Austeniticn ASTM A182 F316L threadolet pipe fittings

Austeniticn ASTM A182 F316L threadolet pipe fittings

  • Austeniticn ASTM A182 F316L threadolet pipe fittings
  • Austeniticn ASTM A182 F316L threadolet pipe fittings
  • Austeniticn ASTM A182 F316L threadolet pipe fittings
  • Austeniticn ASTM A182 F316L threadolet pipe fittings
  • Austeniticn ASTM A182 F316L threadolet pipe fittings
Austeniticn ASTM A182 F316L threadolet pipe fittings
Product Details:
Place of Origin: CHINA
Brand Name: YUHONG
Certification: API , ABS, DNV, GL , LR, NK.
Model Number: ASTM A182 F316L Stainless steel threadolet Pipe Fittings
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: NEGOTIABLE
Packaging Details: Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Delivery Time: 20-80
Payment Terms: L/C, T/T
Contact Now
Detailed Product Description
Specification: ASTM A182 F316L Stainless Steel Threadolet Pipe Fittings Connection: Welding
Type: Elbow,Nipple,Pipe Threaded,Reducer,elbow.tee Color: Silver
Usage: Joining Pipe Lines,Oil Gas Water Industrial,oil,gas,Water Packing: Plywood Case Or Pallet
Name: Stainless Steel Pipe Fittings Application: For Water, Oil And Gas Industrial
High Light:

ASTM A182 threadolet pipe fittings

,

F316L threadolet pipe fittings

,

ASTM A182 stainless steel threadolet

ASTM A182 F316L Stainless steel threadolet Pipe Fittings


We are one of the biggest projects pipeline products supplier in China. Our products contain steel pipe/tube,fittings, flanges. With development more than 20 years, we have accumulated a great many clients all around the world and Yuhong products also won the great praise among the customers.



What is F316L?

F316L is an Austenitic Cr-Ni stainless steel. It is a low carbon derivative of F316 The Material is always supplied in the Solution Annealed condition. F316L is readily machinable in the annealed condition by milling, drilling, turning, etc as required.



What is ASTM A182?

ASTM A182 F6a is a forged martensitic stainless steel with 13 wt. Martensitic stainless steels can be high-carbon or low-carbon steel alloys. The ASTM standard A182 describes the general set of specifications about several material grades.





A182 F316L Stainless Steel Pipe Fitting Chemical Composition

Grade C Mn Si P S Cr Mo Ni N
SS 316L 0.035 max 2.0 max 1.0 max 0.045 max 0.030 max 16.00 - 18.00 2.00 - 3.00 10.00 - 14.00 68.89 min



A182 F316L Stainless Steel Pipe Fitting Mechanical Properties

Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation
8.0 g/cm3 1399 °C (2550 °F) Psi – 75000 , MPa – 515 Psi – 30000 , MPa – 205 35%





A182 F316L Stainless Steel Pipe Fitting Equivalent Grades

STANDARD WERKSTOFF NR. UNS JIS BS GOST AFNOR EN
SS 316L 1.4404 / 1.4435 S31603 SUS 316L 316S11 / 316S13 03Ch17N14M3/ 03Ch17N14M2 Z3CND171102/ Z3CND181403 X2CrNiMo17-12-2/ X2CrNiMo18-14-3





Forging



This alloy can be readily forged at temperatures 1000 – 1200Deg.C Hot working below 927Deg.C should be avoided. The low carbon content of these alloys ensures no heavy scale but excessive soak times should still be avoided to avoid enlarged grain size, suggest 15minutes per inch (25mm) of maximum ruling section.



Heat Treatment



This alloy is not hardenable by heat treatment and is therefore supplied in the Annealed condition. Anneal 1040Deg.C minimum, ensuring that sufficient time is allowed for the centre to achieve furnace temperature and hold for a time commensurate with the ruling section, followed by rapid cooling in Water.



Machining



F316L is readily machinable in the annealed condition by milling, drilling, turning, etc as required. Cutting edges should be kept sharp and cuts should be kept light but deep enough to avoid work hardening. Coolants and lubricants should be used in large quantity.



Corrosion Resistance



F316L has excellent corrosion resistance when exposed to a range of corrosive environments. It is usually regarded as Marine grade stainless, however it is not resistant to warm sea water. Warm Chloride environments can cause pitting and crevice corrosion. F316L will also suffer from stress corrosion cracking above 60Deg.C.



Oxidation Resistance



This alloy has good resistance to oxidation in intermittent service upto 870Deg.C and in continuous service up to 925Deg.C. Whilst continuous use between 425 – 860Deg.C is not recommended for F316 if corrosion resistance in water is required this lower carbon variant, F316L, is recommended due to its resistance to carbide precipitation. When high strength at temperatures above 500Deg.C is required, grade F316H is recommended.



Welding



Austenitic stainless steels are generally considered to be weldable by the common fusion and resistance techniques but special consideration is required to avoid hot cracking of the weld metal. F316L was developed from standard F316 to be more amenable to welding and the lower carbon content increases the immunity to grain boundary carbide precipitation, making it suited to use in heavy gauge (>6mm) welded components.



Application

  • Food processing
  • Brewing
  • Marine
  • Automotive
  • Aerospace
  • Mining
  • Medical
  • Oil and Gas





Austeniticn ASTM A182 F316L threadolet pipe fittings 0
