (inclusive) thickness . ASTM A213 UNS S30400 pipe in other diameters may be supplied provided that such pipe meets all other requirements of this specification.
ASTM A213 TP304 Stainless Steel Seamless Pipes are manufactured in a seamless process for use in high pressure environments, stainless steel TP304 grade is the most commonly used material because of its high strength and excellent corrosion resistance.
The main manufacturing process of ASTM A213 TP 304 seamless pipe includes cold rolling, cold drawing, heat treatment and pickling. The manufacturing of seamless pipe shall be in accordance with ASTM A213 specification and the product shall be analyzed according to the test and inspection certificate.
Material Grade:
| Grade | UNS Designation | Carbon | Manganese | Phosphorus | Sulfur | Silicon | Chromium | Nickel | Molybdenum | Nitrogen | Niobium | Titanium | Other Elements |
| TP304 | S30400 | 0.08 | 2.00 | 0.045 | 0.030 | 1.00 | 16.0-20.0 | 8.0-11.0 | -- | -- | -- | -- | -- |
| American Standard |
Austenitic Steel: TP304, TP304L, TP304H, TP304N, TP310S, TP316, TP316L, TP316Ti, TP316H, TP317, TP317L, TP321, TP321H, TP347, TP347H, 904L… Duplex Steel : S31803, S32101, S32205, S32304, S32750, S32760 Others: TP405, TP409, TP410, TP430, TP439,... |
| Europen Standard | 1.4162, 1.4301, 1.4307,1.4362, 1.4401, 1.4404, 1.4410, 1.4438, 1.4462, 1.4501, 1.4539, 1.4541, 1.4550, 1.4571, 1.4841, 1.4845,1.4878, 1.4948, |
| GOST Standard | 08Х17Т, 08Х13, 12Х13, 12Х17, 15Х25Т, 04Х18Н10, 08Х20Н14С2, 08Х18Н12Б, 10Х17Н13М2Т, 10Х23Н18, 08Х18Н10, 08Х18Н10Т, 08Х18Н12Т, 08Х17Н15М3Т, 12Х18Н10Т, 12Х18Н12Т, 12Х18Н9, 17Х18Н9, 08Х22Н6Т, 06ХН28МДТ |
| Grade | Tensile Strength (MPa) min | Elongation (% in 50mm) min | Yield Strength 0.2% Proof (MPa) min | Hardness | |
| Rockwell B (HR B) max | Brinell (HB) max | ||||
| SS 304 | 515 | 40 | 205 | 92 | 201 |
Size Range:
| Production | Outside Diameter | Wall Thickness |
| Seamless Pipe | 6.00mm-830mm | 0.5mm-48mm |
The tubing sizes and thicknesses usually furnished to this specification are 1⁄8 in. [3.2 mm] in inside diameter to 5 in. [127 mm] in outside diameter and 0.015 to 0.500 in. [0.4 to 12.7 mm], inclusive, in minimum wall thickness or, if specified in the order, average wall thickness. Tubing having other diameters may be furnished, provided such tubes comply with all other requirements of this specification.
