Copper Nickel Tube Admiralty Bass Tube ASTM B111 C70600 C68700 C44300 Heat exchangers, Condensers, Cooling systems Application

Product Details:

Place of Origin:	CHINA
Brand Name:	YUHONG HOLDING GROUP
Certification:	ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number:	ASME B111 C44300 SB 395

Payment & Shipping Terms:

Minimum Order Quantity:	500KGS
Price:	Negotiable
Packaging Details:	Wooden Box package
Delivery Time:	10-15 DAYS
Payment Terms:	L/C, T/T
Supply Ability:	1000Ton per month

Contact Now

All Products

Stainless Steel Seamless Pipe (286)

Stainless Steel Seamless Tube (275)

Duplex Stainless Steel Pipe (127)

Duplex Stainless Steel Tube (28)

Needle Tube (102)

Fin Tube (619)

Heat Exchanger (16)

Heat Exchanger Tube (425)

Heat Exchanger Tube Bundle (37)

Heat Exchanger Tubesheet (116)

Heat Exchanger Baffle (36)

Air Cooler (8)

Pressure Vessel (4)

Stainless Steel Welded Pipe (57)

Stainless Steel Welded Tube (112)

Nickel Alloy Pipe (259)

Nickel Alloy Tube (78)

Copper Alloy Tube (222)

Alloy Steel Tube (182)

Titanium Tube (10)

Bright Annealed Tube (153)

Boiler Tube (141)

Steel Fitting (797)

Steel Flange (583)

Others (388)

Cladding Parts (7)

Detailed Product Description

Name:	Straight Copper Seamless Tube	Material:	C44300 C70600 C68700
Diameter:	3mm-500mm	Thickness:	0.5mm-10mm
Processing:	Bending, Decoiling, Welding, Punching, Cutting	Application:	Heat Exchangers, Condensers, And Cooling Systems; Desalination Equipment.

Copper Nickel Tube Admiralty Bass Tube ASTM B111 C70600 C68700 C44300 Heat exchangers, Condensers, Cooling systems Application

ASME SB111 and ASTM B111 are internationally recognized standards that specify the requirements for seamless copper alloy tubes commonly used in heat exchangers, condensers, and similar applications. The C68700 alloy, also known as Aluminum Brass, is a high-performance copper-zinc alloy with excellent corrosion resistance and mechanical properties.

Copper Alloy Tube chemical Requirement:

Copper or Copper Alloy UNS No.	CopperA	Tin	Aluminum	Nickel, incl Cobalt	Lead, max	Iron	Zinc	Managnese	Arsenic	Antimony	Phosphorus	Chro mium	Other Named Elements
C10200	99.95 min	-	-	-	-	-	-	-	-	-	-	-	-
C12000	99.90 min	-	-	-	-	-	-	-	-	-	0.004-0.012	-	-
C12200	99.9 min	-	-	-	-	-	-	-	-	-	0.015-0.040	-	-
C14200	99.40 min	-	-	-	-	-	-	-	0.15-0.50	-	0.015-0.040	-	-
C19200	98.7 min	-	-	-	-	0.8-1.2	-	-	0.15-0.50	-	0.01-0.04	-	-
C23000	84.0-86.0	-	-	-	0.05	0.05 max	remalnder	-	-	-	-	-	-
C28000	59.0-63.0	-	-	-	0.30	0.07 max	remainder	-	-	-	-	-	-
C44300	70.0-73.0	0.9-1.2	-	-	0.07	0.06 max	remainder	-	0.02-0.06	-	-	-	-
C44400	70.0-73.0	0.9-1.2	-	-	0.07	0.06 max	remainder	-	-	0.02-0.10	-	-	-
C44500	70.0-73.0	0.9-1.2	-	-	0.07	0.06 max	remainder	-	-	-	0.02-0.10	-	-
C60800	remainder	-	5.0-6.5	-	0.10	0.10 max	-	-	0.02-0.35	-	-	-	-
C68700	76.0-79.0	-	1.8-2.5	-	0.07	0.06 max	remainder	-	0.02-0.10	-	-	-	-
C70400	remainder	-		4.8-6.2	0.05	1.3-1.7	1.0max	0.30-0.8	-	-	-	-	-
C70600	remainder	-		9.0-11.0	0.05B	1.0-1.8	1.0maxB	1.0max	-	-	B	-	B
C71000	remainder	-		19.0-23.0	0.05B	0.50-1.0	1.0maxB	1.0max	-	-	B	-	B
C71500	remainder	-		29.0-33.0	0.05B	0.40-1.0	1.0maxB	1.0max	-	-	B	-	B
C71640	remainder	-		29.0-32.0	0.05B	1.7-2.3	1.0maxB	1.5-2.5	-	-	B	-	B
C72200	remainder	-		15.0-18.0	0.05B	0.50-1.0	1.0maxB	1.0max	-	-	B	0.30 -0.70	B

Copper Alloy Tube diameter Tolerance :

Outside Diameter, in	Wall Thickness, in.
	0.020A 0.022 0.025 0.028	0.032	0.035	0.042	0.049 and Over
	Diameter Tolerance, Plus and Minus, in.
Up to 0.500, incl	0.003	0.0025	0.0025	0.0025	0.0025
Over 0.500-0.740, incl	0.0040	0.004	0.004	0.0035	0.003
Over 0.500-7.40, incl	0.0060	0.006	0.005	0.0045	0.004
Over 0.740-1.000, incl	...	0.009	0.008	0.006	0.045
Over 1.250-1.375, incl	...	...	...	0.008	0.005
Over 1.375-2.000, incl	...	...	...	...	0.006

A Tolerances in this column are applicable to light drawn and drawn tempers only.
Tolerances for annealed tempers shall be as agreed upon between the manufacturer and the purchaser.

Copper Alloy Seamless Tube Wall Thickness Tolerance ,

Wall Thicness, in.	Outside Diameter, in.
Wall Thicness, in.	Over ? to ?, incl	Over ? to 1, incl	Over 1 to 2, incl
0.020, incl to 0.032	0.003	0.003	...
0.032, incl to 0.035	0.003	0.003	0.004
0.035, incl to 0.058	0.004	0.0045	0.0045
0.058, incl to 0.083	0.0045	0.005	0.005
0.083, incl to 0.120	0.005	0.0065	0.0065
0.120, incl to 0.134	0.007	0.007	0.0075

Product Name	Hollow Brass Tube H62 C28000 C44300 c68700 Brass Pipe
Material	Brass:C21000,C22000,C22600,C23000,C24000,C26000,C26130,C26800, C27000,C27200,C27400,C2800,H59,H62,H70,H65,H80,H90,CuZn30, CuZn37,CuZn35,CuZn40,etc Leaded brass: C31400,C31600,C32000,C33000,C33200,C33500,C34000,C34200, C34500,C35000,C35300,C35600,C36000,C36500,C37000,C37700,C38000,C38500,etc Tin brass: C40500,C40800,C41100,C42200,C44400,C48200,C46400,C46200 Aluminium bronze:C60600,C62300,C62400,C63000,C63200,C64200,etc Nickel copper:C71000,C71500,C70400,C70600,C70250,C70260,C71520 C72200,C74500,C75200,C77400,etc Phosphor bronze:C50500,C51100,C52100,C51980,etc
Size	Outside Diamter 2~914mm Wall thickness 0.2-120mm Length 1~12meters
Hardness	1/16 hard,1/8 hard,1/4 hard,1/2hard,full hard
Surface	mill,polished,bright,hair line,mirror,brush,sand blast,etc
Price Term	x-Work,FOB,CNF,CFR,CIF,FCA,DDP,DDU,etc
Payment Term	TT,L/C,Western Union,D/P,etc
Used	Brass pipe have strong, corrosion resistant properties, and become a modern contractor in all ofcommodity house pipes,heating, cooling water piping installation of choice
Export to	Ireland,Singapore,Indonesia,Ukraine,Saudi Arabia,Spain,Canada,USA,Brazil, Thailand,Korea,Russia,Chile,India,Egypt,Oman,Kuwait,Egypt,VietNam, England,Holland,Mexico,Peru,Malaysia,Italy,Nigeria,etc
Package	Standard export package,suit for all kinds of transport,or as required.
Container Size	20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High) 40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High) 40ft HC:12032mm(Length)x2352mm(Width)x2698mm(High)
