ASTM A213 TP304L Stainless Steel Seamless Tubes For Heat Exchangers Chemical

ASTM A213 TP304L Stainless Steel Seamless Tubes For Heat Exchangers Chemical

  • ASTM A213 TP304L Stainless Steel Seamless Tubes For Heat Exchangers Chemical
  • ASTM A213 TP304L Stainless Steel Seamless Tubes For Heat Exchangers Chemical
  • ASTM A213 TP304L Stainless Steel Seamless Tubes For Heat Exchangers Chemical
  • ASTM A213 TP304L Stainless Steel Seamless Tubes For Heat Exchangers Chemical
ASTM A213 TP304L Stainless Steel Seamless Tubes For Heat Exchangers Chemical
Product Details:
Place of Origin: CHINA
Brand Name: YUHONG GROUP
Certification: ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number: TP304
Payment & Shipping Terms:
Minimum Order Quantity: 1PC
Price: Negotiation
Packaging Details: Bundle /Ply-wooden Case
Delivery Time: Depends on quantity
Payment Terms: L/C, T/T
Supply Ability: 10000 Ton/month
Contact Now
Detailed Product Description
Material Grade: TP304L Standard: ASTM A213
Size: 6 – 530mm W.T.: 0.50 – 64mm
Length: 1000mm-12500mm NDT: ET HT UT PT
Packing: Ply-wooden Case /Iron Case/ Bundle Appllication: Heat Exchanger/ Chemical
High Light:

TP304L Stainless Steel Round Tube

,

Chemical Stainless Steel Seamless Tubes

,

Heat Exchangers Seamless Stainless Steel Pipe



ASTM A213 TP304L Stainless Steel Seamless Tubes For Heat Exchangers Chemical





ASTM A213 A312 A269 A511 A240 UNS S30403 304L, EN 10216-5 1.4307 stainless steel tubing is a variant of the 18% chromium - 8% nickel austenitic alloy that is the most familiar and frequently used alloy in the stainless steel family. This alloy can be considered for a wide range of applications and exhibits good corrosion resistance, ease of fabrication, excellent malleability, high strength with low weight. type 304L is a lower carbon variant of grade 304 - the steel can be welded without causing problems with carbon precipitation of chromium carbide, as the steel is depleted of chromium during the welding process, thus reducing its effectiveness against corrosion/oxidation, and due to the low carbon percentage. intergranular corrosion attack can be minimized.

Therefore, Type 304L seamless pipe is a sort after material for use in severe corrosive conditions. Welding annealing is only necessary if the stress load is excessive in the application. This steel grade is found in various commercial sectors, especially in the chemical industry. 304 and 304L have similar properties and in some cases are stocked with dual certification, it is concluded that the properties and composition of each item conform to both types of steel. 304H grade cannot be included in this equation because of the higher carbon content of the steel, intended for high temperature applications.





Chemical Composition of ASTM A213 TP304L Stainless Steel Seamless Tubes







Grade C Mn Si P S Cr Mo Ni N
304L/S30403 min.max. -0.035 -2 -1 -0.045 -0.03 18.0-20.0 8.0-12.0
304/S30400 min.max. -0.08 -2 -1 -0.045 -0.03 18.0-20.0 8.0-11.0
EN 10216-5 1.4301 min.max. -0.07 -2 -1 -0.04 -0.015 17.00-19.5 8.0-10.5 -0.11
EN 10216-5 1.4307 min.max. -0.03 -2 -1 -0.04 -0.015 17.5-19.5 8.0-10.0 -0.11
304H /S30409 min.max. 0.04-0.10 -2 -1 -0.045 -0.03 18.0-20.0 8.0-11.0
EN 10216-5 1.4948 min.max. 0.04-0.08 -2 -1 -0.035 -0.015 17.0-19.0 8.0-11.0 -0.11





Mechanical Property of ASTM A213 TP304L Stainless Steel Seamless Tubes





Tensile Strength Yield Strength Elongation Hardness Hardness
Grade (MPa) min 0.2% Proof (MPa) min (% in 50mm) min Rockwell B (HR B) max Brinell (HB) max
304 515 205 35 90 192
304L 485 170 35 90 192







Physical Properties Of  ASTM A213 TP304L Stainless Steel Seamless Tubes





304L Stainless Steel Pipe Density (lb / cu. in.) 0.29
Specific Gravity(kgs/dm³) 7.93
Specific Heat (Btu/lb/Deg°F – [32-212 Deg °F]) 0.12
Electrical Resistivity (microhm-cm (at 68 Deg °F)) 432
Melting Point (Deg°F) 2650
Modulus of Elasticity Tension 28







ASTM A213TP304L Stainless Steel Seamless Tubes APPLICATION



Gas Processing

Petrochemical

Power Generation

Food Processing

Chemical

Oil & Gas
