Detailed Product Description

Highlight:

ASTM A358 CL1 stainless steel pipe

TP316L corrosion resistant steel pipe

electric fusion welded stainless pipe

YUHONG brand goods have been already exported to more than 85 countries With more than 35 years' experience, because of strict quality control policy, excellent sales service, delivery on time. YUHONG won more and more new clients and got more and more repeat orders from old clients, in YUHONG People's mind: Quality is First Important!

ASTM A358-CL1 TP316/TP316L Electric-Fusion-Welded Stainless Steel Pipe with Strong Corrosion Resistance

This specification covers electric-fusion-welded austenitic chromium-nickel stainless steel pipe suitable for corrosive or high-temperature service, or both, or for general applications.ASTM A358-CL1 TP316/TP316L Electric-Fusion-Welded Stainless Steel Pipe refers to an electric-fusion-welded austenitic stainless steel pipe manufactured in accordance with ASTM A358/A358M, specified as Class 1 quality level and with dual-certified material TP316/TP316L. The pipe is formed from steel plate or strip by electric-fusion welding (single or double arc welding). Class 1 requires 100% radiographic examination of the weld and permits double-welded joints. The TP316 material meets the high-temperature strength and excellent intergranular corrosion resistance of TP316L. This product is suitable for high-temperature, corrosive, or low-temperature services and is widely used in chemical, petrochemical, marine engineering, pressure vessels, and heat exchangers.

Specifications	ASTM A358 / A358M
Type	Welded Pipe
Out Diameter	NPS 8" - NPS 110"
Wall Thickness	SCH.5, 10, 20, 30, 40, 60, 80, 100, 120, 140, 160, XX, (3 mm to 100 mm Thickness)
Grades	ASTM A358 304, 304L, 310S, 316,316L,316H,317L,321,321H, 347, 347H, 904L
A358 Pipe Classes (CL)	CL1, CL2, CL3, CL4, CL5
Type	EFW, ELECTRIC FUSION WELDED
EFW Pipe End	Plain Ends / Beveled Ends

1.Chemical & Mechanical Properties

ASTM A358 TP316/TP316L Chemical Composition (%)
Grade	C	Mn	P	S	Si	Cr	Ni	N
TP316	≤0.08	≤2.00	≤0.045	≤0.03	≤0.75	16.0~18.0	10.0-14.0	≤0.10
TP316L	≤0.03	≤2.00	≤0.045	≤0.03	≤0.75	16.0~18.0	10.0-14.0	≤0.10

Mechanical Properties

Tensile Strength	Yield Strength	Elongation	Heat Treating Temperature
75000Psi [515Mpa]	30000Psi [205Mpa]	35 %	1900 °F [1040 °C]

2. Key Adventages

100% Radiographic Examination of Weld – Superior Weld Quality
Electric-Fusion Welding – Ideal for Large Diameter, Thin or Thick Wall Pipe
Excellent Corrosion Resistance – Suitable for Aggressive Media
Wide Temperature Range – From Cryogenic to Elevated Temperatures

3. Key Applications

Chemical and petrochemical industries: Chemical processing plants, refineries, and petrochemical facilities.
Oil and gas industries: Used for transporting fluids such as crude oil, natural gas, and refined petroleum products.
Power generation industries: Used in boiler piping, heat exchangers, and condensers.

ASTM A358-CL1 TP316/TP316L Electric-Fusion-Welded Stainless Steel Pipe with Strong Corrosion Resistance 0
