| Place of Origin: | CHINA, KOREA |
| Brand Name: | YUHONG |
| Certification: | ASME, ASTM, ASME U Stamp |
| Model Number: | TUBE BUNDLE, TUBESHEET |
| Minimum Order Quantity: | 1 SET |
|---|---|
| Price: | 0-1000000USD |
| Packaging Details: | Wooden export crates |
| Delivery Time: | 30-60DAYS |
| Payment Terms: | T/T, L/C, D/A |
| Supply Ability: | 15 SETS/MONTH |
| Tube: | ASME SA213 TP316L | Tubesheet: | ASTM A350 GRADE LF2 CLASS 1 |
|---|---|---|---|
| Baffles: | A/SA 516 Gr.70+N | Rods: | ASTM A194 Grade 2H |
| Spacers: | ASME SA213 TP316L | Support Plate: | SA516 GR.70N |
ASME SA213 TP316L Straight Tube bundle in Shell and Tube Heat Exchanger
We specialize in manufacturing Shell & Tube Heat Exchangers, Oil Coolers, Steam Heaters, Air Preheaters, Finned Tube Coolers, Finned Tube Heaters, Cooling Towers, Cooling Equipment, Condensers, Air Receivers, Blast Furnace Oil Coolers, Hot Air Generators, Industrial Heat Exchangers, Evaporators, Heat Exchanger Coils, Radiators, Pressure Vessels, Wound Finned Tubes/Coolers, Extruded Finned Tubes, Rectangular/Square finned tubes, and all other heat transfer products.
| YUHONG GROUP Heat Exhanger Tube bundle parts- 081-E-0001 A/B/C | |||||||
| NO. | POS | DESPRITION | SIZE | MATERIAL | OVERLAY CLADDING | QUANTITY | |
| A | A--0 | Seamless TUBE | Ø19.05×2.11(min) x7315mm | ASME SA213 TP316L | / | 2490 | PCS |
| 11 | 3-1 | S.T. TUBE SHEET | Ø997×81mmT | SA350 LF2 CL1N | 8MM SS316L | 3 | PC |
| 12 | 3-2 | F.L. TUBE SHEET | Ø926×81mmT | SA350 LF2 CL1N | 8MM SS316L | 3 | PC |
| 17 | 4-5 | GASKET | Ø926×4mmT | SS316L+GRAPHITE | / | 9 | PCS |
| 21 | 5-4 | STUD B./2H.N | 1-8UNC×395L | SA320-L7/SA194-2H | / | 108 | PCS |
| 22 | 5-5 | SQ. STUD B./2H.N | 1-8UNC×445L | SA320-L7/SA194-2H | / | 33 | PCS |
| 27 | 7-1 | F.T H.D FLANGE | Ø1026×Ø894×100mmT | SA350 LF2 CL1N | 3MM SS316L | 3 | PC |
| 28 | 7-2 | F.T H.D COVER | Ø894×25mmT | SA516 GR.70N | 3MM SS316L | 3 | PC |
| 29 | 7-3 | BACKING RING | Ø1026×Ø894×167mmT | SA350 LF2 CL1N | / | 3 | PC |
| 32 | 10 | CONNECTION PIECES | Ø1018×Ø914×27mT | SA516 GR.70N | / | 6 | PCS |
| 33 | 1-1 | BAFFLE | Ø935.2×649.2×10mmT | SA516 GR.70N | / | 3 | PC |
| 34 | 1-2 | BAFFLE | Ø935.2×649.2×8mmT | SA516 GR.70N | / | 21 | PCS |
| 35 | 1-3 | BAFFLE | Ø935.2×649.2×10mmT | SA516 GR.70N | / | 3 | PC |
| 36 | 1-4 | BAFFLE | Ø935.2×649.2×8mmT | SA516 GR.70N | / | 21 | PCS |
| 37 | 1-5 | SUPPORT PLATE | Ø935.2×16mmT | SA516 GR.70N | / | 3 | PC |
| 38 | 3 | TIE ROD / NUTS | Ø13×6869mmL | SA36/194-2H | / | 24 | PCS |
| 39 | 4-1 | SEALING STRIP | 8×27×5579mmL | SA516 GR.70N | / | 12 | PCS |
| 40 | 4-2 | SEALING STRIP | 8×56.5×5579mmL | SA516 GR.70N | / | 6 | PCS |
| 41 | 5 | SLIDING SHOE | 16×41×6843mmL | SA516 GR.70N | / | 6 | PCS |
| 42 | 6 | IMPINGEMENT PLATE | T=12mm | SA516 GR.70N | / | 3 | PC |
| 43 | 7-1 | LIFTING LUG | 16×80×190 | SA516 GR.70N | / | 6 | PCS |
| 44 | 7-2 | LIFTING LUG | 16×80×190 | SA516 GR.70N | / | 6 | PCS |
| 45 | 7-3 | LIFTING LUG | 16×80×140 | SA516 GR.70N | / | 9 | PCS |
| 46 | 7-4 | LIFTING LUG | 16×95×170 | SA516 GR.70N | / | 12 | PCS |
| 47 | 7-5 | LIFTING LUG | 25×110×160 | SA516 GR.70N | / | 12 | PCS |
| 48 | 7-6 | LIFTING LUG | T=25mm | SA516 GR.70 | / | 12 | PCS |
| 49 | 7-7 | RIB PLATE | T=25mm | SA516 GR.70 | / | 12 | PCS |
| 50 | 7-8 | REINFORANCE PAD | T=14mm | SA516 GR.70 | / | 12 | PCS |
| 51 | 9-1 | EYE BOLT | M36×P4 | SA36 | / | 12 | PCS |
| 52 | 9-2 | PLUG | M36×P4×75 | SS304 | / | 12 | PCS |
| 53 | 10 | CENTERING PIN LUG | T=25mm | SA516 GR.70 | / | 6 | PCS |
| A | HEAT TREATMENT | ||||||
| B | HYDROSTATIC TEST | ||||||
| A | HARDNESS TEST | ||||||
| B | MECHANICAL PROPERTY | ||||||
| A | CHEMICAL ANALYSIS REPORT | ||||||
| B | WELDING PROCEDURE SPECIFICATIONS | ||||||
