Yuhong Holding Group Co.,LTD
Place of Origin: | CHINA |
Brand Name: | YUHONG |
Certification: | API, PED,DNV, ABS, LR, BV |
Model Number: | A420/SA420 WPL3 |
Minimum Order Quantity: | 1PC |
---|---|
Price: | Negotiable |
Packaging Details: | PLY-WOODEN CASE OR WOODEN PALLET |
Delivery Time: | Depending on QTY |
Payment Terms: | T/T, L/C AT SIGHT |
Supply Ability: | 10000 PCS PER MONTH |
Standard: | ASTM A420 / ASME SA420 | Material Grade: | WPL3 |
---|---|---|---|
Technics: | Butt Weld | Shape: | Elbow |
Size: | DN8 TO DN 100 | Packing: | Pallet / Ply-Wooden Case |
Overview
ASTM A420 WPL3 elbow is a pipe fitting used for turning high-pressure pipelines at different angles. The proportion of all fittings used in high-pressure pipeline systems is large, about 80%. The wall thickness of high-pressure elbows is generally thicker than that of ordinary elbows, or the compressive strength of the material is higher than that of ordinary elbows.
ASTM A420 WPL3 elbows are suitable for pipeline systems in industries such as petroleum, natural gas, chemical, water and electricity, construction, and boilers. They do not require pipe blanks as raw materials, which can save on pipe making equipment and mold costs. They can be used for any large diameter and thinner elbows, and are suitable for on-site processing of large standard elbows. They are used as flat or developable surface blanks, making them simple to cut and easy to protect accuracy. Convenient assembly and welding.
Characteristics of A420 WPL3 elbow
A420 WPL3 elbow production process:
Chemical Composition of WPL3 Buttweld Fittings
Grade |
C |
Mn |
P |
S |
Si |
Ni |
Cr |
Mo |
Cu |
Cb |
V |
A420 WPL3 |
0.3 |
0.050-1.35 |
0.035 |
0.04 |
0.15-0.40 |
0.4 |
0.3 |
0.12 |
0.4 |
0.02 |
0.08 |
Mechanical Properties of WPL3 Buttweld Fittings
Grade |
Tensile Strength (Mpa) |
Yield Strength (Mpa) |
A420 WPL3 |
60-95 |
35 |
Applied Industries:
