ASTM A105 Carbon Steel Series B Weldneck Flange B16.47 For Piping

Product Details:

Place of Origin:	CHINA
Brand Name:	YUHONG
Certification:	ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number:	ASTM A105 A105

Payment & Shipping Terms:

Minimum Order Quantity:	500KGS
Price:	Negotiable
Packaging Details:	Plywooden Case /Iron Case
Delivery Time:	5-8days
Payment Terms:	L/C, T/T
Supply Ability:	1500 tons per month

Contact Now

All Products

Stainless Steel Seamless Pipe (290)

Stainless Steel Seamless Tube (277)

Duplex Stainless Steel Pipe (127)

Duplex Stainless Steel Tube (29)

Needle Tube (107)

Fin Tube (631)

Heat Exchanger (17)

Heat Exchanger Tube (424)

Heat Exchanger Tube Bundle (37)

Heat Exchanger Tubesheet (116)

Heat Exchanger Baffle (36)

Air Cooler (8)

Pressure Vessel (4)

Stainless Steel Welded Pipe (57)

Stainless Steel Welded Tube (114)

Nickel Alloy Pipe (261)

Nickel Alloy Tube (79)

Copper Alloy Tube (227)

Alloy Steel Tube (184)

Titanium Tube (10)

Bright Annealed Tube (153)

Boiler Tube (145)

Steel Fitting (804)

Steel Flange (590)

Others (391)

Cladding Parts (7)

Detailed Product Description

Standard:	ASTM A105	Grade:	A105
Type:	Weldneck	Class:	#150, #300, #400, #600, #900
Application:	Piping Application	Hydrostatic Test:	ASTM A961/A961M
Highlight:	ASTM A105 Weldneck Flange , ASTM A105 Carbon Steel Flange , Piping Weldneck Flange

ASTM A105 Carbon Steel Series B Weldneck Flange B16.47 for Piping Applications

With 30 years of experience in the piping components industry, Yuhong specializes in manufacturing ASTM A105 carbon steel Series B weldneck flanges conforming to B16.47, tailored for diverse piping applications. Having exported to 85 countries, the company has built a solid reputation worldwide, leveraging reliable quality and professional services to stand out in the global piping components market.

ASTM A105 Carbon Steel Series B Weldneck Flange Chemical Requirements

Element	Carbon	Manganese	Phosphorus	Sulfur	Silicon	Copper	Nickel	Chromium	Molybdenum	Vanadium
Composition, %	0.35 max	0.60 - 1.05	0.035 max	0.040 max	0.10 - 0.35	0.40 max	0.40 max	0.30 max	0.12 max	0.08 max

ASTM A105 Carbon Steel Series B Weldneck Flange Mechanical Requirements

Tensile strength, min, ksi [MPa]	70 [485]
Yield strength, min, ksi [MPa]	36 [250]
Hardness, HBW, max	197

Computed Minimum Values

Wall Thickness		Elongation in 2 in. or 50 mm, min, %
in.	mm
5/16 (0.312)	7.9	30
9/32 (0.281)	7.1	28.5
1/4 (0.250)	6.4	27
7/32 (0.219)	5.6	25.5
3/16 (0.188)	4.8	24
5/32 (0.156)	4	22.5
1/8 (0.125)	3.2	21
3/32 (0.094)	2.4	19.5
1/16 (0.062)	1.6	18

ASTM A105 Carbon Steel Series B Weldneck Flange B16.47 for Piping Applications

Energy Sector
- Used in oil & gas exploration, refining, and power generation, handling high - pressure fluids in pipelines.
Petrochemical Industry
- Ideal for petrochemical processes, connecting pipelines that transport chemicals, solvents, and petroleum products.
Infrastructure and Construction
- Applied in building HVAC, water supply, and drainage systems, as well as in bridge and tunnel pipelines.
Mechanical and General Industrial Applications
- Connects pipelines in industrial machinery, sewage treatment, and equipment like pumps and boilers.
