HFW Finned Tube ASTM A213 T12 Alloy Stainless Steel Tube TP304 Fin for Power Plant

HFW Finned Tube ASTM A213 T12 Alloy Stainless Steel Tube TP304 Fin for Power Plant

  • HFW Finned Tube ASTM A213 T12 Alloy Stainless Steel Tube TP304 Fin for Power Plant
  • HFW Finned Tube ASTM A213 T12 Alloy Stainless Steel Tube TP304 Fin for Power Plant
  • HFW Finned Tube ASTM A213 T12 Alloy Stainless Steel Tube TP304 Fin for Power Plant
  • HFW Finned Tube ASTM A213 T12 Alloy Stainless Steel Tube TP304 Fin for Power Plant
  • HFW Finned Tube ASTM A213 T12 Alloy Stainless Steel Tube TP304 Fin for Power Plant
HFW Finned Tube ASTM A213 T12 Alloy Stainless Steel Tube TP304 Fin for Power Plant
Product Details:
Place of Origin: China
Brand Name: Yuhong
Certification: ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number: ASTM A213
Payment & Shipping Terms:
Minimum Order Quantity: 1000KGS
Price: Negotiable
Packaging Details: Ply-wooden Case /Iron Case/ Bundle With Plastic Cap
Delivery Time: 10 Days
Payment Terms: L/C, T/T
Supply Ability: 500 Tons Per Month
Contact Now
All Products
Stainless Steel Seamless Pipe (242)
Stainless Steel Seamless Tube (237)
Finned Tube (453)
Heat Exchanger Tube (162)
Heat Exchanger Parts (169)
Stainless Steel Welded Pipe (50)
Stainless Steel Welded Tube (98)
Duplex Stainless Steel Pipe (135)
Alloy Steel Tube (129)
Bright Annealed Tube (152)
Copper Alloy Tube (169)
Nickel Alloy Pipe (309)
Needle Tube (26)
U Bend Tube (189)
Boiler Tube (110)
Steel Fitting (664)
Steel Flange (477)
Steel Valves (12)
Precision Steel Strip (29)
Alloy Wires (271)
Others (61)
Detailed Product Description
Type: Fined Tube Name: HFW Finned Tube
Standard: ASTM Package: Plywood Case With Steel Frame
FPI: 3-25mm Fin Height: 5-30mm
Application: Heat Exchanger, Cooler, Fluid Cooling
High Light:

Alloy Stainless Steel Tube TP304

,

Alloy Steel HFW Fin Tube

,

Power Plant HFW Finned Tube

HFW Finned Tube ASTM A213 T12 Alloy Stainless Steel Tube TP304 Fin for Power Plant



This welded steel finned tube configuration can be used in virtually any heat exchanger application and is particularly suitable for high temperature and high pressure applications. The important features of this configuration are the efficient and effective connection of the fin to the tube under all temperature and pressure conditions and the ability to withstand high temperatures on the fin side.



A continuous helical fin is attached to the base tube by means of high-frequency electrical resistance welding in order to provide an efficient and thermally reliable connection.

Main chemical composition(%)



Grade UNS Designation C Mn P S

Si
T2 K11547 0.10–0.20 0.30–0.61 0.025 0.025B 0.10–0.30
T5 K41545 0.15 0.30–0.60 0.025 0.025 0.5
T5b K51545 0.15 0.30–0.60 0.025 0.025 1.00–2.00
T5c K41245 0.12 0.30–0.60 0.025 0.025 0.5
T9 K90941 0.15 0.30–0.60 0.025 0.025 0.25–1.00
T11 K11597 0.05–0.15 0.30–0.60 0.025 0.025 0.50–1.00
T12 K11562 0.05–0.15 0.30–0.61 0.025 0.025B 0.5
T17 K12047 0.15–0.25 0.30–0.61 0.025 0.025 0.15–0.35
T21 K31545 0.05–0.15 0.30–0.60 0.025 0.025 0.50–1.00
T22 K21590 0.05–0.15 0.30–0.60 0.025 0.025 0.5
T23 K40712 0.04–0.10 0.10–0.60 0.03 0.01 0.5
T24 K30736 0.05–0.10 0.30–0.70 0.02 0.01 0.15–0.45
T36 K21001 0.10–0.17 0.80–1.20 0.03 0.025 0.25–0.50
T91 K90901 0.07–0.14 0.30–0.60 0.02 0.01 0.20–0.50
T92 K92460 0.07–0.13 0.30–0.60 0.02 0.01 0.5
T122 K91271 0.07–0.14 0.7 0.02 0.01 0.5
T911 K91061 0.09–0.13 0.30–0.60 0.02 0.01 0.10–0.50
















































Delivery conditions



Normalized and tempered

Inspections and tests carried out

  • Chemical composition check, mechanical property tests (tensile strength, yield strength, elongation, flattening, flattening, bending, hardness, impact test
  • Tensile strength, yield strength, elongation, flaring, flattening, bending, hardness, impact testing), surface and dimensional testing, non-destructive testing.
  • Surface and dimensional testing, non-destructive testing, hydraulic testing.
