Yuhong Holding Group Co.,LTD
 |
| Place of Origin: | China |
| Brand Name: | YUHONG |
| Certification: | ABS, LR, GL, DNV, NK, TS, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008 |
| Model Number: | UNS S32750/SAF2507/1.4410 |
| Minimum Order Quantity: | 500KGS |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Ply-wooden Case /Iron Case/ Bundle with plastic Cap |
| Delivery Time: | Depends on quantity |
| Payment Terms: | T/T, L/C at sight |
| Supply Ability: | 3000 tons per month |
| Standard: | ASTM A790/ASME SA790 | Material Grade: | UNS S32750/SAF2507 |
|---|---|---|---|
| Size: | 1/8-72" | W.T.: | 0.8mm - 50mm |
| Product Name: | 2205 Stainless Steel Seamless Pipe S32750 SAF 2507 1.4410 Duplex | Type: | Seamless, Welded |
| Highlight: | duplex steel pipes,welded steel pipe |
||
Overview
UNS S32750 is a stainless steel containing high chromium, high molybdenum, high nitrogen and low carbon for excellent corrosion resistance and high strength. It excels in highly chlorinated and acidic environments and is widely used in the chemical, oil and gas industries.
Heat treatment is the process of changing the organizational structure and properties of UNS S32750 through process treatments such as heating and cooling. Carbon is an important alloying element in UNS S32750 and has a great influence on the properties of UNS S32750.
Characteristic of A790 UNS S32750
Chemical Analysis of S32750
| C | N | P | Si | Mn | Mo | Ni | Cr | S | Other |
| 0.030 | 0.24/0.32 | 0.035 | 0.80 | 1.20 | 3.0/5.0 | 6.00/8.00 | 24.0/26.0 | 0.020 | Cu:0.50 |
Mechanical Properties of S32750
| Pipe Density | Pipe melting point | Pipe yield strength | Pipe tensile trength | Pipe elongation |
| 7.8 g/cm3 | 1350 °C (2460 °F) | Psi - 80000 , MPa - 550 | Psi - 116000 , MPa - 800 | 15 % |
Physical Properties of S32750
| Density (Kg.m-1) | 7810 |
| Magnetic Permeability | 33 |
| Young’s Modulus (N/mm2) | 199 x 103 |
| Specific Heat, 20°C (J.Kg-1.°K-1) | 475 |
| Fracture Toughness, Kq (MPa.m) | 475 |
| Specific Electrical Resistance, 20°C (µO.m) | 0.80 |
| Thermal conductivity, 20°C (W.m-1.°K-1) | 14.2 |
| Mean coefficient of thermal expansion, 20-100°C (°K-1) | 11.1 x 10-6 |
Some of the quality tests carried out by us includes:
| Corrosion Test | Conducted only when specially requested by the client |
| Chemical Analysis | Test done as per required quality standards |
| Destructive / Mechanical Testing | Tensile | Hardness | Flattening | Flare | Flange |
| Reverse-bend and Re. flat tests | Carried out in full compliance with relevant standards & ASTM A-450 and A-530 norms, which ensures trouble-free expansion, welding & use at customers end |
| Eddy Current Testing | Done to detect homogeneities in subsurface by using Digital Flaw-mark Testing System |
| Hydrostatic Testing | 100% Hydrostatic Testing carried out according to ASTM-A 450 norms for checking tube leakage, and biggest pressure we can support 20Mpa/7s . |
| Air Under Pressure Test | To check any evidence of air leakage. |
| Visual Inspection | After passivation, every single length of tubes & pipes is subjected to thorough visual inspection by trained staff for detecting surface flaws & other imperfections |
Supplementary Testing
Apart from the above mentioned tests, we also carry out on the manufactured products supplementary testing.
The tests conducted under this include:
|
|
|
Application
