Yuhong Holding Group Co.,LTD
 |
| Place of Origin: | China |
| Brand Name: | Yuhong Group |
| Certification: | ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008 |
| Model Number: | ASTM A694 F52 |
| Minimum Order Quantity: | 100 kgs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Ply-wooden Case /Iron Case/ Bundle |
| Delivery Time: | 7 days |
| Payment Terms: | T/T |
| Pressure: | Class150/300/600/9001500/2500,PN2.5/6/10/16/25/40,0-63mpa,150LB-2500LB,Class150-2500/ PN6-PN100 | Type: | Threaded Flange,Slip On Flange,socket Weld Flange,weld Neck Flange,LAP Joint Flange |
|---|---|---|---|
| Surface Treatment: | Heat Treatment, Galvanized, Black Oxidation, Customize, Pickeling | Color: | On Quest,Natural Color,Black |
| High Light: | Forged Steel Flanges F60,Chemical Forged Steel Flanges |
||
ASTM A694 F52 F60 B16.5 Forged Carbon Steel Flange
We are one of the biggest projects pipeline products supplier in China. Our products contain steel pipe/tube,fittings, flanges. With development more than 20 years, we have accumulated a great many clients all around the world and Yuhong products also won the great praise among the customers.
Our main products: Stainless/Duplex/Nickel Alloy Pipe/Tube/Fitting/Flange:
1>.A:Stainless Steel Grade: TP304/304L/304H, TP310S/310H, TP316/316L/316Ti/316H, TP317L/317LN, TP321/321H, TP347/347H, NO8904(904L),
B:PH Stainless Steel:17-4PH(1.4542), 17-7PH(1.4568),15-7PH(1.4532)
C:Duplex Steel Grade: S31803(2205), S32750(2507), S32760, S32304, S32101, S31254(254Mo), 235Ma, UNS NO8926, NO8367.
D:Nickel Alloy Steel Grade:Hestalloy:C-276, C-4, C-22, C-2000, X, B-2, B-3, G-30, G-35. Monel:400,401, 404, R-405, K500.
Inconel:600, 601, 617, 625, 690, 718, 740, X-750. Incoloy:800, 800H, 800HT, 825, 840.
Pure Nickel:Ni-200, Ni-201, Ni-270. NS Alloy:Ns 1101, NS1102, NS1103,NS3105.
2>.Standards: ASTM A213, A249, A269, A312, A789,A790, B163,B167, B444, B677,... and ASME,DIN, EN, JIS, BS, GOST,...
3>.Out diameter sizes range: 0.5mm~650mm. Wall thickness:0.05mm~60mm. Max. length under 26 meters/PC.
4>.Seamless & welded, Solution Pickling/Bright Annealed / Polished.
ASTM A694 F52 CS Flanges Standards / Pressure Class
| ASME/ANSI B 16.5 | A694 F52 Welding Neck Flange, A694 F52 Slip on Flange, Blind Flange, High Hub Blind Flange, Socket Weld Flange, A694 F52 Lap Joint Flange, Threaded Flange, A694 F52 Ring Type Joint Flange |
| PRESSURE CLASS | 150, 300, 400, 600, 900, 1500, 2500 |
| ASME/ANSI B 16.47 | A694 F52 Welding Neck Flange, A694 F52 Blind Flange [Series A & B] |
| PRESSURE CLASS | 75, 150, 300, 400, 600, 900 |
| ASME/ANSI B 16.36 | A694 F52 Welding Neck Flange, A694 F52 Slip on Flange, A694 F52 Threaded Flange |
| PRESSURE CLASS | 300, 400, 600, 900, 1500, 2500 |
| BS 4504 SEC 3.1 | A694 F52 Welding Neck Flange, A694 F52 Hubbed Slip on Flange, A694 F52 Hubbed Threaded Flange, Lapped Pipe End Flange, A694 F52 Plate Flange, Loose Plate Flange, Loose Plate With Weld Neck Flange, Blank Flange |
| PRESSURE CLASS | PN 2.5 TO PN 40 |
| BS 4504[PART 1] | A694 F52 Welding Neck Flange, A694 F52 Hubbed Slip-On Hubbed Threaded, Plate Flange, A694 F52 Loose Plate With Weld On Plate Collar, Blank Flange |
| PRESSURE CLASS | PN 2.5 TO PN 400 |
| BS 1560 BOSS | A694 F52 Welding Neck Flange, Socket Welding Flange, A694 F52 Slip-On Flange, A694 F52 Blind Flange, A694 F52 Screwed Boss Flange, A694 F52 Lapped Flange |
| PRESSURE CLASS | 150, 300, 400, 600, 900, 1500, 2500 |
| BS10 | A694 F52 Welding Neck Flange, A694 F52 Plate Slip-On Flange, A694 F52 Screwed Boss Flange, Slip-On Boss Flange, A694 F52 Blind Flange |
| TABLE | D, E, F, H |
| DIN FLANGES | DIN 2527, 2566, 2573, 2576, 2641,2642, 2655, 2656, 2627, 2628, 2629, 2631, 2632, 2633, 2634, 2635, 2636, 2637,2638, 2673 |
| PRESSURE CLASS | PN 6 TO PN 100 |
A694 F52 Carbon steel flange Chemical Composition
| Chemical Composition of ASTM A694, Heat Analysis, % | |
| Carbon [C] | ≤0.30 |
| Manganese [Mn] | ≤1.60 |
| Phosphorus [P] | ≤0.025 |
| Sulfur [S] | ≤0.025 |
| Silicon [Si] | 0.15-0.35 |
A694 F52 Carbon Steel flange Mechanical Properties
| ASTM A694 Grade | Yield Strength min. | Tensile Strength min. | Elongation min. | ||
| MPa | ksi | MPa | ksi | % | |
| F52 | 360 | 52 | 455 | 66 | 20 |
A694 F52 Carbon Steel flange Application Industries
A694 F52 Carbon Steel flange Test Certificates
Material Testing:
