Nickel Alloy Seamless Tube B163 NO8825 Incoloy825 Bright Annealed

Nickel Alloy Seamless Tube B163 NO8825 Incoloy825 Bright Annealed

  • Nickel Alloy Seamless Tube B163 NO8825 Incoloy825 Bright Annealed
  • Nickel Alloy Seamless Tube B163 NO8825 Incoloy825 Bright Annealed
  • Nickel Alloy Seamless Tube B163 NO8825 Incoloy825 Bright Annealed
  • Nickel Alloy Seamless Tube B163 NO8825 Incoloy825 Bright Annealed
Nickel Alloy Seamless Tube B163 NO8825 Incoloy825 Bright Annealed
Product Details:
Place of Origin: CHINA
Brand Name: YUHONG
Certification: ABS, BV, DNV-GL , PED, TUV, LR, KR, NK, CCS.
Model Number: ASTM B163 UNS NO8825
Payment & Shipping Terms:
Minimum Order Quantity: 500kgs
Price: NEGOTIABLE
Packaging Details: Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Delivery Time: Depending on QTY
Payment Terms: L/C at sight, T/T
Supply Ability: 50tons per month
Contact Now
Detailed Product Description
Standard: ASTM B163/ASME SB163 Material: NO8825/ALLOY 825
Testing: ET, HT, Mechinal Property&Chemical Composition Test Type: Seamless
Application: Steam Turbine, Heat Exchanger, Boiler... Surface: Bright Annealed
High Light:

Bright Annealed Nickel Alloy Seamless Tube

,

B163 Nickel Alloy Seamless Tube

,

Incoloy825 Bright Annealed Tube

BRIGHT ANNEALED NICKEL ALLOY SEAMLESS TUBE B163 NO8825 ALLOY 825







NO8825 is a high alloy corrosion-resistant and high-temperature stainless steel material, also known as Inconel 825. It is mainly composed of elements such as nickel, chromium, copper, and molybdenum, and has characteristics such as high strength, high corrosion resistance, and high temperature performance.
NO8825 is widely used in heating pipes, containers, baskets, and chains used in sulfuric acid pickling plants. Seawater cooling heat exchanger, marine product pipeline system, acidic gas environment pipeline. Heat exchangers, evaporators, washing, impregnation tubes, etc. in the production of phosphoric acid. Air heat exchangers in petroleum refining, food engineering, chemical processes.





Incoloy825 Advantages:

  • Strong corrosion resistance: NO8825 has good corrosion resistance in various corrosive media such as acid, alkaline, seawater, and sulfuric acid.
  • Good high-temperature performance: NO8825 can operate stably in high-temperature environments.
  • Good weldability: NO8825 has excellent weldability and can be used for various processing methods.



Incoloy825 Characteristics:

  • Good stress corrosion cracking resistance
  • Good resistance to spot corrosion and crevice corrosion
  • Excellent antioxidant and non oxidative thermal acid properties
  • Excellent mechanical properties at room temperature and high temperatures up to 550 ℃
  • Certification for pressure vessels with manufacturing temperatures up to 450 ℃


NO8825 Chemical Composion



Element %
Nickel 38.0-46.0
Chromium 19.5-23.5
Molybdenum 2.5-3.5
Copper 1.5-3.0
Titanium 0.6-1.2
Iron 22.0 min (~33%)
Carbon 0.05 max
Manganese 1.0 max
Sulphur 0.03 max
Silicon 0.5 max
Aluminium 0.2 max




NO8825 Physical Properties



Density / Specific Gravity 8.1 kg/m³ 0.30 lb/in³
Melting point 1370-1400




NO8825 Mechanical Properties



Alloy state Tensile strength Yield strength Elongation Brinell hardness
Rm N/mm² R P0. 2N/mm² A 5 % HRB Max
N08825 517 172 30 200
Hot Finished
N08825 586 241 30 200
Cold Finished



Application

  • Sulphuric acid piping and vessels
  • Phosphoric acid evaporators
  • Pickling tank heaters
  • Pickling tanks and equipment
  • Chemical process equipment
  • Propellor shafts
  • Tank trucks
  • Calorifiers
  • Electrostatic precipitator electrodes
  • Hot vessels for food
  • Water and seawater
  • Ammonium sulphate vessels
  • Expansion bellows
  • Marine exhaust systems
  • Power station ash hoppers





Nickel Alloy Seamless Tube B163 NO8825 Incoloy825 Bright Annealed 0
