ASTM A312 TP347 High Frequency Welded Spiral Serrated Fin Tubes For Convection Tube Coils

ASTM A312 TP347 High Frequency Welded Spiral Serrated Fin Tubes For Convection Tube Coils

  • ASTM A312 TP347 High Frequency Welded Spiral Serrated Fin Tubes For Convection Tube Coils
  • ASTM A312 TP347 High Frequency Welded Spiral Serrated Fin Tubes For Convection Tube Coils
  • ASTM A312 TP347 High Frequency Welded Spiral Serrated Fin Tubes For Convection Tube Coils
  • ASTM A312 TP347 High Frequency Welded Spiral Serrated Fin Tubes For Convection Tube Coils
ASTM A312 TP347 High Frequency Welded Spiral Serrated Fin Tubes For Convection Tube Coils
Product Details:
Place of Origin: China
Brand Name: YUHONG
Certification: ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2015
Model Number: TP304, TP304L, TP316, TP316L, TP321, TP347, TP347H
Payment & Shipping Terms:
Minimum Order Quantity: 500 KGS
Price: Negotiable
Packaging Details: Plywooden Case /Iron Case With Plastic Cap
Delivery Time: 30 - 60 work days
Payment Terms: T/T, L/C
Supply Ability: According To Customers' Request
Contact Now
All Products
Stainless Steel Seamless Pipe (277)
Stainless Steel Seamless Tube (269)
Duplex Stainless Steel Pipe (128)
Duplex Stainless Steel Tube (27)
Needle Tube (86)
Fin Tube (596)
Heat Exchanger (10)
Heat Exchanger Tube (419)
Heat Exchanger Tube Bundle (37)
Heat Exchanger Tubesheet (117)
Heat Exchanger Baffle (35)
Air Cooler (7)
Pressure Vessel (2)
Stainless Steel Welded Pipe (57)
Stainless Steel Welded Tube (113)
Nickel Alloy Pipe (258)
Nickel Alloy Tube (75)
Copper Alloy Tube (210)
Alloy Steel Tube (173)
Titanium Tube (9)
Bright Annealed Tube (153)
Boiler Tube (138)
Steel Fitting (784)
Steel Flange (574)
Others (384)
Detailed Product Description
Tube Standard: ASTM A312, ASME SA312 Tube Material Grades: TP304, TP304L, TP316, TP316L, TP321, TP347, TP347H
Fin Material: Carbon Steel, Stainless Steel, Alloy Steel Type: HFW Serrated Fin Tube
Fin Pitch: 2-14mm Fin Height: Up To 40 Mm
Tube Length: 18 Meters Max Applications: Heater Parts,Refrigeration Parts,heat Exchanger,Cooler,Fluid Cooling
Highlight:

Welded Spiral Serrated Fin Tubes

,

TP347 Heat Exchanger Tubes

,

High Frequency Serrated Fin Tubes

ASTM A312 TP347 High Frequency Welded Spiral Serrated Fin Tubes For Convection Tube Coils



High Frequency Welded Serrated Fin Tubes is a spiral fin tube formed by welding the steel strip on the base tube surface with high frequency welding technique, And the fin strip is serrated before welding. The High Frequency Welded Serrated Fin Tube is one kind of tubular type of efficient heat transfer elements which has serrated fins. Our YUHONG GROUP has more than 30 years’ manufacturing experience of fin tubes and our high-quality fin tubes have been exported to more than 60 countries.



Equivalent Grades:

STANDARD UNS WERKSTOFF NR. EN
SS 347 S34700 1.4550 X6CrNiNb18-10



Specifications:

Tube Specifications ASTM A 312, ASME SA 312
Tube Grade TP347
Tube O.D 1/2” – 48”
Wall Thickness SCH10 - SCHXXS
Tube Length As Client Request
End Beveled End, Plain End, Treaded
Fin Material Carbon Steel / Stainless Steel / Alloy Steel
Fin Type HFW Serrated Fin Tubes
Fin Thickess 0 - 10mm
Fin Height 0 - 20mm
Fin Pitch As Client Request



Composition Analysis:

ASTM A312 Mn Si C Ni P S Cr Mo
TP347 min. - - - 9 - - 17 2
max. 2 1 0.08 13 0.045 0.03 20 3



Mechanical Properties:

Elongation min (% in 50mm) 40
Yield Strength 0.2% Proof min (MPa) 205
Tensile strength ( MPa ),min 515
Hardness Rockwell B (HR B) max 95



Applications:

  • Power Plants
  • Heat Recovery Steam Generators
  • Petrochemical Industries
  • Marine Applications
  • Refrigeration Applications
  • Economizers
  • Oil and Gas Coolers
  • Plumbing and Air Conditioning
  • Condensers and Evaporators
  • Shell and Tube Heat Exchangers



ASTM A312 TP347 High Frequency Welded Spiral Serrated Fin Tubes For Convection Tube Coils 0
