ASTM A335 Grade 1¼Cr-½Mo P11 Alloy Steel Seamless Pipe for API Standard 560 Fired Heater

Product Details:

Place of Origin:	CHINA
Brand Name:	YUHONG
Certification:	ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number:	P11, 1 1/4Cr-1/2Mo

Payment & Shipping Terms:

Minimum Order Quantity:	1000KG
Price:	Negotiation
Packaging Details:	According to client requirements/wooden case packing
Delivery Time:	30 days
Payment Terms:	T/T, L/C at sight
Supply Ability:	500 tons per month

Contact Now

All Products

Stainless Steel Seamless Pipe (286)

Stainless Steel Seamless Tube (275)

Duplex Stainless Steel Pipe (127)

Duplex Stainless Steel Tube (28)

Needle Tube (102)

Fin Tube (619)

Heat Exchanger (16)

Heat Exchanger Tube (425)

Heat Exchanger Tube Bundle (37)

Heat Exchanger Tubesheet (116)

Heat Exchanger Baffle (36)

Air Cooler (8)

Pressure Vessel (4)

Stainless Steel Welded Pipe (57)

Stainless Steel Welded Tube (112)

Nickel Alloy Pipe (259)

Nickel Alloy Tube (78)

Copper Alloy Tube (222)

Alloy Steel Tube (182)

Titanium Tube (10)

Bright Annealed Tube (153)

Boiler Tube (141)

Steel Fitting (797)

Steel Flange (583)

Others (388)

Cladding Parts (7)

Detailed Product Description

Standard:	ASTM A335	Material Grade:	P11, 1 1/4Cr-1/2Mo
Nondestructive Examination:	Practice E213, Practice E309, Practice E570	Mechanical Test:	Transverse Test, Longitudinal Tension Test, Hardness Test, Flattening Test, Bend Test
Application:	Oil Refinery	Application Equipment:	API Standard 560 Fired Heater
Application Section:	Radiant Section
Highlight:	GRADE P11 ALLOY STEEL SEAMLESS PIPE , ASTM A335 ALLOY STEEL SEAMLESS PIPE , Heater Radiant Alloy Steel Seamless Pipe

ASTM A335 Grade 1¼Cr-½Mo P11 Alloy Steel Seamless Pipe for API Standard 560 Fired Heater

ASTM A335 Grade P11 (1¼Cr-½Mo) seamless pipes deliver exceptional high-temperature creep resistance and oxidation stability in fired heaters. Engineered for API 560 compliance, these pipes ensure reliable performance in radiant/convection sections up to 550°C. Ideal for hydrocarbon processing, they combine weldability, stress tolerance, and cost efficiency for critical heater tube service.

Chemical Composition of ASTM A335 Grade P11 (1¼Cr-½Mo)

Element	Composition (% Weight)
Carbon (C)	0.05–0.15
Manganese (Mn)	0.30–0.60
Phosphorus (P)	≤ 0.025
Sulfur (S)	≤ 0.025
Silicon (Si)	0.50–1.00
Chromium (Cr)	1.00–1.50
Molybdenum (Mo)	0.44–0.65
Notes	Residuals (Cu, Ni, etc.) ≤ 0.50% combined

Mechanical Properties of ASTM A335 P11

Property	Value
Tensile Strength	≥ 415 MPa (60 ksi)
Yield Strength	≥ 205 MPa (30 ksi)
Elongation (50mm Gauge)	≥ 30% (varies with wall thickness)
Hardness (Max)	197 HBW / 207 HV
Impact Test	Charpy V-notch ≥ 20J @ 20°C (Optional per spec)
Notes	Properties apply after heat treatment (normalize + temper)

Equivalent Grades of P11 Across Standards

Standard	Grade Designation	UNS Number	Common Name
ASTM/ASME	A335 Gr. P11	K11597	1¼Cr-½Mo
EN	13CrMo4-5	1.7335	13CrMo4-5
ISO	CrMo 1 1/4 1/2	-	-
JIS	STPA 25	-	Chrome-Moly Pipe
Notes	UNS K11597 is the universal cross-standard identifier

Common Alloy Tubes in Fired Heaters

Alloy Grade	Common Designation	Typical Use in Fired Heaters	Why Used
Carbon Steel	A106 Gr.B / A53	Low-temp sections, economizers	Cost-effective for ≤ 425°C
1¼Cr-½Mo	ASTM A335 P11	Radiant/Convection sections (≤ 550°C)	Creep resistance, weldability
2¼Cr-1Mo	ASTM A335 P22	High-temp radiant sections (≤ 575°C)	Better creep strength than P11
9Cr-1Mo	ASTM A335 P9	Superheaters (≤ 650°C)	Oxidation resistance
Alloy 800H/HT	UNS N08810/11	High-temp crackers (≤ 900°C)	Carburization/oxidation resistance

Radiant Section Components in Fired Heaters

Component	Function
Radiant Tubes	Contain process fluid; absorb direct flame radiation
Burners	Generate flames to heat tubes
Refractory Lining	Insulates walls/floor, reflects heat toward tubes
Tube Supports	Hold tubes in position (e.g., guides, hangers)
Shock/Sight Doors	Allow visual inspection and emergency access
Header Pipes	Distribute fluid to/from tube banks
Crossover Piping	Connect radiant/convection sections
Steel Casing	Structural enclosure containing insulation
Stack/Damper	Flue gas exit path with draft control (connects to convection section)

For API 560 fired heaters, ASTM A335 P11 seamless pipes provide a proven solution for demanding radiant/convection environments. Their balanced chromium-molybdenum chemistry offers superior strength, thermal stability, and corrosion resistance. Optimized for longevity and safety in refineries/petrochemical units, P11 pipes are a cost-effective choice for sustained high-temp operation.
