Yuhong Holding Group Co.,LTD
Place of Origin: | CHINA |
Brand Name: | YUHONG |
Certification: | ABS, BV, DNV, GL, LR, SGS, IEI |
Model Number: | ASTM A335 P22 P11 P9 P91 ALLOY STEEL SEAMLESS PIPE |
Minimum Order Quantity: | 10 pcs |
---|---|
Price: | negotiable |
Packaging Details: | Ply-wooden Case, Iron Case,Woven bags packing, Plastic caps on both ends. |
Delivery Time: | according to quantity |
Payment Terms: | T/T, L/C |
Supply Ability: | 1500 tons per month |
Material: | P1/P5/P9/P11/P12/P22/P91 | Standard: | ASTM A335, ASTM A213 |
---|---|---|---|
Surface: | Black Or Varnish Coating | Length: | 6M Or Specified Length As Required |
Packing: | Ply Wooden Case | Type: | Seamless |
High Light: | alloy steel tube,stainless steel round tube |
Alloy steel seamless pipe/tube |
|
PIPES & TUBES |
: ASTM A335, ASTM A213, ASTM A691 |
PIPES FITTINGS |
: ASTM A234 |
FITTINGS & FLANGES |
: ASTM A182 |
GRADES |
: P1/P5/P9/P11/P12/P22/P91 & T5/T9/T11/T22/T91 |
FORM (PIPES) |
: SEAMLESS / E.R.W / EFSW |
|
|
Available Shapes : |
|
Tubes & Pipes (SEAMLESS ) up to 30". Tubes & Pipes (ERW ) up to 60". Sheets / plates up to 150 MM. Rod / Bar up to 350 MM. Circle up to 1000 & Above as per your requirements. thickness up to 200 MM & Above as per requirements. |
Chemical composition(%):
Grade |
C |
Mn |
P≤ |
S≤ |
Si |
Cr |
Mo |
P11 |
0.05-0.15 |
0.30-0.60 |
0.025 |
0.025 |
0.50-1.00 |
1.00-1.50 |
0.44-0.65 |
P22 |
0.05-0.16 |
0.30-0.60 |
0.025 |
0.025 |
≤0.50 |
1.90-2.60 |
0.87-1.13 |
P5 |
≤0.15 |
0.30-0.60 |
0.025 |
0.025 |
≤0.50 |
4.00-6.00 |
0.45-0.65 |
P9 |
≤0.15 |
0.30-0.60 |
0.025 |
0.025 |
0.25-1.00 |
8.00-10.00 |
0.90-1.10 |
P91 |
0.08-0.12 |
0.30-0.60 |
0.020/0.010 |
0.020/0.010 |
0.02-0.50 |
8.00-9.50 |
0.85-1.05 |
P92 |
0.07-0.13 |
0.30-0.60 |
0.020/0.010 |
0.020/0.010 |
≤0.50 |
8.50-9.50 |
0.30-0.60 |
Mechanical properties:
Grade |
Tensile strength |
Yield strength |
Elongation |
P11, P22, P5, P9 |
≥415 |
≥205 |
≥30/20 |
P91 |
≥585 |
≥415 |
≥20 |
P92 |
≥620 |
≥440 |
≥20 |
