ASME SB725 UNS N04400 Monel 400 Nickel Alloy Steel Welded Pipe For Oil And Gas Marine Projects

Product Details:

Place of Origin:	CHINA
Brand Name:	YUHONG
Certification:	ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number:	ASME SB725 UNS N04400

Payment & Shipping Terms:

Minimum Order Quantity:	100KGS
Price:	NEGOTIABLE
Packaging Details:	Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Delivery Time:	20-80 Days
Payment Terms:	L/C, T/T

Contact Now

All Products

Stainless Steel Seamless Pipe (337)

Stainless Steel Seamless Tube (326)

Duplex Stainless Steel Pipe (134)

Duplex Stainless Steel Tube (38)

Needle Tube (162)

Fin Tube (708)

Heat Exchanger (31)

Heat Exchanger Tube (468)

Heat Exchanger Tube Bundle (50)

Heat Exchanger Tubesheet (125)

Heat Exchanger Baffle (39)

Air Cooler (13)

Pressure Vessel (4)

Stainless Steel Welded Pipe (61)

Stainless Steel Welded Tube (132)

Nickel Alloy Pipe (275)

Nickel Alloy Tube (103)

Copper Alloy Tube (251)

Alloy Steel Tube (212)

Titanium Tube (20)

Bright Annealed Tube (173)

Boiler Tube (152)

Steel Fitting (863)

Steel Flange (662)

Others (406)

Cladding Parts (9)

Detailed Product Description

Standard:	JIS, AISI, ASTM, GB, DIN, EN	SPECIFICATION:	ASME SB725 UNS N04400
Shape:	Round	Type:	Seamless
Length:	Customized	Processing Service:	Bending, Welding, Decoiling, Punching, Cutting
Highlight:	ASME SB725 Monel 400 welded pipe , UNS N04400 nickel alloy pipe , Monel 400 pipe for marine projects

ASME SB725 UNS N04400 Monel 400 Nickel Alloy Steel Welded Pipe For Oil And Gas Marine Projects

ASME SB725 is a specific standard specification for welded nickel and nickel alloy pipes, applicable to UNS N04400 nickel-copper alloy welded pipes. The pipes covered by this standard are supplied in annealed or stress-relieved conditions, primarily targeting general corrosive environments and mechanical applications.

UNS N04400 is a nickel-copper solid solution strengthened alloy, typically with a nickel content of at least 63% and a copper content of 28%–34%. Its significant characteristic is that it requires no aging hardening treatment; high strength can be achieved through cold working alone—a typical behavior of solid solution strengthened alloys.

Therefore, ASME SB725 UNS N04400 welded pipes can be considered a dedicated nickel-copper alloy piping solution for strongly reducing acidic media and seawater environments. It is particularly suitable for applications with stringent corrosion resistance requirements, such as hydrofluoric acid (HF) alkylation plants, marine engineering pipelines, and chemical processing equipment.

Chemical Composition (UNS N04400)
Element	Content Range (%)
Ni (Nickel)	≥ 63.0
Cu (Copper)	28.0 - 34.0
Fe (Iron)	≤ 2.5
Mn (Manganese)	≤ 2.0
Si (Silicon)	≤ 0.5
C (Carbon)	≤ 0.3
S (Sulfur)	≤ 0.024

Mechanical Properties – ASME SB725 Standard Requirements
Condition	Size Range	Tensile Strength (MPa)	Yield Strength 0.2% (MPa)	Elongation (%)
Annealed	OD ≤ 127mm (5 in.)	≥ 480	≥ 195	≥ 35
Annealed	OD > 127mm (5 in.)	≥ 480	≥ 170	≥ 35
Stress Relieved	All sizes	≥ 585	≥ 380	≥ 15

Mechanical Properties – Industry Reference Values (Annealed)
Parameter	Value
Tensile Strength	480 - 550 MPa
Yield Strength (0.2% offset)	172 - 240 MPa
Elongation	35% - 40%
Hardness	110 - 160 HBW
Elastic Modulus	173 - 180 GPa

Heat Treatment Requirements
Item	Parameter
Annealing Temperature (post-weld)	≥ 926°C (1700°F)
Post-Weld Heat Treatment	Annealing or stress relieving required unless otherwise specified in order
Stress Relieving (cold worked)	300 - 320°C, hold 30-60 min, air cool

Application

Petrochemical Industry: Piping, valves, flanges, and containers for HF alkylation units (API 752 recommended materials)
Marine Engineering: Seawater intake pipelines, ballast water pipelines, seawater cooling systems, pump shafts, and propeller shafts
Chemical Processing: Hydrofluoric acid production equipment, fluorine and fluoride processing pipelines, and containers for sulfuric acid/hydrochloric acid reducing environments
Power Industry: Boiler feedwater heaters, deaerator heaters, and nuclear power plant heat exchanger tube bundles
