ASTM A182 F60 1.4462 S32205 Duplex Steel SWRF Forged Flange B16.5

ASTM A182 F60 1.4462 S32205 Duplex Steel SWRF Forged Flange B16.5


The socket welding flange is similar to a slip-on flange, except it has a bore and a counterbore dimension.The counterbore is slightly larger than the O.D. of the matching pipe, allowing the pipe to be inserted into the flange similar to a slip-on flange. The diameter of the smaller bore is the same as the I.D. of the matching pipe. A restriction is built into the bottom of the bore which sets as a shoulder for the pipe to rest on. This eliminates any restriction in flow when using a socket welding flange.

YUHONG is a renowned supplier of superior quality Duplex Steel F60 Flanges. We are offering all types of duplex stall flanges in various grades, standards, sizes, dimensions and specifications that meet the exact demands of our esteem customers. Our proposed Duplex Steel F60 Flanges have superior resistance to general corrosion and pitting. Duplex steel has both ferritic and austenitic microstructure.

Our offered flanges are used to connect valves, pipes and other equipment by avoiding leakages. Duplex Steel F60 Flanges are highly resistive to sulfide corrosion, crevice cracking, stress corrosion cracking and chloride attacks. The excellent mechanical strength and toughness make these duplex flanges capable of sustaining in hostile environments.


F60 Equivalent:



Mechanical Properties of F60 Flange:



F60 Chemical Composition:






Applications:

• Chemical processing
• Desalination plants
• Oil and gas exploration and production
• Geothermal wells
• Seawater and other chloride-containing environments
• Salt evaporation
• Pulp and paper production
• Oil and Gas - refining, petrochemical and gas processing application
• Seawater cooling
