GB/T13296-2013 S32168 06Cr18Ni11Ti Stainless Steel Tubes For Heat Exchanger

GB/T13296-2013 S32168 06Cr18Ni11Ti Stainless Steel Tubes For Heat Exchanger

GB/T13296-2013 S32168 06Cr18Ni11Ti Stainless Steel Tubes For Heat Exchanger
video
GB/T13296-2013 S32168 06Cr18Ni11Ti Stainless Steel Tubes For Heat Exchanger
Product Details:
Place of Origin: China, USA, Korea, UE
Brand Name: YUHONG
Certification: ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number: GB/T13296-2013 S32168 06Cr18Ni11Ti
Payment & Shipping Terms:
Minimum Order Quantity: 100KGS
Price: negotiable
Packaging Details: Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Delivery Time: 10days->
Payment Terms: T/T, L/C
Supply Ability: 1500 tons per month
Contact Now
All Products
Stainless Steel Seamless Pipe (277)
Stainless Steel Seamless Tube (269)
Duplex Stainless Steel Pipe (128)
Duplex Stainless Steel Tube (27)
Needle Tube (86)
Fin Tube (596)
Heat Exchanger (10)
Heat Exchanger Tube (419)
Heat Exchanger Tube Bundle (37)
Heat Exchanger Tubesheet (117)
Heat Exchanger Baffle (35)
Air Cooler (7)
Pressure Vessel (2)
Stainless Steel Welded Pipe (57)
Stainless Steel Welded Tube (113)
Nickel Alloy Pipe (258)
Nickel Alloy Tube (75)
Copper Alloy Tube (210)
Alloy Steel Tube (173)
Titanium Tube (9)
Bright Annealed Tube (153)
Boiler Tube (138)
Steel Fitting (784)
Steel Flange (574)
Others (384)
Detailed Product Description
Standard: GB/T13296-2013 Grade: S32168 06Cr18Ni11Ti
OD: 12.7MM , 15.88MM , 19.05MM , 25.4MM, 31.75MM, 38.1MM , 44.45MM, 50.8MM, 63.5MM, 76.2MM WT: 0.89MM, 1MM, 1.24MM, 1.5MM, 1.65MM, 1.8MM, 2MM, 2.11MM, 2.43MM, 2.5MM, 2.7MM, 3.05MM, 3.4MM
Length: Max. 26m/pc NDT: 100% ET / HT/ UT
Highlight:

06Cr18Ni11Ti Stainless Steel Tubes

,

S32168 Stainless Steel Tubes

,

Heat exchanger Stainless Steel Tubes

GB/T13296-2013 S32168 06Cr18Ni11Ti Stainless Steel Tubes for Boiler



YUHONG Group's S32168 stainless steel is Ni-Cr-Ti austenitic stainless steel with properties such as wear resistance, high temperature resistance, creep resistance, etc. It is used in the manufacture of wear-resistant acid containers and wear-resistant equipment linings,
Creep resistance, etc., used in the manufacture of wear-resistant acid containers and wear-resistant equipment lining,
Conveying pipeline. S32168 corresponds to the new national grade: 06Cr18Ni11Ti, the old grade (0Cr18Ni11TI).

Stainless Steel Seamless Tubing

  • Size: 1/2" OD - 12" OD
  • OD: 3.00 - 219.10 mm
  • Thickness : 0.40 - 12.70 mm
  • Length: Single, Double Random & Cut Length

Chemical composition (wt.%)



C(％) Si(％) Mn(％) P(％) S(％) Cr(％) Ni(％) Mo(％) Ti(%)
0.08 1.0 2.0 0.045 0.03 17.0-19.0 9.0-12.0 4.0-6.0 5C-0.70

Mechanical Properties



Rp0.2 (MPa) Rm (MPa) Impact
KV (J)		 Elongation
A (%)		 A Z (%) Delivery Hardness HB
187 (≥) 184 (≥) 32 21 44 Solution & Aging, Ann, Ausaging, Q+T 124

S32168/321/S32100/1-4541 TubeRange of products


Product type Products Dimension Processes
Plates/Sheets Plates/Sheets 0.08-200mm(T)*W*L Forging,hot rolling and cold rolling
Steel Bar Round Bar,Flat Bar,Square Bar Φ8-1200mm*L Forging,hot rolling and cold rolling,Cast
Coil/Strip Steel Coil/Steel Strip 0.03-16.0x1200mm Cold-Rolled&Hot-Rolled
Pipes/Tubes Seamless Pipes/Tubes,Welded Pipes/Tubes OD:6-219mm x WT:0.5-20.0mm Hot extrusion,Cold Drawn,Welded



Test Certificate
  • DFARS compliant
  • EN 10204/3.1B, EN 10204 3.1 and EN 10204 3.2 Material Test Certificates (MTC)
  • 100% Radiography Test Report
  • Raw Materials Certificate
  • Third Party Inspection Report
  • Fumigation Certificates
  • Heat Treatment Charts
  • HS Code Commercial Invoice
  • Manufacturer Test Certificate
  • Surface roughness measurement
  • Laboratory Test Certificate from Govt. Approved Lab

Application

  • Shipbuilding industry: Corrosion-resistant components are needed in harsh marine environments.
  • Petrochemical industry: Chemical processing equipment requiring high temperature and corrosion resistance.
  • High temperature and corrosion resistant equipment is required.
  • Nuclear Energy. Components in nuclear reactors must be made of materials that can withstand high temperatures and corrosive environments.
  • Environmental...
  • Electronics and Turbine Manufacturing: Components requiring durability, heat and wear resistance.
  • High-speed rail and marine engineering: Structural components that need to withstand pressure and temperature fluctuations.
  • Temperature fluctuations.
  • Pressure Vessel and Machine Building: Components designed to withstand high pressures and temperatures.
  • Temperature components.
