316/316L Stainless Steel UNS S31603 Butt Weld Elbow

316/316L Stainless Steel UNS S31603 Butt Weld Elbow

  • 316/316L Stainless Steel UNS S31603 Butt Weld Elbow
  • 316/316L Stainless Steel UNS S31603 Butt Weld Elbow
  • 316/316L Stainless Steel UNS S31603 Butt Weld Elbow
  • 316/316L Stainless Steel UNS S31603 Butt Weld Elbow
316/316L Stainless Steel UNS S31603 Butt Weld Elbow
Product Details:
Place of Origin: CHINA
Brand Name: YUHONG
Certification: API , ABS, DNV, GL , LR, NK.
Model Number: Stainless Steel 316L UNS S31603 Butt Weld Pipe Fittings
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: NEGOTIABLE
Packaging Details: Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Delivery Time: 20-80
Payment Terms: L/C, T/T
Contact Now
All Products
Stainless Steel Seamless Pipe (224)
Stainless Steel Seamless Tube (178)
Stainless Steel Welded Pipes (41)
Stainless Steel Welded Tube (77)
Finned Tube (204)
Heat Exchanger Tube (131)
Duplex Stainless Steel Pipes (111)
Alloy Steel Seamless Tubes (62)
Bright Annealed Tube (146)
Copper Alloy Tube (131)
Nickel Alloy Pipe (264)
Carbon Steel Pipe (50)
U Bend Tube (140)
Boiler Tube (72)
Steel Pipe Fittings (530)
Steel Flanges (374)
Steel Valves (12)
Precision Steel Strip (23)
Alloy Wires (271)
Heat Exchanger Parts (44)
Detailed Product Description
Standard: ANSI,ASME Shape: Elbow
Connection: Female Technics: Forged
Type: Elbow Size: Customized Size
Application: Gas And Oil Pipes Color: Gray
High Light:

UNS S31603 Butt Weld Elbow

,

316L Butt Weld Elbow

,

ss316 Butt Weld Elbow

Stainless Steel 316L UNS S31603 Butt Weld Pipe Fittings



We are one of the biggest projects pipeline products supplier in China. Our products contain steel pipe/tube,fittings, flanges. With development more than 20 years, we have accumulated a great many clients all around the world and Yuhong products also won the great praise among the customers.



Specification:



Specifications : ASTM A403 / ASME SA 403

Standards : ASTM, ASME

Size : 1/2″ to 24″

Thickness : Sch 5s, Sch 10s, Sch 40s, Sch 80s, Sch 160s, Sch XXS

Variants : 316L

Type : Seamless / Welded

Two Joint / Two Halve 316L Butt weld Fittings Size : 6″ to 48″

Dimensions : ANSI/ASME B16.9, B16.28, MSS-SP-43.







ASME SA403 WP316L Stainless Steel Pipe Fittings Equivalent Grade

STANDARD UNS WERKSTOFF NR. JIS GOST BS AFNOR EN
SS 316L S31603 1.4404 / 1.4435 SUS 316L 03Ch17N14M3 / 03Ch17N14M2 316S11 / 316S13 Z3CND17‐11‐02 / Z3CND18‐14‐03 X2CrNiMo17-12-2 / X2CrNiMo18-14-3







ASME SA403 WP316L Stainless Steel Pipe Fittings Chemical Composition

Grade C Ni Mn S Cr Si P Mo N
SS 316L min. – 10 – – 16 – – 2 –
max. 0.08 14 2 0.03 18 0.75 0.045 3 0.1





ASME SA403 WP316L Stainless Steel Pipe Fittings Physical Properties

Grade Density (kg/m3) Specific Heat 0-1000C (J/kg.K) Mean Coefficient of Thermal Expansion (m/m/0C) Elastic Modulus (GPa) Thermal Conductivity (W/m.K) Electrical Resistivity (n.m)
0-100°C 0-315°C 0-538°C at 100°C at 500°C
316L 8000 500 15.9 16.2 17.5 193 16.3 21.5 740





ASME SA403 WP316L Stainless Steel Pipe Fittings Mechanical Properties

Grade Yield Strength 0.2% Proof (MPa) min Tensile Strength (MPa) min Elongation (% in 50mm) min Hardness
Rockwell B (HR B) max Brinell (HB) max
SS 316L 170 485 40% 95 217







ASME SA403 WP316L Stainless Steel Pipe Fittings Application Industries



  • Off-Shore Oil Drilling Companies
  • Power Generation
  • Petrochemicals
  • Gas Processing
  • Specialty Chemicals
  • Pharmaceuticals
  • Pharmaceutical Equipment
  • Chemical Equipment
  • Sea Water Equipment
  • Heat Exchangers
  • Condensers
  • Pulp and Paper Industry





ASME SA403 WP316L Stainless Steel Pipe Fittings Test Certificates



  • EN 10204/3.1B,
  • Raw Materials Certificate
  • 100% Radiography Test Report
  • Third Party Inspection Report, etc





Material Testing:

  • Mechanical Testing Such as Tensile of Area
  • Hardness Test
  • Chemical Analysis – Spectro Analysis
  • Positive Material Identification – PMI Testing
  • Flattening Test
  • Micro and MacroTest
  • Pitting Resistance Test
  • Flaring Test
  • Intergranular Corrosion (IGC) Test





316/316L Stainless Steel UNS S31603 Butt Weld Elbow 0
