ASME SB163 Incoloy 825 N08825 Nickel Alloy Seamless Tube for Heat Exchanger with Corrosion Resistance

Product Details:

Place of Origin:	CHINA
Brand Name:	YUHONG
Certification:	ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number:	ASME SB163 N08825

Payment & Shipping Terms:

Minimum Order Quantity:	100 KGS
Price:	NEGOTIABLE
Packaging Details:	Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Delivery Time:	20-80 days
Payment Terms:	T/T,L/C
Supply Ability:	1500 Tons Per Month

Contact Now

All Products

Stainless Steel Seamless Pipe (308)

Stainless Steel Seamless Tube (297)

Duplex Stainless Steel Pipe (132)

Duplex Stainless Steel Tube (33)

Needle Tube (134)

Fin Tube (672)

Heat Exchanger (20)

Heat Exchanger Tube (443)

Heat Exchanger Tube Bundle (40)

Heat Exchanger Tubesheet (117)

Heat Exchanger Baffle (37)

Air Cooler (9)

Pressure Vessel (4)

Stainless Steel Welded Pipe (58)

Stainless Steel Welded Tube (120)

Nickel Alloy Pipe (266)

Nickel Alloy Tube (92)

Copper Alloy Tube (240)

Alloy Steel Tube (204)

Titanium Tube (15)

Bright Annealed Tube (155)

Boiler Tube (151)

Steel Fitting (826)

Steel Flange (615)

Others (401)

Cladding Parts (7)

Detailed Product Description

Standard:	ASTM, ASME, DIN, JIS, ISO, GB, GOST, BS	Application:	Petroleum, Chemical, Power, Gas, Metallurgy, Shipbuilding, Construction, Etc.
Thickness:	Customized	Alloy Or Not:	Is Alloy
Technique:	Hot Rolled,Cold Drawn,Cold Rolled,welded And Seamless Steel Pipe	Certificate:	ISO, SGS, BV, Etc.
Heat Treatment:	Annealing, Normalizing, Quenching, Tempering, Etc.	Length:	Customized
Material:	Nickel Alloy	Package:	Standard Export Seaworthy Package
Process Method:	Hot Rolled/Cold Rolled/Cold Drawn/ERW/Forged	Shape:	Pipe
Size:	Customized	Surface Treatment:	Polished
Test:	UT, ET, HT, RT, Etc.
Highlight:	asme sb 163 nickel alloy tube , uns n08825 heat exchanger tube , condenser nickel alloy tube

ASME SB163 Incoloy 825 N08825 Nickel Alloy Seamless Tube For Condenser Heat Exchanger

Yuhong Group is a leading domestic manufacturer and supplier of Incoloy 825 seamless tubes compliant with ASTM B163 UNS N08825 standards. These nickel alloy 825 tubes are engineered for superior performance in demanding industrial applications.

Material Composition & Properties

Incoloy 825 is a nickel-iron-chromium alloy enhanced with molybdenum and copper, specifically formulated to deliver exceptional resistance to various corrosive environments. While similar to Alloy 800, it offers superior water corrosion resistance and excellent performance against reducing and oxidizing acids, stress corrosion cracking, and localized corrosion including pitting and crevice corrosion.

Key Applications: Chemical processing, pollution control equipment, oil and gas well pipelines, nuclear fuel reprocessing, acid production, and pickling equipment.

Available Materials

UNS N02200
UNS N02201
UNS N04400
UNS N06025
UNS N06045
UNS N06600
UNS N06601
UNS N06603
UNS N06686
UNS N06690
UNS N06696
UNS N06845
UNS N08120
UNS N08800
UNS N08801
UNS N08810
UNS N08811
UNS N08825
UNS N06699
UNS N08935

ASTM SB163 UNS N08825 Chemical Composition

Alloy	C	Mn	Si	S	Cu	Fe	Ni	Cr	Al	Ti
825	0.05 max	1.00 max	0.05 max	0.03 max	1.50 - 3.00	22.00 min	38.00 - 46.00	19.50 - 23.50	0.02 max	0.06 - 1.20

ASTM SB163 UNS N08825 Mechanical Properties

Nickel Alloy	Density	Melting Range	Tensile Stress	Yield Stress (0.2% Offset)	Elongation
825	8.14 g/cm³	1400 °C (2550 °F)	Psi - 80,000, MPa - 550	Psi - 32,000, MPa - 220	30%

ASTM SB163 UNS N08825 Physical Properties

Melting Point	Density / Specific Gravity
1370-1400℃	8.1 kg/m³ (0.30 lb/in³)

Purchasing Specifications & Requirements

The purchaser is responsible for specifying all requirements necessary for the safety and satisfactory performance of materials ordered in accordance with this specification.

Alloy Selection - Specify the required alloy grade
State (Tempering) - Define the required tempering condition
Annealed Ends - If required, specify the length of ends to be annealed and whether one or both ends should be annealed
Complete Specifications - Provide full technical requirements
Dimensional Requirements - Outer diameter, minimum or average wall thickness (in inches, not specification numbers), and length
Production Operations:
- Cold bending or coiling requirements
- Packaging specifications
- Rolled or expanded into tube sheet
- Welding or brazing processes
- Hydrostatic test or non-destructive electrical test type
- Pressure requirements (if different from standard)
- End preparation - Flat ends for cutting and deburring
Supplementary Requirements - Specify nature and details of any additional requirements
Product Analysis Samples - Indicate whether to provide product analysis samples
Buyer Inspection - If witness testing is required, specify which tests or inspections to witness
Small Diameter and Light Wall Pipe - For converter size applications

Size Specifications: This specification covers tubes with outer diameter of 3 inches (76.2 mm) and below, minimum wall thickness of 0.148 inches (3.76 mm) and below, and average wall thickness of 0.165 inches (4.19 mm) and below. Specifications are limited to tubes with outer diameter not exceeding 3.5 inches (88.9 mm).
