ASTM A249 TP316L Bright Annealed Stainless Steel Welded Tubes , Used For Air Coolers

Product Details:

Place of Origin:	China
Brand Name:	YUHONG
Certification:	ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2015
Model Number:	TP304, TP304L, TP316, TP316L, TP321, TP321H, TP310S, TP347H

Payment & Shipping Terms:

Minimum Order Quantity:	100 KGS
Price:	Negotiable
Packaging Details:	Plywood Case
Delivery Time:	20-60 Days
Payment Terms:	T/T, L/C at sight
Supply Ability:	1000 Tons Per Month

Contact Now

Standard:

ASTM A249/ASME SA249

Raw Material Grades:

TP304, TP304L, TP316, TP316L, TP321, TP321H, TP310S, TP347H, TP904L, ...

Outer Diameter:

6.35-152.4mm

Wall Thickness:

0.5-3.4mm

Length:

6 Meters Or As Customized

Ends:

Bevlled End, Plain End, Thread End

Surface Finish:

Bright Annealed, Pickled And Annealed, Mechanical Polished

Applications:

Heat Exchanger, Boiler, Heaters, Air Coolers, Petroleum Industry, Food Processing Industry, Condenser, Etc.

Highlight:

Parameter	Common Range
Outer Diameter (OD)	6.35mm to 152.4mm (1/4" to 6")
Wall Thickness (WT)	0.5mm to 3.4mm or As Requested
Length per Piece	Single Random Length (SRL): 4.0m – 7.0m Double Random Length (DRL): 7.0m – 13.0m

Element	Composition (Weight, %)
Carbon (C)	≤ 0.035
Manganese (Mn)	≤ 2.00
Phosphorus (P)	≤ 0.045
Sulfur (S)	≤ 0.030
Silicon (Si)	≤ 1.00
Chromium (Cr)	16.0 – 18.0
Nickel (Ni)	10.0 – 14.0
Molybdenum (Mo)	2.0 – 3.0
Nitrogen (N)	≤ 0.10 (max)

Finish Type	Description	Key Characteristic
Bright Annealed (BA)	Mirror-like, highly reflective surface produced by heat treatment in a reducing atmosphere. Oxide-free.	Highest corrosion resistance due to an intact, chromium-rich passive layer. No pickling required.
Pickled (AP)	Chemically cleaned to remove oxides; matte, dull grey finish.	Cost-effective, but rougher. Requires passivation post-pickling.
Mechanically Polished (MP)	Ground and polished post-annealing to achieve a specific shine.	Brighter than AP, but removes the as-annealed pristine surface layer.
