P22 Alloy Steel Seamless Tubes For Bubbling Fluidized Bed Biomass Boiler

P22 Alloy Steel Seamless Tubes For Bubbling Fluidized Bed Biomass Boiler

  • P22 Alloy Steel Seamless Tubes  For Bubbling Fluidized Bed Biomass Boiler
  • P22 Alloy Steel Seamless Tubes  For Bubbling Fluidized Bed Biomass Boiler
  • P22 Alloy Steel Seamless Tubes  For Bubbling Fluidized Bed Biomass Boiler
  • P22 Alloy Steel Seamless Tubes  For Bubbling Fluidized Bed Biomass Boiler
P22 Alloy Steel Seamless Tubes  For Bubbling Fluidized Bed Biomass Boiler
Product Details:
Place of Origin: CHINA
Brand Name: YUHONG SPECIAL STEEL
Certification: ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008.
Model Number: ASTM A335 P22 Alloy Stainless Steel Seamless Pipes
Payment & Shipping Terms:
Minimum Order Quantity: 100KGS
Price: NEGOTIABLE
Packaging Details: Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Delivery Time: 30days, 60days etc..
Payment Terms: L/C, T/T
Supply Ability: 800 Tons/ month
Contact Now
Detailed Product Description
Specification: ASTM A335 P22 Alloy Stainless Steel Seamless Pipes O.D.: 25mm, 32mm, 40mm, 51mm, 76mm
WT: 2mm, 3mm, 5mm, 8mm Etc.. Shape: Round
Certification: ISO,SGS,BV,ISO & SGS,ISO/CE/SGS Length: 6000 To 12000 MM
Package: Standard Seaworthy Package Application: BFB, Bubbling Fluidized Bed Biomass Boiler
Highlight:

P22 Alloy Steel Seamless Tubes

,

Bubbling Fluidized Bed Biomass Boiler Tubes

,

Biomass Boiler Alloy Steel Seamless Tubes

P22 Alloy Steel Seamless Tubes for Bubbling Fluidized Bed Biomass Boiler



Yuhong Group, a global leader in high-performance alloy steel tubes and heat exchanger solutions, proudly offers P22 Alloy Steel Seamless Tubes designed for Bubbling Fluidized Bed (BFB) Biomass Boilers. With over 20 years of export experience and clients in 80+ countries, Yuhong Group is recognized as one of China’s top five exporters of boiler heat exchanger tubes.



The P22 Alloy Steel Seamless Tube, manufactured to ASTM A335 standards, is specifically engineered for high-temperature and high-pressure applications. It is an ideal choice for biomass boilers, providing exceptional reliability, corrosion resistance, and long service life in demanding environments.


Advantages of P22 Alloy Steel Material



P22 Alloy Steel is a low-alloy, chromium-molybdenum steel known for its excellent performance in high-temperature and high-pressure environments. Key advantages include:



Property Benefits
High-Temperature Strength Maintains mechanical integrity under temperatures up to 600°C (1112°F).
Corrosion Resistance Resists oxidation and scaling in aggressive biomass combustion environments.
Thermal Stability Ensures long-term performance with minimal deformation or creep.
Good Weldability Simplifies fabrication and installation in complex boiler systems.
Cost-Effectiveness Offers a balance of performance and affordability for boiler applications.





These properties make P22 Alloy Steel Seamless Tubes a popular choice for biomass boiler applications, where durability and efficiency are critical.


Introduction to Biomass Bubbling Fluidized Bed Boilers



Biomass Bubbling Fluidized Bed (BFB) Boilers are a sustainable solution for energy production, utilizing renewable biomass fuels such as wood, agricultural residues, and organic waste. These boilers operate by suspending biomass particles in a bed of air or gas, creating a bubbling motion that enhances heat transfer and combustion efficiency.

  • Key Features of BFB Boilers:

    1. High Combustion Efficiency: The bubbling motion ensures thorough mixing of fuel and air, maximizing energy output.
    2. Fuel Flexibility: Capable of using a variety of biomass fuels, including low-grade materials.
    3. Reduced Emissions: Effective at minimizing NOx and SOx emissions compared to traditional boiler systems.
  • Operating Conditions:

    • Temperatures: Typically between 800°C to 900°C (1472°F to 1652°F).
    • Pressures: High-pressure environments requiring robust materials like P22 Alloy Steel.

The advanced design of BFB boilers demands materials with excellent high-temperature strength, corrosion resistance, and thermal stability, making P22 Alloy Steel Tubes a preferred choice.


Applications of P22 Alloy Steel Tubes in Biomass Boilers



The P22 Alloy Steel Seamless Tubes are used in critical components of biomass boiler systems, including:

  1. Water Walls:

    • Used to contain and transfer heat from the combustion chamber to water for steam generation.
  2. Superheaters:

    • Located in the hottest part of the boiler, superheaters require materials like P22 to withstand extreme temperatures and pressures.
  3. Economizers:

    • Installed to recover waste heat from flue gases and improve overall boiler efficiency.
  4. Heat Exchangers:

    • Facilitate efficient heat transfer in boiler systems, enhancing energy utilization.
  5. Headers and Manifolds:

    • Distribute steam and water within the boiler system, requiring materials with excellent mechanical strength.

Available Sizes of P22 Alloy Steel Seamless Tubes



Yuhong Group offers a wide range of sizes for P22 Alloy Steel Seamless Tubes, ensuring compatibility with diverse boiler designs and specifications. Below are standard dimensions:



Outer Diameter (OD) Wall Thickness (WT) Length Type
21.3mm (1/2") Sch 40 / Sch 80 Up to 12 meters Seamless
33.4mm (1") Sch 40 / Sch 80 Cut-to-length or custom Seamless
60.3mm (2") Sch 40 / Sch 80 / Sch 120 Straight lengths or U-bends Seamless
114.3mm (4") Sch 40 / Sch 80 Customizable Seamless
219.1mm (8") Sch 40 / Sch 80 / Sch XXS As per project needs Seamless

Custom sizes and schedules can be provided upon request to meet specific project requirements.


Conclusion



Yuhong Group’s P22 Alloy Steel Seamless Tubes are engineered to meet the stringent demands of biomass bubbling fluidized bed boilers and other high-temperature applications. With exceptional strength, thermal stability, and resistance to corrosion, these tubes ensure reliable performance and long service life in the most challenging environments.



Contact us today to learn more about our P22 Alloy Steel Seamless Tubes or request a free quote. Let Yuhong Group provide the ideal solution for your biomass boiler and heat exchanger needs!
