ASTM A403 6 Moly Alloys Steel Pipe Joints And Fittings SCH40S / SCH80S Impact Toughness

ASTM A403 6 Moly Alloys Steel Pipe Joints And Fittings SCH40S / SCH80S Impact Toughness

  • ASTM A403 6 Moly Alloys Steel Pipe Joints And Fittings SCH40S / SCH80S Impact Toughness
  • ASTM A403 6 Moly Alloys Steel Pipe Joints And Fittings SCH40S / SCH80S Impact Toughness
  • ASTM A403 6 Moly Alloys Steel Pipe Joints And Fittings SCH40S / SCH80S Impact Toughness
  • ASTM A403 6 Moly Alloys Steel Pipe Joints And Fittings SCH40S / SCH80S Impact Toughness
  • ASTM A403 6 Moly Alloys Steel Pipe Joints And Fittings SCH40S / SCH80S Impact Toughness
  • ASTM A403 6 Moly Alloys Steel Pipe Joints And Fittings SCH40S / SCH80S Impact Toughness
  • ASTM A403 6 Moly Alloys Steel Pipe Joints And Fittings SCH40S / SCH80S Impact Toughness
ASTM A403 6 Moly Alloys Steel Pipe Joints And Fittings SCH40S / SCH80S Impact Toughness
Product Details:
Place of Origin: CHINA
Brand Name: YUHONG GROUP
Certification: ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2015, IEI
Model Number: S31254 / 254MO / 253MA /6MO
Payment & Shipping Terms:
Minimum Order Quantity: 1PC
Price: Negotiable
Packaging Details: Ply-wooden Case Or Iron Case
Delivery Time: 10 DAYS
Supply Ability: 200 TONS PER MONTH
Contact Now
Detailed Product Description
Material: ASTM A403 S31254 / 254MO / 253MA /6MO Size: OD:1/2" NB - 48" NB; WT: SCH10s - SCH XXS
Dimension Standard:: ANSI B16.9, MSS SP 43 FORM: Elbows In Long & Short Radius In 45 Deg, 90 Deg, 180 Deg,Equal, Unequal Tee & Barred Tee
High Light:

carbon steel fittings

,

forged steel fittings

ASTM A403 6 Moly alloys  ELBOW , TEE, REDUCER , CAP , B16.9 SCH10S , SCH40S , SCH80S , SCH160, STD


6 Moly - 6% Molybdenum Stainless Steels

UNS S31254 - UNS N08925 - UNS N08926 - UNS N08367 (AL6XN)

6 Moly Plate/Sheet
6 Moly Seamless & Welded Tube
6 Moly Seamless & Welded Pipe
6 Moly Round Bar
6 Moly Flanges F44
6 Moly Specialty Forgings
Alloys Now offers a large variety of products in materials of 6% Moly (6MO) including tubing, seamless- and welded pipe, butt weld fittings, flanges, round bar and plate products:




6% Moly Stainless Steels
"Super"-Austenitic
UNS S31254 UNS N08367(AL6XN) UNS N08925 UNS N08926

Tubing
Seamless
1/16" - 2" OD0.016" - 0.250" WT
3 mm - 50 mm OD0.5 mm - 6.0 mm WT
Tubing
Welded
1/2" - 6" OD0.035" - 0.500" WT
12 mm - 150 mm OD1.0 mm - 12.0 mm WT
Pipe
Seamless & Welded
1/2" - 36"Sch 10S thru Sch 80
Butt Weld Fittings
Seamless & Welded
1/2" - 36"Sch 10S thru Sch 80
Flanges
WN & Blind
1/2" - 36"Sch 10S thru Sch 40
150lb & 300lb
Round Bar1/2" - 12"
Plate1/8" - 2" thick


With its high levels of chromium, molybdenum, and nitrogen, 6 Moly alloys have excellent resistance to a wide range of chemicals and are especially suited for high chloride environments such as brackish water, seawater, pulp mill bleach plants and other high chloride process streams. They provide a cost-efficient alternative to nickel-based alloys and titanium.

BENEFITS of 6% MOLY
  • High resistance to pitting, crevice and general corrosion.
  • Very high resistance to chloride stress corrosion cracking.
  • 50% stronger than 300-series austenitic stainless steels.
  • Excellent impact toughness.
  • Excellent workability and weldability.
6% MOLY APPLICATIONS
  • Seawater handling equipment; heat exchanger, cooling water pipes
  • Pulp mill bleach systems; drums, vats and press rolls.
  • Tall oil distillation columns and equipment
  • Chemical processing equipment
  • Food processing equipment
  • Desalination equipment
  • Flue gas desulphurization scrubbers
  • Oil and gas production equipment
  • Tanks and pipelines for various chemicals with high halide levels



UNS S31254
CarbonChromiumCopperManganeseMolybdenumNitrogenNickelPhosphourusSulfurSilicon
0.020
max
19.50-20.500.50-1.001.00
max
6.00-6.500.180-0.22017.50-18.500.030
max
0.010
max
0.80
max




UNS N08367 (AL6XN)
CarbonChromiumIronManganeseMolybdenumNitrogenNickelPhosphourusSulfurSilicon
0.030
max
20.0-22.0remaining2.00
max
6.00-7.000.18-0.2523.50-25.500.040
max
0.030
max
1.00
max




UNS N08925
CarbonChromiumCopperIronManganeseMolybdenumNitrogenNickelPhosphourusSulfurSilicon
0.020
max
19.0-21.00.8-1.5


remaining

1.00 max6.0-7.00.10-0.2024.0-26.00.045
max
0.030
max
0.50
max




UNS N08926
CarbonChromiumCopper


Iron

ManganeseMolybdenumNitrogen


Nickel

PhosphourusSulfurSilicon
0.020
max
19.0-21.00.5-1.5


remaining

2.00 max6.0-7.00.15-0.2524.0-26.00.030
max
0.010
max
0.50
max




Trade NameUNS6Moly Industry SpecificationsChemical CompositionMin.Tensile
(KSI)
Min.Yield
(KSI)
Elongation
%
254 SMOUNS S31254ASME SA-182, SA-240, SA-249, SA-312, SA-358, SA-409, SA-479, SA-480
ASTM A182 (F44), A193, A240, A249, A269, A270, A276, A312, A358, A403, A409, A473, A479, A480, A813, A814, A988
SAE J405
C 0.020 max
Cr 19.50-20.5
Cu 0.50-1.00
Mn 1.00 max
Mo 6.00-6.50
N 0.18-0.220
Ni 17.50-18.50
P 0.030 max
S 0.010 max
Si 0.80 max
944435
N/AUNS N08925ASME SB-625, SB-649, SB-673, SB-674
ASTM B366, B625, B649, B673, B674, B677
C 0.020 max
Cr 19.0-21.0
Cu 0.80-1.50
Fe rem
Mn 1.00 max
Mo 6.00-7.00
N 0.10-0.20
Ni 24.0-26.0
P 0.045 max
S 0.030 max
Si 0.50 max
944335
Alloy 25-6MO/
Alloy 926
UNS N08926ASME SB-366, SB-625, SB-649, SB-673, SB-674, SB-677
ASTM A240, A249, A269, A270, A314, A358, A480, A688, A959, B366, B472, B625, B649, B673, B674, B677, B804
SAE J405
C 0.020 max
Cr 19.0-21.0
Cu 0.50-1.5
Fe rem
Mn 2.00 max
Mo 6.00-7.00
N 0.15-0.25
Ni 24.0-26.0
P 0.030 max
S 0.010 max
Si 0.50 max
944335




Moldydenum General Information

Molybdenum is a lustrous, silvery colored metal which has an abundance of 1.5 ppm in the earth's crust. In many instances, it shows a resemblance to tungsten with which it tends to be paired in the transition series in the periodic table, but their chemistries tend to show more distinct differences than might be expected.
Molybdenum has a high melting point and applications for the pure metal take advantage of this; for example, the pure material is used as resistance heating elements in furnaces, as filament supports in electric lamps, and as electrodes for mercury vapor lamps. Molybdenum is used as an alloying agent in certain grades of steel, Permalloys and Stellites (a series of alloys which contain varying proportions of Cr, Co, W and Mo, are very hard and are used in cutting tools and to protect surfaces subject to heavy wear).

Molybdenum Key Properties

Low co-efficient of thermal expansion (5.1x10-6 m/m/°C) which is about half that of most steels,
Good thermal conductivity,
Good electrical conductivity,
Good stiffness, greater than that of steel (Young’s Modulus 317MPa),
High melting point (2615°C),
Good hot strength,
Good strength and ductility at room temperature,
High density (10.2 g/cm3)
Molybdenum's ability to withstand high temperatures and maintain strength under these conditions are responsible for the fact that molybdenum finds most of its application at elevated temperatures. In fact, it can work at temperatures above 1100°C (in non-oxidizing conditions), which is higher than steels and nickel-based superalloys.
When exposed to temperatures in excess of 760°C in air rapid oxidation can result. Under these conditions, the oxide layer sublimes and the base metal is attacked. Thus, molybdenum performs best in inert of vacuum environments.

Molybdenum Applications

Seawater Handling Equipment
Pulp Mill Bleach Systems
Tall Oil Distillation Columns and Equipment
Chemical Processing Equipment
Food Processing Equipment
Desalination Equipment
Flue Gas Desulfurization Scrubbers
Oil and Gas Production Equipment
ASTM A403 6 Moly Alloys Steel Pipe Joints And Fittings SCH40S / SCH80S Impact Toughness 0
