ERW Tube , ASME SA178 Grade A Carbon Steel Tube , Welded Steel Boiler Tube

Product Details:

Place of Origin:	CHINA
Brand Name:	YUHONG
Certification:	ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008.
Model Number:	ASME SA178 Grade A ERW Carbon Steel Tube

Payment & Shipping Terms:

Minimum Order Quantity:	1000KGS
Packaging Details:	Ply-wooden Case /Bundle with plastic Cap
Delivery Time:	7days
Payment Terms:	L/C, T/T

Contact Now

All Products

Stainless Steel Seamless Pipe (290)

Stainless Steel Seamless Tube (277)

Duplex Stainless Steel Pipe (127)

Duplex Stainless Steel Tube (29)

Needle Tube (107)

Fin Tube (631)

Heat Exchanger (17)

Heat Exchanger Tube (424)

Heat Exchanger Tube Bundle (37)

Heat Exchanger Tubesheet (116)

Heat Exchanger Baffle (36)

Air Cooler (8)

Pressure Vessel (4)

Stainless Steel Welded Pipe (57)

Stainless Steel Welded Tube (114)

Nickel Alloy Pipe (261)

Nickel Alloy Tube (79)

Copper Alloy Tube (227)

Alloy Steel Tube (184)

Titanium Tube (10)

Bright Annealed Tube (153)

Boiler Tube (145)

Steel Fitting (804)

Steel Flange (590)

Others (391)

Cladding Parts (7)

Detailed Product Description

Product Name:	Boiler Tube	Specification:	ASTM A178, ASME SA178
Material:	Grade A, C, D	O.D.:	1/2" To 5" (12.7 To 127 Mm)
Min. Thickness:	0.035 To 0.360 In. (0.9 To 9.1 Mm)	Length:	Single Random, Double Random & Cut Length
End:	Plain Ends / Beveled Ends	Process:	Cold Drawn, Hot Finished
Application:	Boiler, Heat Exchanger, Superheat
Highlight:	ASME SA178 Grade A ERW Tube , Boiler Carbon Steel ERW Tube , Heat Exchanger Carbon Steel ERW Tube

ASTM A178 / ASME SA178 Gr.A Carbon Steel ERW Tube Boiler Tube

ASTM A178/ASME SA178 is a standard specification for electric-resistance-welded (ERW) carbon steel tubes used primarily in boiler superheaters, heat exchangers, and condensers. These tubes are designed for moderate temperature and pressure service. The key characteristic of SA178 tubes is their welded construction, making them a cost-effective alternative to seamless tubes for many applications where the highest pressures and temperatures are not a concern.

ASME SA178 Grade A Carbon Steel ERW Tube Chemical Composition

Element %.	ASTM A178/ ASME SA-178
Element %.	Grade A	Grade C	Grade D
C	0.06~0.18	≤0.35	≤0.27
Mn	0.27~0.63	≤0.80	1.00~1.50
P	≤0.035	≤0.035	≤0.030
S	≤0.035	≤0.035	≤0.015
Si	-	-	≥0.10

*Grade A is a low-carbon steel with good weldability and formability. Grade C has a higher carbon and silicon content, providing higher strength at elevated temperatures, making it more suitable for superheater applications.

ASME SA178 Grade A Carbon Steel ERW Tube Mechanical Properties

ASTM A178	Grade C	Grade D
Tensile strength ksi [MPa]	60 [415]	70 [485]
Yield strength ksi [MPa]	37 [255]	40 [275]
Eelongation in 2" min. %	30	30
For longitudinal strip tests a deduction for each 1 ⁄ 32 in. [0.8 mm] decrease in 1.50A 1.50A wall thickness below 5 ⁄ 16 in. [8 mm] from the basic minimum elongation of the following percentage points shall be made.

Manufacturing Process

ERW (Electric Resistance Welding): Sheets of steel are formed into a cylindrical shape, and edges are fused using electrical resistance. This method ensures precise dimensions and cost-effectiveness.
Post-Weld Heat Treatment: Often applied to relieve residual stresses and enhance mechanical properties.

Applications

SA178 tubes are chosen for specific, well-defined roles in thermal systems:

Boiler Superheaters (especially Grade C): For saturated or low-temperature superheat sections.
Water-Tube Boilers: For generating and containing steam at moderate pressures.
Heat Exchangers & Condensers: For transferring heat between fluids (e.g., in power plants, refineries, HVAC systems).
General Service Pressure Tubes: Where the operating conditions fall within the limits of ERW carbon steel.
