Yuhong Holding Group Co.,LTD
 |
| Place of Origin: | China |
| Brand Name: | YUHONG |
| Certification: | ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2015 |
| Model Number: | ASTM A335 P9 11R |
| Minimum Order Quantity: | 500KGS |
|---|---|
| Price: | NEGOTIABLE |
| Packaging Details: | Ply-wooden Case /Iron Case/ Bundle with plastic Cap |
| Delivery Time: | 10-90 Days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | According To Client's Request |
| Standard: | ASTM A335 | Size: | Customized |
|---|---|---|---|
| Tube Wall Thickness: | Customized | Fin Material: | P9 11R |
| Tube/Pipe Size: | 16-219MM | Fin Tube Length: | No Practical Limit |
| Finned Height: | ＜17MM | Fin Type: | 1 To 7 Fins Per Inch |
| FinPitch: | 2.1-5MM | ||
| High Light: | oil Refining condenser SERRATED FIN TUBE,P9 11R SERRATED FIN TUBE |
||
The serrated finned tube is produced using high-frequency welding technology and has high-frequency patented technology. Using high-frequency power as the heat source, the steel strip and steel pipe are heated and welded together at the same time. It has the characteristics of long life, wide operating temperature range and high voltage resistance.
Serrations are small grooves or notches cut into the surface of the fins that disrupt the boundary layer and increase turbulence in the fluid flowing through the fins. This increased turbulence enhances convective heat transfer between the pipes and fluid, resulting in a more efficient heat exchanger. Serrated finned tubes are commonly used in applications requiring high thermal performance such as boilers, air-cooled condensers and other heat exchangers.
Specification
| Type | Description | Base tube O.D. (mm) |
Fin specification (mm) | ||
| Fin pitch | Fin height | Fin thick | |||
| Embedded | G-type fin tube | 16-63 | 2.1-5 | <17 | ~0.4 |
| Extruded | Single metal combined metal | 8-51 | 1.6-10 | <17 | 0.2-0.4 |
| Low fin tube t-type fin tube | 10-38 | 0.6-2 | <1.6 | ~0.3 | |
| Bamboo tube corrugated tube | 16-51 | 8-30 | <2.5 | / | |
| Wound | l/kl/ll type fin tube | 16-63 | 2.1-5 | <17 | ~0.4 |
| String | String fin tube | 25-38 | 2.1-3.5 | <20 | 0.2-0.5 |
| U-type | U-type tube | 16-38 | / | / | / |
| Welding | HF-welding fin tube | 16-219 | 3-25 | 5-30 | 0.8-3 |
| H/HH type fin tube | 25-63 | 8-30 | <200 | 1.5-3.5 | |
| Studed fin tube | 25-219 | 8-30 | 5-35 | φ5-20 | |
| Fin material | N° fins per meter | Strip thickness | Production capacity |
| All type of material | From 50 to 500 | From 0,4mm. to 0,5mm. | More than 500 meters per day |
| Tube material | Tube thickness | O.D. tube | Lenght available |
| All type of material | 1,00mm. minimum | From 10,00mm. to 200,00mm. |
All lenghts up to 8 Meters |
