ASTM A249 TP304 Stainless Steel Welded Bright Annealed Tube For Brewery , Electropolished Tube

ASTM A249 TP304 Stainless Steel Welded Bright Annealed Tube For brewery , Electropolished Tube

ASTM A249 stainless steel welded tubes are ideal for applications which require good dimensional precision and excellent polished surfaces. The bright annealed surface finish and cold drawn process enhance performance of tubes, making them suitable for food grade applications, beverage industry, sugar refinery, chemical processing, and industrial systems. These welded tubes are manufactured by forming flat strips of stainless steel 304 into a tube shape and welding the seam longitudinally using an automated process (TIG welding). After welding, the tube undergoes a solution annealing treatment. The bright annealing process occurs in a controlled atmosphere furnace. This process relieves internal stresses induced during forming and welding, and produces a smooth, oxide-free surface. The absence of scale eliminates the need for further chemical pickling, ensuring a pristine finish ideal for hygienic and high-purity applications.

YUHONG GROUP has produced ASTM A249 / ASME SA249 TP304, TP304L, TP316, TP316L, TP321, TP321H, TP310S, TP347H stainless steel welded tubes for 40 years. The regular outer diameter size range from 6mm to 76.2mm, while the wall thickness can be 0.5mm - 3.4mm. We generally cut such tubes into 6 meter per piece. If clients have customized requests, we can also meet their requirements.

Chemical Composition of SS304:

Mechanical Properties of SS304:

Key Advantages Of ASTM A249 SS304 Welded Tubes:

• Superior Corrosion Resistance: The 18/8 chromium-nickel composition provides excellent resistance to oxidation and a wide range of corrosive media.
• Hygienic and Smooth Surface: The Bright Annealed finish is non-porous and extremely smooth, preventing bacterial growth and making it ideal for sanitary applications.
• Excellent Mechanical Properties: Good tensile and yield strength combined with high ductility, allowing for easy bending and forming.
• Consistent Dimensional Accuracy: The welding and drawing process ensures uniform wall thickness and roundness.
• Heat Resistance & Excellent Weldability

Applications of SS304 Welded Tubes:

• Heat Exchangers and Condensers: Used extensively in power generation, petrochemical, and HVAC industries.
• Food and Beverage Industry: For transporting milk, beer, oils, and other food products where hygiene is paramount.
• Pharmaceutical and Biotechnology: For clean steam, purified water (Water For Injection), and process lines requiring sterile environments.
• Dairy Industry: For pipelines, storage tanks, and processing equipment.
• Instrumentation: Used as tubing for pneumatic controls and instrument air lines.
• Automotive: Exhaust systems and decorative trims.
• Construction: Handrails, architectural tubing, and structural supports where a bright finish is desired aesthetically.
