Corrosion Resistant Alloy 625 Inconel Tubing , ASME SB444 GR.2 Inconel 625 Seamless tube

Corrosion Resistant Alloy 625 Inconel Tubing , ASME SB444 GR.2 Inconel 625 Seamless tube

    • Corrosion Resistant Alloy 625 Inconel Tubing , ASME SB444 GR.2  Inconel 625 Seamless tube
    • Corrosion Resistant Alloy 625 Inconel Tubing , ASME SB444 GR.2  Inconel 625 Seamless tube
    • Corrosion Resistant Alloy 625 Inconel Tubing , ASME SB444 GR.2  Inconel 625 Seamless tube
    • Corrosion Resistant Alloy 625 Inconel Tubing , ASME SB444 GR.2  Inconel 625 Seamless tube
    • Corrosion Resistant Alloy 625 Inconel Tubing , ASME SB444 GR.2  Inconel 625 Seamless tube
  • Corrosion Resistant Alloy 625 Inconel Tubing , ASME SB444 GR.2  Inconel 625 Seamless tube

    Product Details:

    Place of Origin: China, USA, Korea, UE
    Brand Name: YUHONG SPECIAL STEEL
    Certification: ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
    Model Number: ASME SB167 UNS NO 6600. UNS6600H

    Payment & Shipping Terms:

    Minimum Order Quantity: 100KGS
    Price: negotiable
    Packaging Details: Ply-wooden Case /Iron Case/ Bundle with plastic Cap
    Delivery Time: 10days->
    Payment Terms: T/T, L/C
    Supply Ability: 1500 tons per month
    Contact Now
    Detailed Product Description
    Standard: ASME SB444 SB704 , SB705 Grade: Inconel 625®, Chronin® 625, Altemp® 625, Haynes® 625, Nickelvac® 625, Nicrofer® 6020
    Size: OD:3MM TO 530MM ,WT:0.2MM TO 60MM, L:MAX 50M PACKING: Ply-wooden Case Or Iron Case

    Corrosion Resistant Alloy 625 Inconel Tubing , ASME SB444 GR.2 Seamless Pipe



    Inconel ® 625 is a nonmagnetic, corrosion and oxidation resistant, nickel-base alloy. It has high strength and toughness in the temperature range cryogenic to 2000°F (1093°C) which is derived largely from the solid solution effects of the refractory metals, columbium and molybdenum, in a nickel-chromium matrix. Alloy 625 has excellent fatigue strength and stress - corrosion cracking resistance to chloride ions.

    Typical applications for Alloy 625 have included heat shields, furnace hardware, gas turbine engine ducting, combustion liners, spray bars, chemical plant hardware and special seawater applications.Available forms are seamless pipe, welded pipe, seamless tube, welded tube, bar, wire, sheet, plate, forgings, pipe fittings and flanges like inconel 625 plates, inconel 625 pipe, inconel 625 reducer, inconel 625 round bar, inconel 625 fittings, inconel 625 elbow, inconel 625 sheet, inconel 625 tube etc.

    Chemical Analysis of ALLOY 625 (UNS N06625)
    Common Names : Inconel 625®, Chronin® 625, Altemp® 625, Haynes® 625, Nickelvac® 625, Nicrofer® 6020

    C MN P S Si Cr Ni Mo Cu Co Cb Ta Ti Al Fe Nb Other
    0.1 .50 max .015 max .015 max .50 max 20.0 -23.0 58.0 min 8.0 -10.0   1.0 max   0.40 max 0.40 max 5.0 max 3.15 -4.15



    Specifications

    International Specifications Sheet/Plate Round Bar Pipe Tube Fittings Forgings
    BS 3072, BS 3074, BS 3076, NA 21 DIN 17744, DIN 17750, DIN 17751, DIN 17752, DIN 17754. Werkstoff Nr. 2.4856 AFNOR NC 22 D Nb ASME SB-443 AMS 5599 AMS 5869 ASME SB-446 AMS 5666 AMS 5837 ASME SB-444 ASME SB-829 ASME SB-775 ASME SB-705 ASME SB-444 ASME SB-829 ASME SB-751 ASME SB-704 AMS 5581 ASME SB- 366 ASME SB- 564 AMS 5666





    Inconel 625 Alloy is frequently used for:

    • Heat shields
    • Tubing
    • Combustion and chimney liners
    • Valves
    • Piping
    • Distillation columns
    • Bubble caps
    • Reaction vessels
    • Heat exchangers
    • Furnace hardware
    • Gas turbine engine duct work
    • Equipment used to produce acid
    • Sour gas production tubes



    Corrosion Resistant Alloy 625 Inconel Tubing , ASME SB444 GR.2  Inconel 625 Seamless tube
