C68700 Aluminium Brass Seamless Tube, ASTM B111 UNS C68700, Used In Desalination Plant

C68700 Aluminium Brass Seamless Tube, ASTM B111 UNS C68700, Used In Desalination Plant

  • C68700 Aluminium Brass Seamless Tube, ASTM B111 UNS C68700, Used In Desalination Plant
  • C68700 Aluminium Brass Seamless Tube, ASTM B111 UNS C68700, Used In Desalination Plant
  • C68700 Aluminium Brass Seamless Tube, ASTM B111 UNS C68700, Used In Desalination Plant
  • C68700 Aluminium Brass Seamless Tube, ASTM B111 UNS C68700, Used In Desalination Plant
C68700 Aluminium Brass Seamless Tube, ASTM B111 UNS C68700, Used In Desalination Plant
Product Details:
Place of Origin: CHINA
Brand Name: YUHONG
Certification: ISO, TUV, PED etc.
Model Number: C68700 Aluminium Brass Seamless Tube
Payment & Shipping Terms:
Minimum Order Quantity: 300kgs
Price: NEGOTIABLE
Packaging Details: Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Delivery Time: Depends on quantity
Payment Terms: T/T, L/C at sight
Supply Ability: 1000 Ton/Month
Contact Now
All Products
Stainless Steel Seamless Pipe (290)
Stainless Steel Seamless Tube (277)
Duplex Stainless Steel Pipe (127)
Duplex Stainless Steel Tube (29)
Needle Tube (107)
Fin Tube (631)
Heat Exchanger (17)
Heat Exchanger Tube (424)
Heat Exchanger Tube Bundle (37)
Heat Exchanger Tubesheet (116)
Heat Exchanger Baffle (36)
Air Cooler (8)
Pressure Vessel (4)
Stainless Steel Welded Pipe (57)
Stainless Steel Welded Tube (114)
Nickel Alloy Pipe (261)
Nickel Alloy Tube (79)
Copper Alloy Tube (227)
Alloy Steel Tube (184)
Titanium Tube (10)
Bright Annealed Tube (153)
Boiler Tube (145)
Steel Fitting (804)
Steel Flange (590)
Others (391)
Cladding Parts (7)
Detailed Product Description
Standard: ASTM B111 / ASME SB111 Material: C68700 / CuZn20Al2As / CuZn20Al2 (Aluminium Brass)
Non-destructive Tests: ET / UT / HT Applications: Marine Condensers / Heat Exchangers / Desalination Plants
Highlight:

Condenser Aluminum Brass Seamless Tube

,

Seamless Aluminum Brass Tube

,

C68700 Aluminum Brass Heat Exchanger Tube

C68700 Aluminium Brass Seamless Tube, ASTM B111 UNS C68700, Used In Desalination Plant




Short Introduction: C68700 Copper Alloy Seamless Tube



C68700 Copper Alloy Seamless Tube, also known as Aluminium Brass Tube, is a high-performance, non-ferrous tubing material made primarily of copper, zinc, and aluminium. It offers excellent corrosion resistance, particularly in seawater and marine environments, and is commonly used in heat exchangers, condensers, and power plant cooling systems. The seamless design ensures leak-free operation under pressure and thermal stress. Its high thermal conductivity, good mechanical strength, and resistance to biofouling make it ideal for demanding industrial and marine applications.




Key Characteristics of C68700 Aluminium Brass Seamless Tube



FeatureDescription
TypeSeamless (SMLS) copper alloy tube
StandardASME SB111 / ASTM B111
Corrosion ResistanceExcellent in seawater, brackish water
Thermal Conductivity~121 W/m·K
Mechanical StrengthTensile ≥ 345 MPa, Yield ≥ 125 MPa (annealed)
WorkabilityGood for expansion, bending, welding
Biofouling ResistanceHigh due to aluminium content




Chemical Composition (UNS C68700)



Element

Percentage (%)

Copper (Cu)

76.0 – 79.0

Zinc (Zn)

Balance

Aluminium (Al)

1.8 – 2.5

Iron (Fe)

0.02 – 0.06

Manganese (Mn)

0.2 – 0.6

Arsenic (As)

Trace (for corrosion resistance)



ASME SB111 C68700  Mechanical Properties


Copper or Copper Alloy UNS NO.Temper DesignationTensile StrengthYield StrengthElongation
in 2 in.,
CodeFormermin ksi(min MPa)min ksi(min MPa)min %
C68700O61annealed50(345)18(125)---




ASME SB111 C68700 Equivelant


STANDARDUNSWERKSTOFF NR.
Aluminium BrassC687002.0460 / 1785



Application of Aluminium Brass Seamless Tube:

  • Evaporator Tubing

  • Heat Exchanger Tubing

  • Condenser Tube Plates

  • Distiller Tubes

  • Oil Well Pump Liner

  • Ferrules

  • Bourdon Tubes

  • Condenser Tubes

  • Desalination plant
