ASTM A213 TP304 Stainless Steel Seamless Tube
YUHONG GROUP is a leading manufacturer of high-quality ASTM A213/ASME SA213 TP304/304L pipes. These seamless tubes are specifically designed for boiler, heat exchanger, and superheater applications in demanding industrial environments.
Product Specifications
Material Composition
| Grade |
UNS Designation |
Carbon |
Manganese |
Phosphorus |
Sulfur |
Silicon |
Chromium |
Nickel |
| TP304 |
S30400 |
0.08 |
2.00 |
0.045 |
0.030 |
1.00 |
16.0-20.0 |
8.0-11.0 |
Mechanical Properties
| Grade |
Tensile Strength (MPa) min |
Elongation (% in 50mm) min |
Yield Strength 0.2% Proof (MPa) min |
Rockwell B (HR B) max |
Brinell (HB) max |
| SS 304 |
515 |
40 |
205 |
92 |
201 |
Size Range
| Production |
Outside Diameter |
Wall Thickness |
| Seamless Pipe |
6.00mm-830mm |
0.5mm-48mm |
Standard tubing sizes range from 1/8 in. [3.2 mm] ID to 5 in. [127 mm] OD with wall thickness from 0.015 to 0.500 in [0.4 to 12.7 mm]. Custom diameters are available upon request, provided they meet all specification requirements.
Applications
- Food processing equipment (beer brewing, milk processing, wine making)
- Kitchen benches, sinks, and appliances
- Building paneling, railings, and decoration
- Chemical containers and transportation equipment
- Heat exchangers and boilers
- Mining, quarrying, and water filtration screens
- Threaded fasteners and springs
Available Standards
American Standard: TP304, TP304L, TP304H, TP304N, TP310S, TP316, TP316L, TP316Ti, TP316H, TP317, TP317L, TP321, TP321H, TP347, TP347H, 904L, and duplex steels including S31803, S32101, S32205, S32304, S32750, S32760
European Standard: 1.4162, 1.4301, 1.4307, 1.4362, 1.4401, 1.4404, 1.4410, 1.4438, 1.4462, 1.4501, 1.4539, 1.4541, 1.4550, 1.4571, 1.4841, 1.4845, 1.4878, 1.4948
