ASME SA350 LF2 Class 1 Forged Carbon Steel Nozzle Cover Flange for Piping Systems

ASME SA350 LF2 Class 1 Forged Carbon Steel Nozzle Cover Flange for Piping Systems

  • ASME SA350 LF2 Class 1 Forged Carbon Steel Nozzle Cover Flange for Piping Systems
  • ASME SA350 LF2 Class 1 Forged Carbon Steel Nozzle Cover Flange for Piping Systems
  • ASME SA350 LF2 Class 1 Forged Carbon Steel Nozzle Cover Flange for Piping Systems
  • ASME SA350 LF2 Class 1 Forged Carbon Steel Nozzle Cover Flange for Piping Systems
ASME SA350 LF2 Class 1 Forged Carbon Steel Nozzle Cover Flange for Piping Systems
Product Details:
Place of Origin: CHINA
Brand Name: YUHONG
Certification: ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number: ASME SA350 LF2 Class 1
Payment & Shipping Terms:
Minimum Order Quantity: 500KGS
Price: Negotiable
Packaging Details: Ply-wooden Case /Iron Case
Delivery Time: 15-20 Days
Payment Terms: L/C, T/T
Supply Ability: 800 Tons/ Month
Contact Now
All Products
Stainless Steel Seamless Pipe (308)
Stainless Steel Seamless Tube (297)
Duplex Stainless Steel Pipe (132)
Duplex Stainless Steel Tube (33)
Needle Tube (134)
Fin Tube (672)
Heat Exchanger (20)
Heat Exchanger Tube (443)
Heat Exchanger Tube Bundle (40)
Heat Exchanger Tubesheet (117)
Heat Exchanger Baffle (37)
Air Cooler (9)
Pressure Vessel (4)
Stainless Steel Welded Pipe (58)
Stainless Steel Welded Tube (120)
Nickel Alloy Pipe (266)
Nickel Alloy Tube (92)
Copper Alloy Tube (240)
Alloy Steel Tube (204)
Titanium Tube (15)
Bright Annealed Tube (155)
Boiler Tube (151)
Steel Fitting (826)
Steel Flange (615)
Others (401)
Cladding Parts (7)
Detailed Product Description
​Standard​: ASME SA350 Grade​: LF2 Class 1
Material Type​: Forged Carbon Steel Application​: Low Temperature Piping Systems
Face Type​: Raised Face (RF) / Ring Type Joint (RTJ) Size Range​: Custom Size
Highlight:

ASME SA350 LF2 forged flange

,

carbon steel nozzle cover flange

,

piping system forged steel flange

ASME SA350 LF2 Class 1 Forged Carbon Steel Nozzle Cover Flange for Piping Systems



​​YUHONG GROUP​​ specializes in manufacturing ​​ASME-certified forged steel flanges​​ for critical low-temperature applications. Our ​​ASTM A350 LF2 Class 1 Forged Carbon Steel Nozzle Cover Flanges​​ are engineered to deliver reliable performance in cryogenic piping systems operating as low as ​​-46°C.

​​Chemical Composition of ASTM A350 LF2 (UNS K03011) Forged Steel Flange​



​Element​​ ​​Requirement (%)​​ ​​Notes​​
​​Carbon (C)​​ ≤0.30 Controlled for weldability
​​Manganese (Mn)​​ 0.60-1.35 Enhances strength and toughness
​​Phosphorus (P)​​ ≤0.035 Minimizes brittleness
​​Sulfur (S)​​ ≤0.040 Improves machinability
​​Silicon (Si)​​ 0.15-0.30 Deoxidizer and strength enhancer
​​Nickel (Ni)​​ ≤0.40 Part of the alloy sum restriction
​​Chromium (Cr)​​ ≤0.30 Part of the Cr+Mo sum restriction
​​Molybdenum (Mo)​​ ≤0.12 Part of the Cr+Mo sum restriction
​​Copper (Cu)​​ ≤0.40 Part of the alloy sum restriction
​​Columbium (Cb)​​ ≤0.02 Controlled for weldability
​​Vanadium (V)​​ ≤0.08 Grain refinement control

Tensile Properties for ASTM A350 LF2 Class 1/2



​​Property​​ ​​Requirement for LF2 Class 1 & 2​​ ​​Notes​​
​​Tensile strength​​ 70-95 ksi [485-655 MPa] Range applies to both Class 1 & 2
​​Yield strength, min​​ 36 ksi [250 MPa] By a 0.2% offset or a 0.5% extension method
​​Elongation (standard round specimen)​​ 22% min in 4D gauge length For full-section testing
​​Elongation (strip specimen)​​ 30% min in 2 in. (50 mm) For thickness ≥7.94 mm
​​Reduction of area, min​​ 30% Applies to round specimens only

Impact Test Temperature for ASME SA350



​Grade​​ ​​Test Temperature, °F [°C]​​
LF1 -20 [-29]
LF2, Class 1 -50 [-46]
LF2, Class 2 0 [-18]
LF3, Classes 1 and 2 -150 [-101]
LF5, Classes 1 and 2 -75 [-59]
LF6, Classes 1 and 2 -60 [-51]
LF6, Class 3 0 [-18]
LF9 -100 [-73]
LF787, Class 2 -75 [-59]
LF787, Class 3 -100 [-73]

​​Key Advantages of ASTM A350 LF2 Class 1 Forged Carbon Steel Nozzle Cover Flange​

​

​​1. Certified Low-Temperature Performance​​

​​Guaranteed impact toughness​​ at -46°C (-50°F) per ASTM A350 Table 4

​​Class 1 designation​​ ensures superior performance in cryogenic service compared to Class 2

​​2. Optimized Material Composition​​

​​Controlled carbon content (≤0.30%)​​ enables excellent weldability without preheat requirements

​​Manganese content (0.60-1.35%)​​ provides an optimal balance of strength and toughness

​​3. Manufacturing Reliability​​

​​Forged construction​​ eliminates defects and ensures structural integrity under pressure

​​Full traceability​​ with heat number marking and EN 10204 3.1 certification available

​​4. Quality Verification​​

​​100% non-destructive testing​​ (PT/MT/UT) available upon request

​​Third-party inspection​​ acceptance (SGS/BV/DNV)

ASME SA350 LF2 Class 1 Forged Carbon Steel Nozzle Cover Flange for Piping Systems 0
