Yuhong Holding Group Co.,LTD
 |
| Place of Origin: | CHINA |
| Brand Name: | YUHONG |
| Model Number: | ASTM A213 TP304 |
| Minimum Order Quantity: | 100 KGS |
|---|---|
| Price: | NEGOTIABLE |
| Packaging Details: | Ply-wooden Case /Iron Case/ Bundle with plastic Cap |
| Delivery Time: | 20-80 days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 1500 Tons Per Month |
| Certification: | ISO, SGS, BV, ISO & SGS, ISO/CE/SGS | Stock: | Always In Good Stock |
|---|---|---|---|
| Steel Grade: | 300 Series, Stainless Steel 304/316L, 400 Series, X5CrNi18-20, 200 Series | Type: | Seamless, Welded, Round Pipe/Tube |
| Standard: | ASTM, AISI, GB, DIN, JIS | Length: | Customizable |
| Thickness: | 1mm-20mm | Technique: | Cold Rolled Hot Rolled, Cold Drawn, Extrusion, Cold Drawn/Cold Rolling Or Both Of Them |
| Product Name: | Stainless Steel Pipe, 304 304L 316 316L 321 310S Stainless Steel Welded/Seamless Tube, Factory Direct Sales Stainless Steel Pipe For Electric Heating Element, Seamless Stainless Steel Pipe/Tube | Outer Diameter: | 6-630mm, Customized, 6-762mm, 6-860mm;, 6mm-630mm |
| Surface: | Annealing,pickling | Finish: | Brush Polish, Cold Drawn, Pickled, Bright Annealed Or Un Annealed, Bright |
| Alloy Or Not: | Non-Alloy | Corrosion Resistance: | High |
| Material: | Stainless Steel | Ndt: | ET, UT, HT, PMI |
| Origin: | China | Package: | Wooden Boxed |
| Techenology: | Cold Rolled | Treatment: | Cold Rolled / Cold Drawn |
| Tube Finish: | Pickled & Annealed, Bright Annealed | Wall Thickness: | Customizable |
| Welding Line Type: | Seamless | ||
| High Light: | Boiler Steel Seamless Tube,TP304 Stainless Steel Round Tube,Heat Exchanger Seamless Stainless Steel Tube |
||
YUHONG GROUP is one of the big manufacturers of high quality ASTM A213 / ASME SA213 TP 304/304L pipes. ASTM A213 TP304 Specification for Seamless Ferritic and Austenitic Alloy Steel Boiler, Heat Exchanger, and Superheater Tubes. ASTM A213 seamless tubes are mainly used as superheater, boiler, heat exchanger tubes. ASME SA213 TP304 pipe is made from austenitic grades with 2% to 3% molybdenum added to further improve corrosion resistance. ASTM A213 TP304 Tubing sizes and thicknesses are typically supplied to their specifications from 1/8 in. [3.2 mm] ID to 5 in. [127 mm] OD with a minimum wall thickness of 0.015 to 0.500 in [0.4 to 12.7 mm] (inclusive of )thickness. ASTM A213 UNS S30400 tubing in other diameters may be supplied provided that such tubing meets all other requirements of this specification.
Large Diameter ASTM A213 Stainless Steel 304L Seamless Pipe is used in a variety of applications and industries including food and beverage processing, petrochemical and construction. ASTM A213 Stainless Steel Tube includes ASTM A213 TP304L Stainless Steel Square Tube, ASTM A213 TP304L Stainless Steel Oval Tube, ASTM A213 TP304L Stainless Steel Rectangular Tube, ASTM A213 TP304L Heat Exchanger Tube, ASTM A213 TP304L Stainless Steel Condenser Tube, ASTM A213 TP304L Stainless Steel Superheater Tube and ASTM A213 TP304L Stainless Steel Rectangular Tube A213 TP304L stainless steel round tube, custom shapes and sizes available. ASTM A213 TP304L heat exchange tubes have excellent corrosion resistance at normal temperature and normal atmospheric conditions and can withstand some natural acids, which is why this grade is often used in the food and beverage processing industry.
Material Grade:
| Grade | UNS Designation | Carbon | Manganese | Phosphorus | Sulfur | Silicon | Chromium | Nickel | Molybdenum | Nitrogen | Niobium | Titanium | Other Elements |
| TP304 | S30400 | 0.08 | 2.00 | 0.045 | 0.030 | 1.00 | 16.0-20.0 | 8.0-11.0 | -- | -- | -- | -- | -- |
| American Standard |
Austenitic Steel: TP304, TP304L, TP304H, TP304N, TP310S, TP316, TP316L, TP316Ti, TP316H, TP317, TP317L, TP321, TP321H, TP347, TP347H, 904L… Duplex Steel : S31803, S32101, S32205, S32304, S32750, S32760 Others: TP405, TP409, TP410, TP430, TP439,... |
| Europen Standard | 1.4162, 1.4301, 1.4307,1.4362, 1.4401, 1.4404, 1.4410, 1.4438, 1.4462, 1.4501, 1.4539, 1.4541, 1.4550, 1.4571, 1.4841, 1.4845,1.4878, 1.4948, |
| GOST Standard | 08Х17Т, 08Х13, 12Х13, 12Х17, 15Х25Т, 04Х18Н10, 08Х20Н14С2, 08Х18Н12Б, 10Х17Н13М2Т, 10Х23Н18, 08Х18Н10, 08Х18Н10Т, 08Х18Н12Т, 08Х17Н15М3Т, 12Х18Н10Т, 12Х18Н12Т, 12Х18Н9, 17Х18Н9, 08Х22Н6Т, 06ХН28МДТ |
| Grade | Tensile Strength (MPa) min | Elongation (% in 50mm) min | Yield Strength 0.2% Proof (MPa) min | Hardness | |
| Rockwell B (HR B) max | Brinell (HB) max | ||||
| SS 304 | 515 | 40 | 205 | 92 | 201 |
Size Range:
| Production | Outside Diameter | Wall Thickness |
| Seamless Pipe | 6.00mm-830mm | 0.5mm-48mm |
The tubing sizes and thicknesses usually furnished to this specification are 1⁄8 in. [3.2 mm] in inside diameter to 5 in. [127 mm] in outside diameter and 0.015 to 0.500 in. [0.4 to 12.7 mm], inclusive, in minimum wall thickness or, if specified in the order, average wall thickness. Tubing having other diameters may be furnished, provided such tubes comply with all other requirements of this specification.
Application:
