ASME SB163 Inconel 601 Nickel Alloy Seamless Tube Heat Exchanger Tube
YUHONG GROUP specializes in ASTM B167 Inconel 601 Seamless Tube with years of Experience in Manufacturing UNS N06601 Seamless Tube. we offer high quality, lower cost but the best service. As a result to that our ASTM B167 Inconel 601 Seamless Tubes export account today are more than 40 coumtries.
ASTM SB163 Inconel 601 Nickel Alloy Tube Specification
| Standard |
ASTM / ASME |
| Designation |
ASTM / ASME SB 163 |
| Type |
Seamless |
| Size |
15 NB to 150 NB IN |
| End |
Plain End, Beveled End, Treaded |
| Length |
Single Random, Double Random, Cut Length |
| Form |
Round, Square, Rectangular, Hydraulic etc. |
1.1 This specification2 covers nickel-chromium-iron alloys (UNS N06600, N06601, N06603, N06690, N06693, N0625, N06045, and N06696),3 nickel-chromium-cobalt-molybdenum alloy (UNS N06617), and nickel-iron-chromium-tungsten alloy UNS N06674), in cold-worked annealed, hot-worked annealed, and hot-finished seamless pipe and tube intended for general corrosion resistant and heat resistant applications.
1.2 The values stated in inch-pound units are to be regarded as standard. The values given in parentheses are mathematical conversions to SI units that are provided for information only and are not considered standard.
About Inconel 601
Inconel 601 is a nickel-chromium alloy used for applications that require resistance to corrosion and heat. This nickel alloy stands out due to its resistance to high temperature oxidation, remaining highly resistant to oxidation through 2200° F. Alloy 601 develops a tightly adherent oxide scale which resists spalling even under conditions of severe thermal cycling. This nickel alloy has good high temperature strength, and retains its ductility after long service exposure. It has good resistance to aqueous corrosion, high mechanical strength, and is readily formed, machined and welded. Inconel 601’s properties make it a material of broad utility in fields like thermal processing, chemical processing, pollution control, aerospace, and power generation. However, alloy 601 is not suggested for use in strongly reducing, sulfur bearing environments.
Standard Specification for Nickel-Chromium-Iron Alloys (UNS N06600, N06601, N06603, N06690, N06693, N0625, N06045, and N06696), Nickel-Chromium-Cobalt-Molybdenum Alloy (UNS N06617), and Nickel-Iron-Chromium-Tungsten Alloy (UNS N06674) Seamless Pipe and Tube
Inconel 601 characteristics
- 1. Outstanding oxidation resistance to 2200° F
- 2. Resists spalling even under severe thermal cycling conditions
- 3. Highly resistant to carburization
- 4. Good creep rupture strength
- 5. Metallurgical stability
| Chemical Composition, % |
| Ni |
Cr |
Al |
C |
Mn |
Si |
Fe |
| 61.5 |
22.5 |
1.4 |
0.05 |
0.3 |
0.2 |
14 |
| Mechanical Properties |
| Typical room temperature Properties |
| Tensile (psi) |
0.2% Yield (psi) |
Elongation (%) |
| 80,000 |
30,000 |
35 |
| ASTM Specifications |
| Pipe Smls |
Pipe Welded |
Tube Smls |
Tube Welded |
Sheet/Plate |
Bar |
Forging |
Fitting |
Wire |
| B167 |
B517 |
B167 |
- |
B168 |
B166 |
B564 |
B366 |
B166 |
Inconel 601 Applications
- 1. Chemical Processing
- 2. Aerospace
- 3. Heat treating industry
- 4. Power generation
- 5. Heat treating muffles and retorts
- 6. Radiant tubes
- 7. Catalyst support grids in nitric acid production
- 8. Steam superheater tube supports
