Yuhong Holding Group Co.,LTD
 |
| Place of Origin: | CHINA |
| Brand Name: | YUHONG |
| Certification: | ABS, BV, DNV-GL , PED, TUV, LR, KR, NK, CCS |
| Model Number: | ASME B163 INCONEL 601 600 603 690 693 67 * 4 * 1010 MM ALLOY STEEL SEAMLESS PIPE |
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | NEGOTIABLE |
| Packaging Details: | Ply-wooden Case /Iron Case/ Bundle with plastic Cap |
| Delivery Time: | 20-80 |
| Payment Terms: | L/C, T/T |
| Standard:: | ASME B163 | Material:: | 601 600 603 690 693 |
|---|---|---|---|
| Testing: | ET, HT, Flattening Test; Expansion Test, Mercurous Nitrate Test; Ammonia Vapor Test; Chemical Analysis; Microscopical Examination; Tension Testing. | Specification: | ASME B163 INCONEL 601 600 603 690 693 67 * 4 * 1010 MM ALLOY STEEL SEAMLESS PIPE |
| Length: | 6 Meters Or Customized | Shape: | Round.square.Rectangle |
| Package: | Standard Seaworthy Package | ||
| High Light: | Asme B163 alloy steel seamless pipe,Inconel 601 alloy steel seamless pipe,Asme B163 Inconel 601 Pipe |
||
Asme B163 Inconel 601 600 603 690 693 Alloy Steel Seamless Pipe
We are one of the biggest manufactures of stainless steel & duplex steel & alloy steel tubes and pipes in China. With development more than 20 years, we have accumulated a great many clients all around the world and Yuhong products also won the great praise among the customers.
ASME B163 covers seamless tubes of nickel and nickel alloy for use in condenser and heat-exchanger service. This covers outside diameter and average wall, or outside diameter and minimum wall tube. Tube shall be furnished in the alloys and conditions defined by this specification. The material shall conform to the composition limits of nickel, copper, molybdenum, iron, manganese, carbon, silicon, chromium, aluminium, titanium, phosphorus, cerium, zirconium, yttrium, born, cobalt, columblum, tungsten, and nitrogen specified. Tensile strength, yield strength, elongation, and Rockwell hardness of the material shall conform to the required mechanical properties set by this specification. Test methods such as chemical analysis, tension, rounding procedure, Rockwell hardness, grain size and hardness conversion shall be performed.
Inconel 601 Corrosion resistance: One of the mainly performance of 601 is inexorability in high temperature, even in very inclement conditions. If in the process of heating and cooling cycle, 601 can generate the dense layer of oxide film to get high spalling resistance. 601 have good carbonation resistance. With excellent inoxidability in the high temperature of sulfur atmosphere since it has high chromium and aluminum content.
Inconel 601 Tubes Specification
Pipe Specification : ASTM B163, B516 / ASME SB163, SB516
Size : 1/8″NB TO 30″NB IN
Thickness Range : 0.3mm – 50 mm
Schedule : SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Type : Seamless Tube, Welded Tube, ERW Tube, Fabricated Tube, CDW
Form : Round Tubes, Square Tubes, Rectangular Tube
Length : Single Random, Double Random & Cut Length.
End : Plain End, Beveled End, Threaded
End Protection : Plastic Caps
Outside Finish : 2B, No.1, No.4, No.8 Mirror Finish
Finish : Annealed and Pickled, Polished, Bright Annealed, Cold Drawn
External Coating : 3LPE / 3LPP/ FBE/ DFBE/ PP
Origin : Indian Origin, European Origin, Japanese Origin.
Testing and Documents : Mill Test Certificates, EN 10204 3.1, Chemical Reports, Mechanical Reports, Destructive Test Report, Non Destructive Test Reports, PMI Test Reports, Visual Inspection Reports, Third Party Inspection Reports, NABL Approved Lab Reports
Packing : Packed in Wooden Boxes, Bubble wraps, Steel Strips Bundled, or as per Customers Requests
Inconel 601 Nickel Alloy Seamless Tubes Tubing Pipes Characteristic
Inconel 601 Nickel Alloy Seamless Tubes Tubing Pipes Chemical Composition
| Alloy | % | Ni | Cr | Fe | C | Mn | Si | Cu | Al | P | S |
| ASTM B163 N06601 | Min. | 58 | 21 | 1 | |||||||
| ASTM B163 N06601 | Max. | 63 | 25 | balance | 0.1 | 1 | 0.5 | 1 | 1.7 | 0.02 | 0.015 |
| Alloy | % | Ni | Cr | Fe | C | Mn | Si | Cu | Al | P | S |
| ASTM B167 N06601 | Min. | 58 | 21 | 1 | |||||||
| ASTM B167 N06601 | Max. | 63 | 25 | balance | 0.1 | 1.5 | 0.5 | 1 | 1.7 | 0.02 | 0.015 |
Inconel 601 Nickel Alloy Seamless Tubes Tubing Pipes Mechanical Properties
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 601 | 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30% |
