ASME SB407 N08811 Nickel Iron Chromium Alloy Seamless Tube ABS Approved

Product Details:

Place of Origin:	CHINA
Brand Name:	YUHONG
Certification:	ABS Approved
Model Number:	ASME SB407

Payment & Shipping Terms:

Minimum Order Quantity:	500kgs
Price:	Negotiable
Packaging Details:	Ply-wooden Case /Iron Case/ Bundle with plastic Cap etc.
Delivery Time:	7DAYS
Payment Terms:	L/C, T/T
Supply Ability:	800 Tons/ Month

Contact Now

All Products

Stainless Steel Seamless Pipe (277)

Stainless Steel Seamless Tube (269)

Duplex Stainless Steel Pipe (128)

Duplex Stainless Steel Tube (27)

Needle Tube (86)

Fin Tube (596)

Heat Exchanger (10)

Heat Exchanger Tube (419)

Heat Exchanger Tube Bundle (37)

Heat Exchanger Tubesheet (117)

Heat Exchanger Baffle (35)

Air Cooler (7)

Pressure Vessel (2)

Stainless Steel Welded Pipe (57)

Stainless Steel Welded Tube (113)

Nickel Alloy Pipe (258)

Nickel Alloy Tube (75)

Copper Alloy Tube (210)

Alloy Steel Tube (173)

Titanium Tube (9)

Bright Annealed Tube (153)

Boiler Tube (138)

Steel Fitting (784)

Steel Flange (574)

Others (384)

Detailed Product Description

Product Name:	Nickel Iron Chromium Alloy Seamless Tube	OD:	3.00 - 219.10 Mm
Thickness:	0.40 - 12.70 Mm	Material Grade:	UNS N08811, Incoloy 800HT, DIN1.4958
End:	Beveled Ends(BE)	Test Report:	Chemical Analysis, Mechanical Properties, Grain Size, Hydrostatic Test
Highlight:	800HT NICKEL ALLOY SEAMLESS TUBE , ABS APPROVED NICKEL ALLOY SEAMLESS TUBE , N08811 NICKEL ALLOY SEAMLESS TUBE

ASME SB407 N08811 Nickel Iron Chromium Alloy Seamless Tube ABS Approved

The mechanical properties of Incoloy 800/800HT alloys are combined with their resistance to corrosion at elevated temperatures, making them extremely suitable for use in various high-temperature and long-term operations.

These alloys are also largely used in various corrosive media. The chemical composition limits of Incoloy 800H and 800HT alloys are within the limits of INCOLOY 800. Alloy 800 has high mechanical strength at high temperatures. It is suitable for use at temperatures up to 1500oF.

The important difference between Incoloy alloy series depends on the difference in their mechanical properties.

The difference in mechanical properties is due to the difference in their chemical composition and different annealing temperatures. In general, Incoloy 800 alloy has higher mechanical properties at room temperatures and minimal to high temperatures. On the other hand, Incoloy 800H and 800HT alloys offer high resistance to creep and stress cracking at higher temperatures.

ASME SB407 N08811 Nickel Iron Chromium Alloy Seamless Tube Chemical Composition

Alloy	%	Ni	Cr	Fe	C	Mn	Si	Cu	S	Al	Ti
UNS N08800	Min.	30	19							0.15	0.15
–	Max.	35	23	balance	0.1	1.5	1	0.75	0.015	0.6	0.6
UNS N08810	Min.	30	19		0.05					0.15	0.15
–	Max.	35	23	balance	0.1	1.5	1	0.75	0.015	0.6	0.6
UNS N08811	Min.	30	19		0.06					0.15	0.15
–	Max.	35	23	balance	0.1	1.5	1	0.75	0.015	0.6	0.6

ASME SB407 N08811 Nickel Iron Chromium Alloy Seamless Tube Specification

Rod, Bar, Wire, Forgings, and Forging Stock

ASTM B 408 / ASME SB 408: Nickel-Iron-Chromium Alloy Rod & Bar
ASTM B 564 / ASME SB 564: Nickel-Based Alloy Forgings
ASME Code Case 1325: Applies to all product forms of nickel-based alloys
ASME Code Case 1949: Nickel-Based Alloy Forgings
AMS 5766: Nickel-Based Superalloy Rod & Bar
ISO 9723: Nickel-Based Alloy Rod & Bar.
ISO 9724: Nickel-Based Alloy Wire.
ISO 9725: Nickel-Based Alloy Forgings.

Plate, Sheet, and Strip

ASTM B 409 / ASME SB 409: Nickel-Iron-Chromium Alloy Plate & Strip
ASTM B 906 / ASME SB 906: Nickel-Based Alloy Plate & Strip
ASME Code Case 1325: Applies to all product forms of nickel-based alloys.
ASME Code Case 2339: Nickel-Based Alloy Plate
AMS 5871: Nickel-Based Superalloy Sheet & Strip
ISO 6208: Nickel-Based Alloy Plate, Sheet, and Strip.

Pipe and Tubes

ASTM B 163 / ASME SB 163: Nickel-Based Alloy Seamless Condenser & Heat-Exchanger Tubes
ASTM B 407 / ASME SB 407: Nickel-Chromium Alloy Seamless Pipe & Tubes
ASTM B 829 / ASME SB 829: Nickel-Based Alloy Seamless Pipe & Tubes.
ASTM B 514 / ASME SB 514: Nickel-Based Alloy Welded Pipe
ASTM B 775 / ASME SB 775: Nickel-Based Alloy Welded Pipe.
ASTM B 515 / ASME SB 515: Nickel-Based Alloy Welded Tubes.
ASTM B 751 / ASME SB 751: Nickel-Based Alloy Welded Tubes.
ASME Code Case 1325: Applies to all product forms of nickel-based alloys.
ISO 6207: Nickel-Based Alloy Seamless Tubing.

ASME SB407 N08811 Nickel Iron Chromium Alloy Seamless Tube Mechanical Properties

Alloy	Density	Tensile Stress	Yield Stress (0.2%Offset)	Elongation
Inconel 800HT Tube	7.94 g/cm3	Psi - 65,000 , MPa - 450	Psi - 25,000 , MPa -	30 %

ASME SB407 N08811 Nickel Iron Chromium Alloy Seamless Tube Equivalent

NICKEL ALLOY	DIN	UNS	JIS	BS	GOST	AFNOR	EN	OR
Incoloy 800HT	1.4958	N08811	NCF 800HT	NA 15(HT)	ЭИ670	-	X8NiCrAlTi32-21	XH32T

What forms of Incoloy® 800H/HT do we offer?

Sheets
Plates
Bars
Pipe and tubing (welded and seamless)
Pipe fittings (i.e., flanges, slip-on sleeves, shutters, butt weld necks, lap joints, long weld necks, socket welds, elbows, tees, short pipe ends, returns, caps, crosses, reducers, and fittings)
