ASTM B366 Inconel 625 Cap UNS N06625 Butt Weld Fitting B16.9

ASTM B366 Inconel 625 Cap UNS N06625 Butt Weld Fitting B16.9

  • ASTM B366 Inconel 625 Cap UNS N06625 Butt Weld Fitting B16.9
  • ASTM B366 Inconel 625 Cap UNS N06625 Butt Weld Fitting B16.9
  • ASTM B366 Inconel 625 Cap UNS N06625 Butt Weld Fitting B16.9
  • ASTM B366 Inconel 625 Cap UNS N06625 Butt Weld Fitting B16.9
ASTM B366 Inconel 625 Cap UNS N06625 Butt Weld Fitting B16.9
Product Details:
Place of Origin: CHINA
Brand Name: YUHONG
Certification: ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number: ASTM B366 UNS N06625
Payment & Shipping Terms:
Minimum Order Quantity: 100KGS
Price: Negotiable
Packaging Details: According to Client Requirements/ Ply-wooden Case/ Iron Case/ Bundle with plastic Cap
Delivery Time: 15-35 DAYS
Payment Terms: T/T, L/C
Supply Ability: According to Client Requirements
Contact Now
Detailed Product Description
Product Name: NICKEL ALLOY BUTT WELD FITTING Material: UNS NO6625/DIN 2.4856
Application: Aircraft Ducting Systems/Aerospace/Jet Engine Exhaust Systems Surface Treatment: Sand Blasting And Sand Rolling
High Light:

B16.9 Stainless Steel Cap

,

Inconel 625 Butt Weld Cap

,

Cap Butt Weld Fitting



ASTM B366 INCONEL 625 CAP UNS N06625 BUTT WELD FITTING B16.9



Introduction

Inconel 625 is a corrosion and oxidation resistant nickel alloy that is used both for its high strength and outstanding aqueous corrosion resistance. Its outstanding strength and toughness is due to the addition of niobium which acts with the molybdenum to stiffen the alloy’s matrix. Alloy 625 has excellent fatigue strength and stress-corrosion cracking resistance to chloride ions. This nickel alloy has excellent weldability and is frequently used to weld AL-6XN. This alloy resists a wide range of severely corrosive environments and is especially resistant to pitting and crevice corrosion. Some typical applications Inconel 625 is used in are chemical processing, aerospace and marine engineering, pollution-control equipment, and nuclear reactors.



Specification

ASTM B366/B366M-20 Standard Specification for Factory-Made Wrought Nickel and Nickel Alloy Fittings

Pipe Smls

Pipe Welded

Tube Smls

Tube Welded

Sheet/Plate

Bar

Forging

Fitting

Wire

B444 B705 B444 B704 B443 B446 - - -



Chemical Composition

Cr

Ni

Mo

Co + Nb

Ta

Al

Ti

C

Fe

Mn

Si

P

S

20.00-30.00 Remainder 8.0-10.0 1.0 max 3.15-4.15 .40 max .40 max .10 max 5.0 max .50 max .50 max .015 max .015 max



Mechanical Properties

Temp° F

Tensile (psi)

.2% Yield (psi)

Elongation in 2"(%)

70 144,000 84,000 44
400 134,000 66,000 45
600 132,000 63,000 42.5
800 131,500 61,000 45
1000 130,000 60,500 48
1200 119,000 60,000 34
1400 78,000 58,500 59
1600 40,000 39,000 117



Applications



ASTM B366 Inconel 625 Cap UNS N06625 Butt Weld Fitting B16.9 0



  • Aircraft ducting systems
  • Aerospace
  • Jet engine exhaust systems
  • Engine thrust-reverser systems
  • Specialized seawater equipment
  • Chemical process equipment
