ASTM B729 N08020 Nickel Iron Chromium Molybdenum Copper Nickel Alloy Seamless Pipe

Product Details:

Place of Origin:	CHINA
Brand Name:	YUHONG
Certification:	ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number:	ASTM B729 N08020

Payment & Shipping Terms:

Minimum Order Quantity:	1000kgs
Price:	Negotiable
Packaging Details:	Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Delivery Time:	Depends on quantity
Payment Terms:	T/T, L/C AT SIGHT
Supply Ability:	50 tons per month

Contact Now

All Products

Stainless Steel Seamless Pipe (290)

Stainless Steel Seamless Tube (277)

Duplex Stainless Steel Pipe (127)

Duplex Stainless Steel Tube (29)

Needle Tube (107)

Fin Tube (631)

Heat Exchanger (17)

Heat Exchanger Tube (424)

Heat Exchanger Tube Bundle (37)

Heat Exchanger Tubesheet (116)

Heat Exchanger Baffle (36)

Air Cooler (8)

Pressure Vessel (4)

Stainless Steel Welded Pipe (57)

Stainless Steel Welded Tube (114)

Nickel Alloy Pipe (261)

Nickel Alloy Tube (79)

Copper Alloy Tube (227)

Alloy Steel Tube (184)

Titanium Tube (10)

Bright Annealed Tube (153)

Boiler Tube (145)

Steel Fitting (804)

Steel Flange (590)

Others (391)

Cladding Parts (7)

Detailed Product Description

Standard:	ASTM B729	Material Grade:	N08020
Thickness:	SCH5-SCHXXS	Type:	Seamless
Surface:	Pickled And Annealed, Bright Annealed, Polished	Type Of Tube:	Straight Tube
Special Type:	Thick Wall Pipe	Process:	Hot/Cold Rolled, Hot Work, Cold Drawn
Hydrostatic Test:	ASTM B829-19a	Nondestructive Electric Test:	ASTM B829-19a
Chemical Composition:	ASTM B829-19a	Mechanical Properties:	ASTM E8
Highlight:	UNS N08020 Seamless Pipe , 100% UT Seamless Pipe , ASTM B729 Alloy20 Seamless Pipe

ASTM B729 N08020 Nickel Iron Chromium Molybdenum Copper Nickel Alloy Seamless Pipe

YUHONG'S UNS N08020 Alloy 20 is an austenitic stainless steel with high resistance to pitting, corrosion and acidic environments. Its unique properties make it ideal for use in industries such as chemical processing, pharmaceutical, food and beverage, and water treatment. Alloy 20 Seamless Steel Tubes are manufactured as per standard specifications and are widely available in the market.

ASTM B729 N08020 Nickel Iron Chromium Molybdenum Copper Nickel Alloy Seamless Pipe Chemical Composition

Nickel	Carbon	Manganese	Phosphorus	Sulfur	Silicon	Chromium	Molybdenum	Copper	Columbium (Nb) + tantalum	Nitrogen	Iron
32-38	0.07	2	0.045	0.035	1	19.00 - 21.00	2.00 - 3.00	3.00 - 4.00	8 × carbon - 1.00	...	remainder

ASTM B729 N08020 Nickel Iron Chromium Molybdenum Copper Nickel Alloy Seamless Pipe Mechanical Properties

Density	Melting Point	Yield Strength (0.2%Offset)	Tensile Strength	Elongation
8.1 g/cm3	1443 °C (2430 °F)	ksi – 80, MPa – 240	ksi – 35 , MPa – 550	30 %

ASTM B729 N08020 Nickel Iron Chromium Molybdenum Copper Nickel Alloy Seamless Pipe Equivalent specification

ALLOY	UNS	WERKSTOFF NR.	AFNOR	EN	JIS	BS	GOST
Alloy 20	N08020	2.4660	Z2NCUD31-20AZ	NiCr20CuMo	–	–	–

ASTM B729 N08020 Nickel Iron Chromium Molybdenum Copper Nickel Alloy Seamless Pipe Schedule Chart

3 1/2" IPS( 4.000"O. D.)	1/8" IPS(.405"O. D.)
SCH 40, 10, 160, 80, XXH	SCH 40, 80
4" IPS(4.500"O. D.)	1/4" IPS(.540"O. D.)
SCH 40, 10, 160, 80, XXH	SCH 40, 10, 80
5" IPS( 5.563"O. D.)	3/8" IPS(.675"O. D.)
SCH 40, 10, 160, 80, XXH	SCH 40, 10, 80
6" IPS(6.625"O. D.)	1/2" IPS(.840"O. D.)
SCH 10, 5, 80, 40, 160, 120 XXH	SCH 5, 40, 10, 160, 80, XXH
8 ” IPS(8.625"O. D.)	3/4" IPS(1.050"O. D.)
SCH 10, 5, 80, 40, 160, 120 XXH	SCH 40, 10, 160, 80, XXH
10" IPS(10.750"O. D.)	1" IPS:(1.315′O. D.)
SCH 10, 20, TRUE 80(.500), 40, 80 (.500),	SCH 5, 40, 10, 160, 80, XXH
12" IPS(12.750"O. D.)	1-1/4" IPS(1.660"O. D.)
SCH 10, 20, TRUE40(.406), 40(.375), SCH80(.500)	SCH 40, 10, 160, 80, XXH
14" IPS(14.000"O. D.)	1-1/2" IPS(1.900"O. D.)
SCH10(.188), SCH40(.375)	SCH 40, 10, 160, 80, XXH
16" IPS(16.000"O. D.)	2" IPS(2.375"O. D.)
SCH10(.188), SCH40(.375)	SCH 40, 10, 160, 80, XXH
18" IPS (18.000"O. D.)	2 1/2" IPS(2.875"O. D.)
SCH-40 (.375)	SCH 40, 10, 160, 80, XXH
	3" IPS( 3.500"O. D.)
	SCH 5, 40, 10, 160, 80, XXH

ASTM B729 N08020 Nickel Iron Chromium Molybdenum Copper Nickel Alloy Seamless Pipe Application

Synthetic rubber production equipment
Processing of pharmaceuticals, plastics, organic and chemical products
Production equipment such as storage tanks, pipelines, heat exchangers, pumps, valves, etc
Pickling equipment
Chemical processing pipeline
Bubble hood
Petrochemical production equipment
Production of food and dyes
